DIGI2/DIGI2p
a) Slide the cover down and unscrew screw.
b) Carefully take out the front face.
c) Fix the base to the wall and connect the device according the diagram below.
d) Replace the front cover and screw in screw again.
Telephone remote control (ELEKTRA DIGI2)
or floor temperature sensor (ELEKTRA DIGI2p)
Contact mode (between terminals 4 and 5) = anti-freezing (+6°C)
The type of contact should be adapted to low level connection
(e.g. gold-gilded contact).
28
