Pottery Barn HAYDEN PIVOT MIRROR Manual

This mounting hardware is meant for dry wall/stud mounting only. If walls are concrete, brick or plaster,
please consult your local hardware store for assistance. For safety and ease of mounting, assembly by
two people is recommended.

Hardware/Parts Included

(1) Mirror
(2) Wall brackets
(2) Mounting Plates
(2) Screws
(2) Wall anchors (for dry wall only)
(4) Hex screws (installed in the brackets)
(1) Allen wrench

Mounting Instructions:

A) With the help of another person, hold the mirror in a desired location and as level as possible so
that the two side wall brackets are flush against the wall. Holding this position, use a pencil to
mark on the wall the location of the brackets (just trace around each circular bracket). Set the
mirror aside.
B) Use a level to make sure that each traced circular mark on the wall is level with respect to each
other and adjust if necessary. Position a mounting plate against the wall, centering it within one
of the pencil-drawn circles (note that each mounting plate includes a hole and a pin - arrange the
bracket against the wall so that the hole is located above the pin and a vertical orientation. Mark
the wall through the hole of the mounting plate. Repeat this step with the other circle and
mounting plate. The resulting two marks are the insertion points for the mounting hardware.
C) The anchors provided with this product cannot penetrate wood (or wall studs). Therefore we
have to determine if either of the marks of Step (C) happens to align with a wall stud (use a stud
finder to determine this). If a mark does align, use a screwdriver and a provided screw to secure
that mounting plate directly to the wall at that location. Align the hole of the plate with the mark
on the wall and use the screwdriver to secure the screw directly into the wall until tight. Make
sure that the mounting plate remains vertically straight when the screw is fully tightened.
D) For marks that do not align with a wall stud, secure a provided anchor into the sheetrock at each
mark. To do this, place the tip of the anchor at one of the marks and then use the screwdriver to
rotate the anchor clockwise while pushing it into the wall. The anchor will drive itself into the wall
like a large screw. Continue rotating the anchor until the wide end becomes even with the wall.
Repeat this step with the other mark and anchor.
E) Hold a mounting plate against the wall so that its hole aligns with the installed anchor and then
use a screwdriver and provided screw to secure the plate to the wall. Repeat this step with the
other plate and anchor. Again, make sure that the mounting plate remains vertically straight
when the screws are fully tightened.
F) Prior to securing the mirror to the mounted wall plates, we recommend that you use the Allen
wrench to loosen the two set screws located on the wall brackets at the 6 o'clock position. Keep
that Allen wrench handy. Now, with the help of another person, hold the mirror in place so that
the mounting brackets fit onto the wall-mounted mounting plates. While holding this position, use
HAYDEN PIVOT MIRROR

Tools Required for Mounting

Level
Stud finder
Pencil
Phillips Screwdriver (#2 size)
