KTI-63505A
1000 LB. TWO STAGE TELESCOPIC TRANSMISSION JACK
OWNER'S MANUAL
KTI-63505A
WARNING:
Cancer and Reproductive Harm-
www.P65Warnings.ca.gov

SPECIFICATIONS

Capacity ..........................................................................1000 Lbs.
Low Height ................................................................................37"
High Height ............................................................................76-2/5"
Saddle Tilt Forward ....................................................................10˚
Saddle Tilt Backward .................................................................27˚
Saddle Left Tilt ...........................................................................29˚
Saddle Right Tilt .........................................................................45˚
Shipping Weight .............................................................158.9 Lbs.
Complies with ASME PASE/2014 Safety Standard

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KTI-63505A and is the answer not in the manual?

Questions and answers

Summary of Contents for K Tool International KTI-63505A

  • Page 1 KTI-63505A 1000 LB. TWO STAGE TELESCOPIC TRANSMISSION JACK OWNER'S MANUAL WARNING: Cancer and Reproductive Harm- www.P65Warnings.ca.gov SPECIFICATIONS Capacity ................1000 Lbs. Low Height ................37" High Height ................76-2/5" Saddle Tilt Forward ..............10˚ Saddle Tilt Backward ..............27˚ Saddle Left Tilt ................29˚ Saddle Right Tilt .................45˚...
  • Page 2 Failure to read this manual completely and thoroughly, failure to understand its OPERATING INSTRUCTIONS, SAFETY WARNINGS, MAINTENANCE INSTRUCTIONS and comply with them, and failure to comply with the METHODS TO AVOID HAZARDOUS SITUATIONS could cause accidents resulting in serious or fatal personal injury and/or property damage. KTI-63505A...
  • Page 3 INSPECTION AND SETUP INSTRUCTIONS Visual inspection should be made before each use of the transmission jack, checking for leaking hydraulic and damaged, loose or missing parts. Each jack must be inspected by an authorized repair facility immediately if subjected to an abnormal load or shock.
  • Page 4 PROBLEM: UNIT WILL NOT LIFT RATED LOAD. ACTION: Purge air from hydraulic system by following procedure under INSPECTION AND SETUP PROBLEM: UNIT WILL NOT SUSTAIN RATED LOAD OR FEELS "SPONGY" UNDER RATED LOAD. ACTION: Purge air from hydraulic system as above. PROBLEM: UNIT WILL NOT LIFT TO FULL HEIGHT. ACTION: Purge air from hydraulic system as above. PROBLEM: UNIT STILL DOES NOT OPERATE. ACTION: Contact your place of purchase for details on handling warranty. KTI-63505A...
  • Page 5 K-Tool International’s option, without charge. This warranty does not apply to damage from accident, overload, misuse or abuse, nor does it apply to any equipment which has been altered or used with special attachments other than those recommended. Michigan KTI-63505A...
  • Page 6 KTI-63505A 1000 LB. TWO STAGE TELESCOPIC TRANSMISSION JACK PARTS BREAKDOWN KTI-63505A...
  • Page 7 KTI-63505A 1000 LB. TWO STAGE TELESCOPIC TRANSMISSION JACK PARTS BREAKDOWN REF. # PART # DESCRIPTION QTY. REF. # PART # DESCRIPTION QTY. Dust Cover Bolt O-Ring KTP63505A02 Finger Secondary Cylinder Head Plate O-Ring Washer Secondary Cylinder Plunger Circlip Hook Dust Cover...
