TOWER UNIT 3 & 4 DRAWERS
(400 & 600mm wide)
Assembly Instructions
Drawer sides (left)
CONTENTS:
I
1x Top panel
A
3 Drawer Unit
• 3x left
1x Side panel (left)
B
4 Drawer Unit
1x Side panel (right)
C
• 4x left
5x Shelves
D
Drawer sides (right)
J
(4x for 4 drawers)
3 Drawer Unit
• 3x
1x Plinth panel
E
4 Drawer Unit
Soft close drawer runners
F
• 4x
3 Drawer Unit
• 3x left, 3x right
Drawer bases
K
4 Drawer Unit
3 Drawer Unit
• 4x left, 4x right
• x3
4 Drawer Unit
Soft close clips
G
• x4
3 Drawer Unit
• 3x left, 3x right
Drawer fronts
L
4 Drawer Unit
3 Drawer Unit
• 4x left, 4x right
• x3
4 Drawer Unit
Drawer backs
H
• x4
3 Drawer Unit
• x3
Drawer handles
M
4 Drawer Unit
3 Drawer Unit
• x4
• x3
4 Drawer Unit
• x4
RECOMMENDED:
• TOOLS:
Screwdriver
• TWO PERSON BUILD
Page 1 of 6
TOWER UNIT PACK
28x
28x
2x
Cams
Dowels
Wall mounting
brackets
DRAWER PACK
12x
12x 12mm
12x 35mm
Euro Screws
Wood Screw
Wood Screws
(16x for
(16x for
(16x for
4 drawers)
4 drawers)
4 drawers)
6x 7mm
6x Handle
12x Cams
Wood Screws
Screws (8x for
(16x for
(8x for 4 drawers)
4 drawers)
4 drawers)
12x Push Dowels
(16x for 4 drawers)
We recommend you use the Wall
Mounting Brackets provided to fix the
Tower Unit to a wall (where possible).
This will prevent the unit being pulled
over. Use suitable fixings.
https://www.spaceslide.co.uk/diy-installation-and-information
Call: 0800 9803499
V1
SS_INSTRUC_TU_DR_05.2016
Advertisement
Related Manuals for spaceslide Tower Unit
Summary of Contents for spaceslide Tower Unit
- Page 1 We recommend you use the Wall • TOOLS: Screwdriver Mounting Brackets provided to fix the • TWO PERSON BUILD Tower Unit to a wall (where possible). This will prevent the unit being pulled over. Use suitable fixings. Page 1 of 6 SS_INSTRUC_TU_DR_05.2016 https://www.spaceslide.co.uk/diy-installation-and-information...
- Page 2 PLEASE NOTE THE 3 AND 4 DRAWER TOWER UNIT ARE THE SAME IN CONSTRUCTION. WE HAVE USED THE 3 DRAWER TOWER UNIT AS AN EXAMPLE. Note: B panel shown Lay panels (B &C) on a flat surface. Fit cams & dowels to both panels.
- Page 3 PLEASE NOTE THE 3 AND 4 DRAWER TOWER UNIT ARE THE SAME IN CONSTRUCTION. WE HAVE USED THE 3 DRAWER TOWER UNIT AS AN EXAMPLE. Ensure cams are facing inwards. Page 3 of 6 SS_INSTRUC_TU_DR_05.2016 https://www.spaceslide.co.uk/diy-installation-and-information Call: 0800 9803499...
- Page 4 PLEASE NOTE THE 3 AND 4 DRAWER TOWER UNIT ARE THE SAME IN CONSTRUCTION. WE HAVE USED THE 3 DRAWER TOWER UNIT AS AN EXAMPLE. MAKING THE DRAWERS (Repeat on all drawer sides). (Repeat on all drawer fronts). Drawer side...
- Page 5 PLEASE NOTE THE 3 AND 4 DRAWER TOWER UNIT ARE THE SAME IN CONSTRUCTION. WE HAVE USED THE 3 DRAWER TOWER UNIT AS AN EXAMPLE. Screw soft close clip into place. (Repeat on all drawers). (Repeat on all drawers). Drawer shown from underneath. (Repeat on all drawers).
- Page 6 PLEASE NOTE THE 3 AND 4 DRAWER TOWER UNIT ARE THE SAME IN CONSTRUCTION. WE HAVE USED THE 3 DRAWER TOWER UNIT AS AN EXAMPLE. USE SUITABLE WALL FIXINGS WALL MOUNTING BRACKETS We recommend you use the Wall Mounting Brackets provided to fix the Tower Unit to a wall (where possible).
- Page 7 HOW TO FIT TOWER UNIT Assembly Instructions TOOLS REQUIRED: Place your tower unit into position (This can be left, centre Cutting around skirting boards (optional). Mark using a compass or right aligned). then cut using a coping saw. Please check your opening for any hidden electrical wires and water pipes before / screwing.
- Page 8 225mm Fix first bracket through both holes. Mark the position of the hanger bar. By measuring in 225mm (We recommend 16mm screws). to the centre of the tower unit. 225mm Back wall Fitting the secong hanger bar. 1- Place hanger bar into first bracket and level up. 2-Make sure to mark position on the side wall 225mm from the back wall.
