Selecting M2R Receiver
Functions
The M2R Receiver includes a FlexList™ mode where
up to 16 mixes can be accessed by name. This feature
enables a user to quickly find and listen to any of the
performer's mixes on the stage. The mix includes the
name, frequency, mixer settings and limiter settings.
The mix is easily shared via the M2R IR port, added to
the list of 16 mixes and stored until cleared by the user.
The M2R allows the user to toggle between the mixes,
making troubleshooting issues easy and efficient.
The DCHT, DCHT/E01's M2R functions create an easy
interface with the FlexList feature. The following options
are available:
M2R... M2R...

GetFrq

SendFrq

GetAll

GetFrq
Sync to receive (get) frequency from the M2R transmit-
ter via the IR port
SendFrq
Sync to send frequency to the M2R transmitter via the
IR port
GetFrq SendFrq
Sync Sync
GetAll
Sync to receive (get) all available settings from the M2R
transmitter via the IR port, including the performer's
name, (or whatever name the user chooses for the
DCHT, DCHT/E01), frequency, mixer settings and lim-
iter settings.
NOTE: The GetAll function is designed for trouble
shooting and allows for settings to be cloned to transfer
to another receiver if there is a problem to be identi-
fied. Not all copied settings are available on the DCHT,
DCHT/E01.
12

SendAll

Name

Flex

Press the
button to begin sync
SendAll
Sync to send all available settings to the M2R transmit-
ter via the IR port, including the performer's name, (or
whatever name the user chooses for the DCHT, DCHT/
E01), frequency, mixer settings and limiter settings.
NOTE: The SendAll function is designed for trouble
shooting and allows for settings to be cloned to transfer
to another receiver if there is a problem to be identified.
Not all settings are available on the DCHT, DCHT/E01.
GetAll
Sync
Name...
Name the DCHT, DCHT/E01 to allow easy identifica-
tion on the M2R FlexList. The following are available for
custom names:
- NameTx: Name the DCHT, DCHT/E01
- NameCh1: Name Channel 1
- NameCh2: Name Channel 2
Use the UP and DOWN arrows to choose which
character you want and then MENU/SEL to move
to next space (there are 8 spaces available for each
name). Press BACK to save.
NOTE: Duplicate names are not allowed in a FlexList.
Be sure to choose unique names for Tx, Ch1 and Ch2.
Cursor
arrow
Flex
Sync DCHT, DCHT/E01 information to the M2R FlexList
either as one stereo Channel or individual channels:
- SendTx: Send (sync) all receiver information to
the M2R FlexList as one stereo channel
- SendCh1: Send (sync) Channel 1 unique infor-
mation to the M2R FlexList
- SendCh2: Send (sync) Channel 2 unique infor-
mation to the M2R FlexList
- SendM12: Send (sync) a mono mix of both
channels to the M2R FlexList
SendTx
Sync
SendAll
Sync
button to begin sync
NameTx
Press the
arrow buttons to select
the desired character,
press MENU/SELECT
DCHT to move to next space;
there are 8 spaces
available.
SendCh1
Sync
button to begin sync
LECTROSONICS, INC.
Press the arrow
and
Use the arrow
