Technical data and limit values

7.3 Version

The specific version name can be found on the type label at the slot bracket of your board.

7.4 Limit values

Height:
Operating temperature:
Storage temperature:
Relative air humidity
at indoor installation:
Minimum PC requirements:
System bus:
Operating system:
Link speed:
Slot:
Safety:
Optical isolation:
Energy demand:
Operating voltage from the PC:
Current consumption (typ., without load)

7.4.1 Digital inputs (24 V)

Number of inputs:
Interruptible inputs:
Filter/Protective circuit:
Optical isolation:
Nominal voltage:
Input voltage:
Input current
(at nominal voltage):
Max. input frequency
(at nominal voltage):
Signal delay
(at nominal voltage):
Logic input levels:
www.addi-data.com
2000 m over NN
0-60 °C (with forced ventilation)
-25 °C to +70 °C
50 % at +40 °C
80 % at +31 °C
according to PCI Express Base Specification,
Revision 1.0a (PCI Express 1.0a)
Windows 7, Vista (32-bit), 2000, XP, Linux
2.5 Gbit/s
1-lane or 4-lane PCI Express slot
1000 V
3.3 V ±9 %
0.31 A ±10 %
7 (common GND according to IEC 1131-2)
7
low pass/TVS diodes
1000 V (via opto-couplers)
24 VDC
0-30 V
5-8 mA typ.
10 kHz
70 μs
UH
: 30 V
max
UH
: 19 V
min
UL
: 14 V
max
UL
: 0 V
min
26
APCIe-040
