TOWER UNIT SHELVES ONLY
(450 & 600mm wide)
Assembly Instructions
CONTENTS:
A
1x Top panel
B
1x Side panel (left)
C
1x Side panel (right)
D
5x Shelves
E
1x Plinth panel
RECOMMENDED:
• TOOLS:
Screwdriver
• TWO PERSON BUILD
Page 1 of 4
22x
22x
2x
Cams
Dowels
Wall mounting
brackets
We recommend you use the Wall Mounting
Brackets provided to fix the Tower Unit to a
wall (where possible). This will prevent the unit
being pulled over. Use suitable wall fixings.
https://www.spaceslide.co.uk/diy-installation-and-information
4
18x
Wooden
dowels
Call: 0800 9803499
V2
SS_INSTRUC_TU_DR_08.2018
Advertisement
Related Manuals for spaceslide TOWER UNIT SHELVES ONLY 450mm
Summary of Contents for spaceslide TOWER UNIT SHELVES ONLY 450mm
- Page 1 • TOOLS: Screwdriver Brackets provided to fix the Tower Unit to a • TWO PERSON BUILD wall (where possible). This will prevent the unit being pulled over. Use suitable wall fixings. Page 1 of 4 SS_INSTRUC_TU_DR_08.2018 https://www.spaceslide.co.uk/diy-installation-and-information Call: 0800 9803499...
- Page 2 Note: B panel shown Lay panels (B&C) on a flat surface. Fit cams & dowels to both panels. Apply to all shelves. Page 2 of 4 SS_INSTRUC_TU_DR_08.2018 https://www.spaceslide.co.uk/diy-installation-and-information Call: 0800 9803499...
- Page 3 Attached shelves (D) onto side panel (C). Ensure cams are facing inwards. Page 3 of 4 SS_INSTRUC_TU_DR_08.2018 https://www.spaceslide.co.uk/diy-installation-and-information Call: 0800 9803499...
- Page 4 Use suitable fixings. Fix the wall mounting bracket to both sides of the Tower Unit. 10 9 Use two people to stand up straight. (Use suitable fixings when attaching to the wall). Page 4 of 4 SS_INSTRUC_TU_DR_08.2018 https://www.spaceslide.co.uk/diy-installation-and-information Call: 0800 9803499...
