Summary of Contents for Telex TRA-223 Series
- Page 1 Motorola Radius, M10, M100, M120, M130, M200, GM300, SM50, SM120 and Maxtrac 100/300 Series Radios to TRA-223 and DSP-223 Series Adapter Panels AN-DISPATCH-005 Rev A 05 AUG 2009...
- Page 2 Table of Contents 1.0 General ..................... 3 2.0 Interconnect Cable Assembly ..............3 3.0 223 Series panels ..................3 3.1 TRA-223 Setup .....................3 3.1.1 TRA-223 Dip Switch Settings ..............4 3.2 3.2 DSP-223 Setup ....................4 3.2.1 3.2.1 DSP-223 Jumper Settings: ..............4 AN-DISPATCH-005...
- Page 3 Motorola Radius, M10, M100, M120, M130, M200, GM300, SM50, SM120 and Maxtrac 100/300 Series Radios to TRA-223 and DSP-223 Series Adapter Panels 1.0 General This application note is intended to show how to assemble a cable and setup the hardware of the TRA-223 and DSP-223 for single channel control to the following Motorola mobile radios: Radius, M10, M100, M120, M130, M200, GM300, SM50, SM120 and Maxtrac 100/300.
- Page 4 Motorola Radius, M10, M100, M120, M130, M200, GM300, SM50, SM120 and Maxtrac 100/300 Series Radios to TRA-223 and DSP-223 3.1.1 TRA-223 Dip Switch Settings Set the front panel dip switch for the following settings: Note: Refer to the TRA-223 manual for further instructions. TABLE 1.
- Page 5 Please contact technical support with suggestions or comments concerning this application note. Technical Support: Email: TelexDispatchtechsupport@us.bosch.com Fax: 1-402-467-3279 Phone: 1-800-898-6723 Bosch Security Systems, Inc. 8601 East Cornhusker Highway Lincoln Nebraska 68507 Phone: (800) 752-7560 Fax: (402) 467-3279 Email: Telexdispatch@us.bosch.com Web: www.telex.com...
