Installations- und
Bedienungsanleitung
(S. 3)
Installation and
operating manual
(p. 21)
Funk-Schließerkontaktschnittstelle
3 Eingänge, Unterputzmontage
Wireless Shutter Contact Interface
3-channel, flush-mount
HM-SCI-3-FM

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HM-SCI-3-FM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HomeMatic HM-SCI-3-FM

  • Page 1 Installations- und Bedienungsanleitung (S. 3) Installation and operating manual (p. 21) Funk-Schließerkontaktschnittstelle 3 Eingänge, Unterputzmontage Wireless Shutter Contact Interface 3-channel, flush-mount HM-SCI-3-FM...
  • Page 2 Dokumentation © 2010 eQ-3 AG, Deutschland Alle Rechte vorbehalten. Ohne schriftliche Zustimmung des Herausgebers darf dieses Handbuch auch nicht auszugsweise in irgendeiner Form reproduziert werden oder unter Verwendung elektronischer, mechanischer oder chemischer Verfahren vervielfältigt oder verarbei- tet werden. Es ist möglich, dass das vorliegende Handbuch noch drucktechnische Mängel oder Druckfehler aufweist.
  • Page 3: Table Of Contents

    Funktion ......5 Allgemeine Systeminformation zu Homematic. . 6 Allgemeine Hinweise zum Funkbetrieb ..7 Installation .
  • Page 4: Hinweise Zu Dieser Anleitung

    Hinweise zu dieser Anleitung Lesen Sie diese Anleitung sorgfältig, bevor Sie Ihre Homematic-Komponenten in Betrieb nehmen. Bewahren Sie die Anleitung zum späteren Nachschla- gen auf! Wenn Sie das Gerät anderen Personen zur Nutzung überlassen, übergeben Sie auch diese Bedienungsan- leitung.
  • Page 5: Funktion

    (Reed-Kontakte) oder Endschalter. Die Än- derung eines Schaltzustands wird nicht nur erkannt, sondern auch gespeichert und als Funkbefehl an ange- lernte Homematic Komponenten übertragen. Wenn ein Schalter/Kontakt offen ist, wird ein Einschalt- signal gesendet, ist ein Schalter/Kontakt geschlossen, wird ein Ausschaltsignal übertragen.
  • Page 6: Allgemeine Systeminformation Zu Homematic

    Allgemeine Systeminformation zu Homematic Dieses Gerät ist Teil des Homematic Haussteuersy- stems und arbeitet mit dem bidirektionalen Homematic Funkprotokoll. Alle Geräte werden mit einer Standardkonfiguration ausgeliefert. Darüber hinaus ist die Funktion des Ge- rätes über ein Programmiergerät und Software konfi- gurierbar.
  • Page 7: Allgemeine Hinweise Zum Funkbetrieb

    Umwelteinflüssen wie Luft- feuchtigkeit bauliche Gegebenheiten vor Ort eine wichtige Rolle. Hiermit erklärt die eQ-3 AG, dass sich dieses Gerät in Übereinstimmung mit den grundlegenden Anforderun- gen und den anderen relevanten Vorschriften der Richt- linie 1999/5/EG befindet. Die vollständige Konformitätserklärung finden Sie unter www.Homematic.com.
  • Page 8: Installation

    Installation Die Schließerkontaktschnittstelle besitzt flexible Verbin- dungsleitungen (0, 75 mm ) mit Aderendhülsen. Entfer- nen Sie vor dem Anschluss die Gummikappen, die auf die Aderendhülsen aufgesteckt sind. Damit sind diese direkt an die verwendeten Kontakte gemäß folgender Skizze anzuschließen: Falls Sie nicht alle Kanäle verwenden, belassen Sie die Gummikappen auf den Aderendhülsen der unbenutzten Kanäle.
  • Page 9: Inbetriebnahme

    Inbetriebnahme 7.1 Batterie einlegen und wechseln Entfernen Sie den Gehäusedeckel indem Sie vorsichtig die Rastnasen am Gehäusedeckel nach innen drücken (Pfeile).
  • Page 10 Legen Sie die mitgelieferte Lithium-Batterie (CR 2032) polrichtig entsprechend den Polaritätsmarkierungen in den Batteriehalter (E) ein (Pluspol nach oben). Setzen Sie den Gehäusedeckel wieder auf. Achten Sie darauf, dass der Gehäusedeckel vollständig wieder einrastet. Vorsicht! Explosionsgefahr unsachge- mäßem Austausch der Batterie. Die eingesetzte Lithium-Knopfzelle muss kurz- schlussfest sein! Verbrauchte Batterien gehören nicht in...
  • Page 11: Anlernen

    7.2 Anlernen Bitte lesen Sie diesen Abschnitt erst vollständig, bevor sie mit dem Anlernen beginnen! Zum Anlernen müssen beide zu verknüpfenden Geräte in den Anlernmodus gebracht werden. Die Anlerntaste (A) befindet sich neben den Abgängen der Anschlussleitungen (B). Um die Schließerkontaktschnittstelle in den Anlernmo- dus zu bringen, drücken Sie die Anlerntaste (A) kurz. Danach befindet sich die Schließerkontaktschnittstelle für 20 Sekunden im Konfigurationsmodus, angezeigt...
  • Page 12 Geräte-LED leuchtet dann rot auf. Nach Auswahl des Kanals bleibt der Anlernmodus für 20 Sekunden aktiv. Innerhalb dieser Zeit muss die an- dere anzulernende Homematic Komponente ebenfalls in den Anlernmodus versetzt werden. Lesen Sie dazu die entsprechende Bedienungsanleitung des Geräts.
  • Page 13: Konfigurationsmodus (Auch Mit Zentrale/Konfigurationsadapter)

    den, aber der Anlernmodus wird nicht aktiviert. Nach Betätigen eines angeschlossenen Schalters/Kontakts leuchtet die Geräte-LED als Fehler meldung lediglich für 2 Sekunden rot auf. Es ist kein direktes Anlernen mehr möglich. 7.3 Konfigurationsmodus (mit Zentrale/Konfigurationsadapter) Weitergehende Konfigurationsmöglichkeiten ergeben sich im Zusammenspiel mit einer Zentrale oder einem Konfigurationsadapter. Um die Konfiguration über eine dieser Komponenten einzuleiten, muss die Schließer- kontaktschnittstelle manuell über einen kurzen Tasten-...
  • Page 14 Rückmeldungen der Geräte-LED im Konfigurationsmo- dus: Gerät ist im Grünes Blinken Konfigurationsmodus Gerät ist im Anlernmodus Oranges Blinken (für Kanal S1, S2 oder S3) Mind. 2s grüne LED Anlernen erfolgreich 2s rote LED Anlernen fehlgeschlagen Gerät im Konfigurations- Gerät bereits an Zentrale modus und bei angelernt und damit gegen Schalterbetätigung direktes Anlernen gesperrt...
  • Page 15: Einfache Bedienfunktionen

    Aktoren wie folgend beschrieben schalten: Schalter/Kontakt offen - Aktor EIN Schalter/Kontakt geschlossen - Aktor AUS. Auch Wechselschaltungen können mit der Schließer- kontaktschnittstelle realisiert werden. Über eine Homematic Zentrale oder einen Homematic Konfigurationsadapter lässt sich die Konfiguration der Schließerkontaktschnittstelle ändern. Lesen Sie dazu auch Abschnitt 7.3. Zurücksetzen in den Auslieferungszustand Halten Sie die Anlerntaste für mindestens 5 Sekunden...
  • Page 16 Beginnt die LED nach 5 Sekunden Drücken der Anlern- taste nicht zu blinken, sondern leuchtet dauerhaft auf, kann das Gerät nicht zurückgesetzt werden. In diesem Fall wurde über eine Homematic Zentrale ein eigener Verschlüsselungscode hinterlegt. Um das Gerät zu- rückzusetzen, müssen Sie die Konfigurationssoftware...
  • Page 17: Fehlerbehebung

    10. Fehlerbehebung Erfolgt beim Betätigen eines Schalters/Kontakts keine Reaktion des zu steuernden Gerätes und liegt keine behebbare Kommunikationsstörung vor (zu steuerndes Gerät vom Netz getrennt, leere Batterien des Empfän- gers, usw.) so ist die verbrauchte Batterie wie im Kapi- tel 7.1 beschrieben gegen eine neue Lithium-Zelle des Typs CR 2032 auszutauschen.
  • Page 18: Technische Daten

    11 Technische Daten Funkfrequenz: 868,3 MHz Typ. Funk-Freifeldreichweite: 200 m Stromversorgung: 1x Lithium-Knopfzelle CR 2032 Batterielebensdauer: bis zu 3 Jahre (bei 6 Betätigungen/Tag) Schutzart: IP 20 Gehäuse: Gehäusefarbe: Schwarz Abmessungen: 50 x 10 mm (ø x H) Gewicht: 30 g (ohne Batterie) Technische Änderungen vorbehalten.
  • Page 19 Entsorgungshinweis: Gerät nicht im Hausmüll entsorgen! Elektro- nische Geräte sind entsprechend der Richtlinie über Elektro- und Elektronik-Altgeräte über die örtlichen Sammelstellen für Elektronik-Altgeräte zu entsorgen. Das CE-Zeichen ist ein Freiverkehrszeichen, das sich ausschließlich an die Behörden wen- det und keine Zusicherung von Eigenschaften beinhaltet.
  • Page 20 Documentation © 2010 eQ-3 AG, Germany All rights reserved. This manual may not be reproduced in any format, either in whole or in part, nor may it be duplicated or edited by electronic, mechanical or chemical means, without the written con- sent of the publisher.
  • Page 21 Function ......23 General information about the Homematic system ..... 24 General information about radio operation..25 Installation .
  • Page 22: Information About This Manual

    Information about this manual Read this manual carefully before starting to use your Homematic components. Keep the manual handy so you can refer to it at a later date. If you hand over the device to other persons for use, please hand over the operating manual as well.
  • Page 23: Function

    A change in a switching state is not only detect- ed, but is also stored and transmitted to taught-in Homematic components in the form of a radio command. If a switch/contact is open, a switch-on sig- nal is sent, and if a switch/contact is closed, a switch-off signal is transmitted.
  • Page 24: General Information About The Homematic System

    General information about the Homematic system This device is part of the Homematic home control sys- tem and works with the bidirectional Homematic wire- less protocol. All devices are delivered in a standard configuration. The functionality of the device can also be configured with a programming device and software. The addition-...
  • Page 25: General Information About Radio Operation

    AG hereby declares that this device con- forms with the essential requirements and oth- er relevant regulations of Directive 1999/5/EC. The full declaration of conformity is provided at www.Homematic.com.
  • Page 26: Installation

    Installation The shutter contact interface features flexible connect- ing cables (0.75 mm ) with ferrules. Remove the rubber caps from the ferrules prior to connection. These must then be connected to the appropriate con- tacts directly, as per the diagram below: If you are not using all the channels, leave the rubber caps on the ferrules of those that remain unused.
  • Page 27: Start-Up

    Start-up 7.1 Inserting and replacing the battery Remove the housing cover by carefully pressing the clips on the housing cover inwards (in the direction indi- cated by the arrows).
  • Page 28 Insert the lithium battery (CR2032) supplied into the battery holder (E), observing the correct polarity (posi- tive pole at the top). Replace the housing cover. Make sure that the housing cover re-engages properly. Caution! There is a risk of explosion if the bat- tery is not replaced correctly.
  • Page 29: Teaching-In

    7.2 Teaching-in Please read this entire section before starting the teach-in procedure. To execute the teach-in procedure, both of the devices to be connected must be in teach-in mode. The teach-in button (A) is located next to the outgoing sections of the connecting cables (B). To switch the shutter contact interface to teach-in mode, briefly press the teach-in button (A). The shut- ter contact interface will then enter configuration...
  • Page 30 Once the channel has been selected, teach-in mode will remain active for 20 seconds. The other Homematic components to be taught-in must also be switched to teach-in mode during this time. For more information on this, refer to the operating manual for the device. The device LED lights up green to indicate that teaching-in has been successful.
  • Page 31: Configuration Mode

    switch/contact is pressed, the device LED simply lights up red for 2 seconds to indicate an error. Direct teach-in is no longer possible. 7.3 Configuration mode (with central control unit/configuration tool) Using a central control unit or configuration tool opens up additional configuration options. To initiate configura- tion using one of these components, the shutter contact interface must be manually switched to configuration mode by briefly pressing the teach-in button (A). The device LED flashes green to indicate that configuration...
  • Page 32 Device LED feedback in configuration mode: Device is in Flashing green configuration mode Device is in teach-in mode Flashing orange (for channel S1, S2 or S3) Green LED lighting Teach-in successful up for at least 2 s Red LED lighting Teach-in failed up for 2 s Device in configu- Device has already been ration mode and...
  • Page 33: Simple Operator Functions

    Switch/contact closed – actuator OFF The shutter contact interface also enables two-way switching to be performed. A Homematic central control unit or Home- matic configuration tool can be used to change the configuration of the shutter contact interface. See also Section 7.3 for more informa- tion on this.
  • Page 34: Remedy

    If the LED does not start to flash after the but- ton has been held down for 5 seconds, but lights up continuously instead, the device cannot be reset. In this case, a specific encryption key has been stored using a Homematic central control unit. To reset the device, you will have to use the configuration software for resetting the central control unit. 10. Remedy...
  • Page 35: Technical Specifications

    nected from the mains, receiver batteries are flat, etc.), follow the instructions described in Section 7.1 to re- place the old battery with a new lithium CR2032 cell. You must observe the correct battery polarity. After replacing a battery, check whether all of the func- tions are available again. 11 Technical specifications Radio frequency: 868.3 MHz...
  • Page 36 Instructions for disposal: Do not dispose of the device with regular do- mestic waste. Electronic devices must be dis- posed of in accordance with the Waste Elec- trical and Electronic Equipment Directive via local disposal points for electronic waste. The CE sign is a free trade sign addressed exclusively to the authorities and does not war- rant any properties.
