Pottery Barn 4ft smart speaker shelf Mounting Instructions

WARNING:
- Electrical shock hazard may cause death or serious injury.
- Do not operate Speaker using AC adapter near water. AC adapter is meant for Indoor Use Only. Always plug
adapter into Speaker before plugging into outlet.
- This power unit is intended to be correctly orientated in a vertical or floor mount position
- Excessive exposure to audio equipment at high volume may lead to hearing loss.
CAUTION:
To reduce the risk of electric shock and fire, do not open any section on the Speaker Shelf. There are
no user serviceable parts inside.
Note: This hanging system is meant for dry wall/stud mounting only. If walls are concrete, brick or plaster, please
consult your local hardware store for assistance. For safety and ease of mounting, installation is recommended
using two people.

Tools needed:

• Electronic stud Finder, #2 Phillips screwdriver, Drill with #2 Phillips bit, Pencil

Hardware Included:

(1) Wall Mounting Bracket with Bubble Level
(5) Stud Mounting Screws (1.5" screws with sharp tip)
(2) Toggle Anchors
(2) Toggle Screws
(The Toggle Anchors and Toggle Screws are meant for dry

Accessories Included:

(1) Stereo Cord – (A)
(1) AC Adapter – (B)
Mounting Instructions:
1. Determine the desired placement on the wall for the product. Within the desired mounting location,
locate the wall studs using the electronic stud finder and mark stud locations using the pencil. (Note:
It is best to mount the bracket to at least (1) stud, using the illustrative graph shown below for
reference.)
2. Determine which wall mount bracket hole or holes on the wall that will be centered on a stud. The
hole positions that are centered over studs will use the Stud Mounting Screws for mounting the
bracket.
3. Insert the included bubble level into the bubble level track, as close to the center of the wall mount
bracket as possible.
4. Place the wall mount bracket at the desired location on wall and confirm that the bracket is level.
5. With the pencil, mark the mounting screw hole locations on the wall with the pencil.
6. Remove the wall mount bracket and set aside.
4ft smart speaker shelf
mounting instructions
maximum weight capacity
Stud Mounting
1. Install the wall mount bracket onto the wall using the Stud Mounting
Screw at one of the stud locations first, using the #2 Phillips
screwdriver or the drill with a #2 Phillips bit. Insert the first Stud
Mounting Screw through the hole in the wall mount bracket and
tighten clockwise. Leave the Stud Mounting Screw slightly loose so
that the wall mount bracket can still be rotated and the wall mount
bracket area on the wall is exposed for installing the dry wall toggle
anchor(s).
(add after testing)
Stud Mounting Screw
Toggle Screw
wall only)
Toggle Anchor
