I/O Connectors

Connector Description
J1 Power IN
J18 Serial port
J2 Radio/Line 1
J31 Radio/Line 2
J4 Display Header
J66 Handset Jack
J7 Ethernet port

Adjustments

Signal
RX Pre-amp
RX Compressor
TX Audio out
TX Monitor IN
(Not available in 750630 Rev A)
CTCSS out

IP-223 Settings - Quick Reference

Line 1 Test point
R175 TP13
RV5 TP12
R47 TP15
R390 TP13
R50 TP7
Line 2 Test point
R110 TP1
RV1 TP3
R61 TP5
R391 TP1
R53 TP10
123
