- Page 1 Lite Operator Manual Clemas & Co. Unit 16 Ashchurch Business Centre, Alexandra Way, Tewkesbury, Gloucestershire, GL20 8NB. Tel: 01684 850777 Fax: 01684 850707 Email: info@clemas.co.uk Web: www.clemas.co.uk...
-
Page 2: Table Of Contents
Operating manual imop lite Contents 1 General ......................5 1.1 The product: imop lite ................5 1.2 Intended operation .................. 5 1.3 Delivery ....................6 2 Safety instructions..................7 2.1 General information regarding safety ............7 2.1.1 Signal words and warning symbols used ........... 7 2.1.2 Hazard statements ................ - Page 3 Operating manual imop lite 5.4 Turning the machine on ................. 31 5.5 Stopping and turning off the machine ............ 31 5.6 Removing/inserting the liquid container ..........32 5.7 Removing/inserting the suction filter ............33 5.8 Fit the machine with cleaning brushes or pads........35 6 Operation ......................
-
Page 4: General
Operating manual imop lite General This operating manual contains all the important information for installing, commissioning and operating your imop lite. It will also provide you with information and important advice regarding your safety and help with problems. The product: imop lite This product was manufactured in accordance with the applicable national standards and guidelines, and serves to clean hard surfaces which are neither sensitive to moisture or polishing. -
Page 5: Delivery
Operating manual imop lite The following points will be considered improper operation: • Use on unsuitable types of flooring • Use of unsuitable cleaning agents • Use of the wrong polishing pads • Outdoor use • Operation by unauthorized persons •... -
Page 6: Safety Instructions
Operating manual imop lite Safety instructions The following basic safety instructions must be observed every time you use the imop lite. Please carefully read through the following safety instructions and information regarding the safe operation of the imop. Please familiarize yourself with all the functions of the imop lite. -
Page 7: Hazard Statements
Operating manual imop lite 2.1.2 Hazard statements Warning Risk of injury or death by electrocution! The imop lite machine uses a current of 110–240 V AC at the power adapter input. Given that electric shocks of as low as 50/60 mA can be deadly, appropriate precautions must be taken. -
Page 8: Safety Instructions For The Operator
Operating manual imop lite Risk of injury and/or property damage being caused by Caution irregularities in relation to the machine! Leakages in the machine Discharge of foam or liquid Follow the instructions regarding the intended Measures operation. Turn the machine off immediately. Safety instructions for the operator 2.2.1 Occupational safety... -
Page 9: Specific Components
Operating manual imop lite Specific components 2.4.1 Safety and warning labels Parts of the machine which pose an electrical hazard are identified using the warning symbol below. The liquid containers (for fresh water and waste water), as well as the waste water hose connection of the imop lite are attached to the machine using strong magnets. - Page 10 Operating manual imop lite • Do not use the battery when it is dirty or wet. • Do not use the battery in environment where there is an explosion hazard. • Keep the battery away from heat, sharp edges, oil, and moving parts. •...
-
Page 11: Specific Life Cycles Of The Imop Lite
Operating manual imop lite Specific life cycles of the imop lite 2.6.1 Transport Risk of injury or damage! • Take the weight of the imop lite into account when transporting it. • When transporting the imop lite and the power adapter in vehicles, secure it in accordance with the applicable guidelines to protect against slipping and tipping. -
Page 12: Commissioning
Operating manual imop lite Figure 2: Moving the imop lite using the transport castors 2.6.2 Commissioning The initial commissioning of the imop lite is generally carried out by our authorized dealers. 2.6.3 Operation Cleaning with the imop lite can be completed within around 45 min., depending on the flooring. -
Page 13: Safety Instructions Applicable To Consumables
Operating manual imop lite Safety instructions applicable to consumables 2.7.1 Cleaning agent The recommended cleaning agent. Do not use any cleaning solution with a pH value of under three or above 11, to prevent damage to sensitive components such as hoses and valves. •... - Page 14 Operating manual imop lite • The battery must always be kept clean and dry to prevent leakage currents. Protect the battery from contamination, e.g. using metallic powder. Cleaning: • The battery may only be cleaned using a damp cloth. Do not clean it using a hose or steam jet! Transport and storage: •...
-
Page 15: Description Of The Imop Lite Machine
Operating manual imop lite Description of the imop lite machine This section defines the working position for when using the machine as well as providing an overview of the controls. Defined working and user positions This contains a description of the working position which must be adopted when using the machine. -
Page 16: Description Of The Defined User Positions
Operating manual imop lite 3.1.2 Description of the defined user positions The following description contains a description of the user positions which must be adopted when using the machine. Description of the defined user positions: Operation… Authorized activities Setting the brushing program …... - Page 17 Operating manual imop lite Figure 5: Handlebar grip with lever Figure 6: Drive and suction unit 1.01 – 2019 D...
- Page 18 Operating manual imop lite Figure 7: Liquid container (fresh water, waste water), suction filter 1.01 – 2019 D...
- Page 19 Operating manual imop lite Figure 8: Power adapter Figure 9: Battery with charge level indicator Description of assemblies: Position Authorized activities Figure 4 Shaft including Contains the components for turning on, starting operating unit up and stopping, setting operating modes Figure 5 Handlebar grip with Pressing the lever to start or stop the preset...
-
Page 20: Operating Unit
Operating manual imop lite Position Authorized activities Figure 6 Drive and suction unit Attaching and detaching the suction line, cleaning brushes or pads Figure 7.1 Liquid container – Attaching and detaching the container, filling fresh water and emptying the container Figure 7.2 Liquid container –... -
Page 21: Lever
Operating manual imop lite Description of operating unit/operating modes: Position Description Function Figure brush Turning the brush function on and off 10.1 Figure turbine Turning the suction function on and off 10.2 Figure water Turning the cleaning fluid on and off 10.3 Figure Turning the cleaning fluid on and off (this is... -
Page 22: Connections
Operating manual imop lite 3.2.4 Connections The power adapter connected to the 230 V AC mains supply via a connection cable with a euro plug. Danger Risk of death by electrocution! Only use the power adapter for charging the battery! Please also observe the safety instructions (see Section 2 “Safety instructions”). - Page 23 Operating manual imop lite Figure 13: Charging connector on the battery The power adapter is connected to the lower side of handle of the battery. Description of connections: Position Description Function Figure 12 Mains connection and Providing the mains power supply to the power charging plug of the adapter to be connected to the battery via the power adapter...
-
Page 24: Preparation
Operating manual imop lite Preparation Unpacking the machine The technical data are summarized in the data sheet. Risk of injury by tipping the machine! Warning The machine can tip over if put in an inclined position! There are no particular requirements for unpacking, (temporary) storage in the transport packaging does not pose any problems either. -
Page 25: Commissioning
Operating manual imop lite Commissioning Before turning the machine on Before beginning work, sufficiently familiarize yourself with the following: • the controls • how it is equipped • how it functions • the immediate environment • the safety devices Putting the machine into the parking position The machine should be put into the parking position or stopped in the parking position when performing preparatory measures or maintenance, as well as when not in use. - Page 26 Operating manual imop lite Figure 14: Putting the machine into the parking position 1.01 – 2019 D...
-
Page 27: Charging The Machine's Battery
Operating manual imop lite Charging the machine’s battery See also Section 4.2 “Connecting the power supply to the power ”. The battery can be charged when within the machine or removed from it. Only remove the battery after the machine has been stopped and turned off. Removing/inserting the battery: Step Activity... - Page 28 Operating manual imop lite Charging the battery and checking the charge level: Step Activity Explanation/illustration Opening the cap of the charging Figure 16 jack on the battery Connecting the power adapter to Figure 17 the battery Checking the charge level of The charge level of the battery is the battery displayed when you press the...
- Page 29 Operating manual imop lite Figure 17: Connecting the power adapter to the battery Figure 18: Checking the charge level of the battery 1.01 – 2019 D...
-
Page 30: Turning The Machine On
Operating manual imop lite Turning the machine on Please observe the safety instructions! Warning You may only switch the machine on after observing the aforementioned instructions. Please also observe the safety instructions (see Section 2 “Safety instructions”). Preparing for start up •... -
Page 31: Removing/Inserting The Liquid Container
Operating manual imop lite Step Activity Explanation/illustration Turn the machine off This is done by choosing the operating mode Removing/inserting the liquid container The liquid container may only be removed after the machine has been stopped. Both of the liquid containers are removed and inserted in a corresponding way. Do not tilt the container too much when removing it as this Important may damage the tank inlet. -
Page 32: Removing/Inserting The Suction Filter
Operating manual imop lite Figure 19: Removing the liquid container Removing/inserting the suction filter The suction filter may only be removed after you have removed the waste water container. Only remove the waste water holder after you have stopped the machine. Removing/inserting the suction filter: Step Activity... - Page 33 Operating manual imop lite Inserting the suction filter Inserting the suction filter into the rubber holder from below and tilting it up into the suction inlet socket. Figure 21 Inserting the waste water container Inserting the waste water by following these steps in reverse order.
-
Page 34: Fit The Machine With Cleaning Brushes Or Pads
Operating manual imop lite Figure 21: Inserting the suction filter Fit the machine with cleaning brushes or pads Fitting the cleaning brushes or pads after you have stopped the machine. When folding the removing or fitting the cleaning brushes Important or pads to the machine, always keep one hand up on the shaft to prevent it from falling over/tipping. - Page 35 Operating manual imop lite Step Activity Explanation/illustration Removing the existing cleaning Releasing the cleaning brushes or brushes pads from the locking mechanism by gently turning them clockwise and then removing them by lifting them from the mounting. Figure 23 Fitting the cleaning brushes or pads The fitting is done by following these steps in reverse order.
- Page 36 Operating manual imop lite Figure 23: Removing cleaning brushes 1.01 – 2019 D...
-
Page 37: Operation
Operating manual imop lite Operation In this section, you will learn • which tasks must be carried out prior to the beginning of work and after work has been finished, • how the machine and its various functions are operated. Prior to the beginning of work The following tasks must be performed on the machine prior to the beginning of work. -
Page 38: Turn The Machine Off
Operating manual imop lite Turn the machine off See Section 5.5 “Stopping and turning off the machine” After finishing work When folding the removing or fitting the cleaning brushes Important or pads to the machine, always keep one hand up on the shaft to prevent it from falling over/tipping. -
Page 39: "Error Conditions
Operating manual imop lite “Error conditions” This section contains information about possible malfunctions and fixing them as well as support regarding malfunctions or errors. Warning Please observe the safety instructions! In the event of a fault, turn the machine of immediately (see section 5.5 “Stopping and turning off the machine”) and protect it against being turned on accidentally. - Page 40 Operating manual imop lite Error/fault Cause Remedy/measure The battery is either discharged Charging the battery or Machine has stopped or not properly latched latching it correctly and will no longer start up again The waste water tank is not Inserting the waste water Insufficient suction correctly inserted into the tank in the machine...
-
Page 41: Maintenance
Operating manual imop lite Maintenance This Section contains only the most important instructions regarding the maintenance of the machine. Maintenance instructions for your safety This contains general information on the things you must bear in mind during all maintenance and servicing work. Servicing work may only be carried out by trained staff Important when disconnected from the power source. -
Page 42: Maintenance Of The Machine
Operating manual imop lite Always replace self-locking screws and nuts unsuitable spare parts Use spare parts that are contained in the spare parts list only Do not approve the machine for use without unauthorized/premature functioning safety devices approval of the equipment Maintenance of the machine This contains find general information regarding which the maintenance work must be performed on the machine at appropriate intervals. - Page 43 Operating manual imop lite Step Activity Explanation/illustration Cleaning the rest of the machine Only clean the machine with a damp cloth! Never clean it with a water jet! Reassembling it by following these steps in reverse order 1.01 – 2019 D...
- Page 44 Operating manual imop lite 1.01 – 2019 D...
-
Page 45: Dismantling/Assembling The Squeegee
Operating manual imop lite Figure 24: Removing the suction hose waste water 8.2.2 Dismantling/assembling the squeegee Step Activity Explanation/illustration Stopping and turning off the machine See Section 5.5 “Stopping and turning off the machine” See Section 5.2 “Putting the Putting the machine into the parking position so you can reach the machine into the parking position”... - Page 46 Operating manual imop lite 1.01 – 2019 D...
- Page 47 Operating manual imop lite Figure 25: Disassembling the squeegee 1.01 – 2019 D...
- Page 48 Operating manual imop lite Figure 26: Attaching the squeegee to the machine 1.01 – 2019 D...
-
Page 49: Repairs
Operating manual imop lite Repairs Before repair work is carried out by specialist personnel with the relevant qualifications, the following steps must be observed. General repair procedure: Step Activity Stopping and turning off the machine Putting the machine into the parking position Removing and emptying the liquid container Removing the battery from the machine Carrying out repair work... -
Page 50: Remedying Faults
Operating manual imop lite 10 Remedying faults Here you will learn what you have to bear in mind when remedying faults and where you can find the necessary information. When remedying faults, please observe the following points. Only remedy the fault if you also have the necessary qualifications (a skilled worker’s qualification in the area of mechanical or electrical engineering). -
Page 51: Shutting Down, Disposal
Operating manual imop lite 11 Shutting down, disposal 11.1 Shutting down and storage This contains information that you must observe if you have to decommission the machine for a long time and you want to recommission the machine after this period. When shutting down the machines please also observe the maintenance instructions (see Section 8 “Maintenance”). -
Page 52: Decommissioning
Operating manual imop lite 11.3 Decommissioning Please observe the following safety instructions. The safety instructions (see Section 2 “Safety instructions”) and instructions contained in the documentation of the supplier shall also be applicable! Dismounting the machine: Step Activity Stopping and turning off the machine Emptying the liquid container Removing the battery from the machine Detaching the machine from the cleaning brushes or pads... - Page 53 Operating manual imop lite Circuit boards Polyester Circuit boards Hazardous waste: Recyclable material Occurrence Power adapter Electronic waste Controls Circuit boards with electronic components Important Disposal Dispose of all of the parts of the machine in a way that prevents any health or environmental damage. 1.01 –...
-
Page 54: Technical Data
Operating manual imop lite 12 Technical data Mechanics: Size Value Length 1140 mm Width 435 mm Depth 280 mm Total weight 12.5 kg Speed 500 rpm Airborne noise emissions max. 68.5 dB(A) Electronics: Size Value Power adapter supply 230 V AC/50 Hz voltage Type of battery Li-ion... -
Page 55: Warranty
Operating manual imop lite 13 Warranty 13.1 Warranty period The statutory warranty period shall apply. 13.2 Processing the warranty claim Warranty claims are processed by the authorized specialist dealer. 13.3 Disclaimers of warranty Damages or faults that are caused by improper handling or operation, as well as defects resulting from the use of non-original parts or accessories are not covered by the warranty. - Page 56 Operating manual imop lite 1.01 – 2019 D...
-
Page 57: Index
Operating manual i-mop lite 14 Index Annex Lever Assemblies Machine (overview) 16, 17 Connections Mechanical data Decommissioning Operating unit Defined user positions Delivery Dismounting the machine Product information Disposal Recommissioning Electrical data Safety instructions Faults Shutting down Signal words Storage... -
Page 58: Declaration Of Conformity And Manufacturer
Operating manual imop lite 15 Declaration of conformity and manufacturer 1.01 – 2019 D...
