- Page 1 L8542771 ITA/ENG/FRA/ESP 09/2013 rev 5 BULLOCK 424 BULLOCK 424 UNIONE NAZIONALE COSTRUTTORI AUTOMATISMI PER CANCELLI, PORTE SERRANDE ED AFFINI...
- Page 2 It is hereby stated that the product automatic system 24Vdc for sliding gates BULLOCK 424. is compliant with provisions set forth in the following EC Directives: - DIRECTIVE 2004/108/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 15 December 2004, on the harmonisa- tion of the laws of Member States relating to electromagnetic compatibility and which cancels Directive 89/336/EEC, according to the following harmonised regulations: EN 61000-6-2:2005, EN 61000-6-3:2007.
-
Page 3: Description Of The Automation
Description of the automation Key of components: Gear motor with incorporated control unit BULLOCK M4 rack, Nylon/Fe Limit switch brackets Photocells Mechanical stoppers Key selector or digital keyboard Flashing light Antenna Preliminary check It is indispensable to carry out several checks before •... -
Page 4: Technical Data
Control unit power supply 230 Vac (Bullock 424) of use can reduce the values indicated. 115 Vac (Bullock 424 115) In no case can the installation of BULLOCK be 50/60 Hz considered a solution for opening inefficient... - Page 5 Laying the foundation plate - Measurements It is also indispensable that the rack projects, with respect to The positioning of the plate must respect the distances indi- the centre of the plate, by at least the measurements indicated cated in figures 2a/b/c/d (seen from above): in figure 3a (motor on left) and 3b (motor on right) to allow po- - Fig.
- Page 6 Laying the foundation plate - Cement foundation If there is no cement flooring (or similar material) a cement* foundation must be prepared. Proceed as follows: 1 - Dig a suitable hole (minimum 40x30cm, at last 35cm deep), Fig. 7 considering the measurements indicated in the previous para- graph.
- Page 7 Laying the foundation plate - Fixing to the floor If the floor is in cement (or similar material) it is possible to fix Fig. 11 the plate directly to the ground: 1 - Obtain suitable fixing systems, normally on the market, steel pressure plugs (figure 11 -ref A) or anchorage with expansion straps (figure 1 -ref B) to be inserted using a mallet.
- Page 8 Fixing the rack Fig. 16 The rack, appropriately fixed to the leaf, transforms the rotary movement of the gear into the linear movement of the leaf. Before fixing the rack, it is necessary to release the gear motor, proceed as follows: 1) Turn the circular cover by 180°, in a way to view the trian- gular pin.
- Page 9 Fixing the end run brackets 8 - When the best stop points have been established, remove Stopping the movement, in the opening phase and in the clos- the two screws, and use a drill (45 mm point), to make the holes ing phase, takes place via the end run brackets FRD.1, which, with depth of about 2 mm in correspondence with the signs left relevantly fixed onto the rack, make the end run spring, present...
-
Page 10: Maintenance
1 - Turn the circular cover by 180°, in a way to view the trian- It is advised to contact a BENINCA' specialised technician or a gular pin. specialised company that is enabled for this purpose. - Page 11 Parti di ricambio - Spare parts - Lista de recambios Code Note 9688164 9688165 9686414 9688166 9686622 Bullock 424 9688142 Bullock 424 115 9686623 9686624 9688169 9686626 9688170 Bullock 424 9688143 Bullock 424 115 9686488 9688174...
- Page 12 AUTOMATISMI BENINCÀ SpA - Via Capitello, 45 - 36066 Sandrigo (VI) - Tel. 0444 751030 r.a. - Fax 0444 759728...
