Page 1
NOTE: Parts are no longer available for this tool. The manual will continue on the next page.
Page 2
Remove Adjusting Key and Wrenches: Form habit of checking to see that keys and adjusting wrenches are removed from tool before turning it on. Caution: The use of an accessory with this tool not provided or specified by SIOUX TOOLS INC. may be hazardous. Printed In U.S.A.
Page 3
INSTRUCTIONS AND PARTS LIST FOR 2L1400-108 POWER UNIT SERIAL “A” Fig. Part Fig. Part Description Description 10220 Bearing—Ball 63258 Lever 13550 End Plate—Front 65499 Screw—Pan Hd (Selftap) 14342 Ring—“O” (#6–32 x 3/4 Long)(2)* 64057 Cylinder 54837 Adaptor—Intake 54860 Rotor (5800RPM) 14312 Ring—“O”...
Page 4
INSTRUCTIONS AND PARTS LIST FOR 2L1400-108 POWER UNIT SERIAL “A” Single Reductin Gear Case (5800 RPM) Fig. Part Description 1. 65144IP Case—Gear 30375 Fitting—Grease 19265 Gear—Ring 4. 65945IP Ass’y—Planetary Reduction (5800RPM) 10228 Bearing—Ball 25439 Washer(2)* 7. 65942IP Carrier—Gear(5800RPM) 10203 Bearing—Ball 19267 Gear—Pinion(5800RPM)
Page 5
Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to cause cancer, birth defects or other reproductive harm. El polvo generado al lijar, aserrar, afilar, taladrar y realizar otras tareas de construcción contiene sustancias químicas que podrían causar cáncer, malformaciones congénitas y otras alteraciones del aparato reproductor.
Page 6
This pdf incorporates the following model numbers: 2L1400-108...
