Installation Instructions
Original Instructions
Shaft Seal Kits for Kinetix TLP Servo Motors
Catalog Numbers TLP-SSN-F046, TLP-SSN-F070, TLP-SSN-F090, TLP-SSN-F100, TLP-SSN-F115,
TLP-SSN-F145, TLP-SSN-F200, TLP-SSN-F235
Topic
Page
2
2
2
3
4
6
7
Advertisement
Table of Contents
Related Manuals for Rockwell Automation Allen-Bradley TLP-SSN-F046
Summary of Contents for Rockwell Automation Allen-Bradley TLP-SSN-F046
- Page 1 Installation Instructions Original Instructions Shaft Seal Kits for Kinetix TLP Servo Motors Catalog Numbers TLP-SSN-F046, TLP-SSN-F070, TLP-SSN-F090, TLP-SSN-F100, TLP-SSN-F115, TLP-SSN-F145, TLP-SSN-F200, TLP-SSN-F235 Topic Page About Shaft Seals Required Tools Required Supplies Remove the Shaft Seal Replace the Shaft Seal Shaft Seal Kit Catalog Numbers Additional Resources...
-
Page 2: About Shaft Seals
• Abrasive cloth to remove any nicks or burrs from the motor shaft Required Supplies Lubricant - Grease, industrial grade, suitable for applications with speeds up to 6000 RPM, and –10…+80 °C (14…176 °F) temperature range. Rockwell Automation Publication 2090-IN044B-EN-P - September 2019... -
Page 3: Remove The Shaft Seal
Do not remove screws. 4. Inspect and clean the shaft and seal surfaces as necessary. Use an abrasive cloth to remove any nicks or burrs from the motor shaft. Rockwell Automation Publication 2090-IN044B-EN-P - September 2019... -
Page 4: Replace The Shaft Seal
• If the shaft seal is installed too shallow, it can reduce the effectiveness of the protective seal. 7. Replace the shaft key. Applies to motors that include a keyed shaft. Rockwell Automation Publication 2090-IN044B-EN-P - September 2019... - Page 5 Nom, mm (in.) Max, mm (in.) TLP-A0xx Press the shaft seal so that the seal is flush with the front surface of the motor. TLP-A1xx and TLP-A2xx 0.00 (0.00) 0.10 (0.004) 0.20 (0.008) Rockwell Automation Publication 2090-IN044B-EN-P - September 2019...
-
Page 6: Shaft Seal Kit Catalog Numbers
Kinetix TLP Low Inertia Motors Motor Cat. No. Shaft Seal Kit Cat. No. TPL-A046 TLP-SSN-F046 TPL-A070 TLP-SSN-F070 TPL-A090 TLP-SSN-F090 TPL-A100 TLP-SSN-F100 TPL-A115 TLP-SSN-F115 TPL-A145 TLP-SSN-F145 TPL-A200 TLP-SSN-F200 TPL-A235 TLP-SSN-F235 Rockwell Automation Publication 2090-IN044B-EN-P - September 2019... -
Page 7: Additional Resources
KNX-SG001 motion control products best suited for your system requirements. Industrial Automation Wiring and Grounding Guidelines, Provides general guidelines for installing a Rockwell Automation publication 1770-4.1 industrial system. Provides declarations of conformity, certificates, and other Product Certifications website, rok.auto/certifications... - Page 8 Rockwell Automation maintains current product environmental information on its website at http://www.rockwellautomation.com/rockwellautomation/about-us/sustainability-ethics/product-environmental-compliance.page. Allen-Bradley, Kinetix, MP-Series, Rockwell Automation, Rockwell Software, and TL-Series are trademarks of Rockwell Automation, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies. Rockwell Otomasyon Ticaret A.Ş., Kar Plaza İş Merkezi E Blok Kat:6 34752 İçerenköy, İstanbul, Tel: +90 (216) 5698400...
