Summary of Contents for Lighting Technologies ARCTIC STANDARD 1200 TH 4000K

  • Page 1 ARCTIC STANDARD MANUAL BETRIEBSANLEITUNG...
  • Page 2: Delivery Set

    MANUAL ARCTIC STANDARD Size, mm, Luminous Mounting Power, W Luminous CCT, K (Length x Width x Name flux, lm, dimension (D), ±5% efficiency lm/W Height ±10% A x B x C) ARCTIC STANDARD 1200 TH 3300 4000 1280 x 96 x 110 4000K /E/ ARCTIC STANDARD 1500 TH 4500...
  • Page 3  Never work on the luminaire when the voltage is switched on.  Do not operate the luminaire without protective grounding.  Position the luminaire to avoid long viewing into the luminaire at a distance of less than 0.5 m. ...
  • Page 4 Bearing surface installation. Drill the mounting holes in the ceiling and luminaire’s body, L – distance between holes: (on fig. а – rubber washer; b - М6 steel washer). 3.1 Suspended installation. Drill installation holes in luminaire's body, L – distance between holes: (on fig.
  • Page 5: Connection Schemes

    Connect mains cable to terminal block on assembly panel according to polarity shown. 5.1 Connect the power supply wires to terminals L1, N1 of the terminal block in accordance with the specified polarity. When the luminaire with emergency unit is connected to mains for the first time it is recommended to wait for battery fully charges (24 hours).
  • Page 6: Warranty

    WARRANTY The manufacturer shall repair or replace a luminaire that has been found to be defective under normal use through no fault of the customer provided that it was delivered, stocked, mounted/installed and operated in conditions and according to the requirements specified in a product data sheet, engineering specifications, mounting and service instructions, delivery terms, rules for technical maintenance of electrical installations and other conditions agreed by the manufacturer and the customer during the warranty period or expanded warranty period specified below.
  • Page 7 BETRIEBSANLEITUNG ARCTIC STANDARD Größe, mm, Strom- Lichtstro Montage Lichtausbeute CCT, K (Länge x Breite x Leuchtenbezeichnung leistung, m, lm, Dimensionen lm/W Höhe W ±5% ±10% (D), mm A x B x C) ARCTIC STANDARD 1200 TH 3300 4000 1280 x 96 x 110 4000K /E/ ARCTIC STANDARD 1500 TH 4500...
  • Page 8: Installation Und Inbetriebnahme

    SICHERHEITSHINWEISE Diese Anleitung geht von einer Montage durch einen zertifizierten Elektriker aus.   Niemals die Leuchte unter Spannungseinfluß während der Montage installieren. Die Leuchte nicht ohne Schutzerdung in Betrieb nehmen.   Positionieren Sie die Leuchte so, dass sich langes Betrachten in die Lichtquelle durch eine Distanz mit weniger als 0.5m vermeiden lässt.
  • Page 9 Oberflächenmontage. Bohren Sie die Montagelöcher in die Decke und durch das Leuchtengehäuse, L – Abstand zwischen den Öffnungen: (in Abbldg. а – Gummi Dichtungsring; b - М6 Stahl Dichtungsring). 3.1 Pendelmontage. Bohren Sie Montagelöcher in das Leuchtengehäuse, L – Abstand zwischen den Öffnungen: (in Abbldg.
  • Page 10 Führen Sie das Stromkabel durch die Kabelverschraubung, welche etwas kleiner sein sollte. Platzieren Sie die Kabelverschraubung in den dazugehörigen Öffnungen des Leuchtengehäuses. Verbinden Sie das Stromkabel mit dem Terminal Block auf der Montagepanele gemäß der angezeigten Polarität. 5.1 Verbinden Sie den Stromanschluss mit Terminals L1, N1 des Terminal Blocks gemäß der angegebenen Polarität.
  • Page 11: Garantie

    DIMENSIONEN (IN MILLIMETER) GARANTIE Der Hersteller muss eine Leuchte reparieren oder ersetzen, die bei normalem Gebrauch ohne Verschulden des Kunden als defekt befunden wurde, vorausgesetzt, dass es geliefert, gelagert, montiert / installiert und betrieben wurde unter Bedingungen und gemäß den Anforderungen, die in einem Produktdatenblatt, technischen Spezifikationen, Montage- und Serviceanleitungen, Lieferbedingungen, Regeln für die technische Wartung von elektrischen Installationen und anderen Bedingungen festgelegt durch den Hersteller und der Kunde während der unten angegebenen...
  • Page 12 Der Hersteller behält sich das Recht vor, Änderungen an dem Produkt, welches die Endnutzer-Leistung verbessert, vorzunehmen. Darüber hinaus übernimmt der Hersteller keine Haftung für Irrtümer und Druckfehler. ÜBERNAHME ZERTIFIKAT Das Produkt entspricht TOR 3461-001-44919750-12 und wurde als funktionstüchtig erklärt. Die Leuchte ist zertifiziert.
