ICOM IC-A200 Aircraft Radio to
223 Series Adapter Panels
AN-DISPATCH-033 Rev B
11 FEB 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRA-223 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Telex TRA-223

Summary of Contents for Telex TRA-223

  • Page 1 ICOM IC-A200 Aircraft Radio to 223 Series Adapter Panels AN-DISPATCH-033 Rev B 11 FEB 2011...

  • Page 2: Table Of Contents

    Table of Contents 1.0General ........................3 2.0Interconnect Cable assembly..................3 3.0223 Series Panels......................3 3.1TRA-223 Setup ..........................3 3.2TRA-223 Dip-Switch Settings ....................4 3.3DSP-223 Jumper Settings......................4 3.4IP-223 Setup ..........................5 3.5ICOM IC-A200 Radio Setup ....................5 AN-DISPATCH-033...

  • Page 3: General

    MIC+ 6 & 8 3.0 223 Series Panels 3.1 TRA-223 Setup The TRA-223 requires the TO-23 option is installed to support a connection to the ICOM IC-A200. For more information, see the TRA-223 Technical Manual (P/N 803570). REFERENCE: This document is available for download at www.telexradiodispatch.com/.

  • Page 4: Tra-223 Dip-Switch Settings

    ICOM IC-A200 Aircraft Radio to 223 Series Adapter Panels 3.2 TRA-223 Dip-Switch Settings Use Table 2 to set the dip switches for the TRA-223. TABLE 2. TRA-223 Dip Switch Settings Switch Setting Signal 2–Wire = On As appropriate 4-Wire = Off 4–Wire = On...

  • Page 5: Ip-223 Setup

    223 Series Panels 3.4 IP-223 Setup Set up the appropriate IP-223 lines for Local mode. Using control and set the jumpers as follows. TABLE 3. Line 1 Jumper Setting Line 2 J33, J34 B = 4-wire J5, J6 J16, J21 B = Balanced J19, J20 Hanging on center pin = 10K Ohm...
  • Page 6 ICOM IC-A200 Aircraft Radio to 223 Series Adapter Panels AN-DISPATCH-033...
  • Page 7 Bosch is prohibited. Technical Support: *All other trademarks are property of their respective owners. Phone ..........(800) 898-6723 ARRANTY AND ERVICE NFORMATION E-mail..TelexDispatchtechsupport@us.bosch.com For warranty and service information, refer to www.telex.com/ Web ..........www.telex.com warranty. Web ......www.telexradiodispatch.com ACTORY ERVICE ENTER LAIMS Factory Service Center Bosch Security Systems, Inc.
  • Page 8 Revision History Document Title: ICOM IC-A200 Aircraft Radio to 223 Series Adapter Panels Document Number: AN-DISPATCH-033 Revision Change Description Date Update brand, format and new document number. 15-NOV-2009 Update Telex website url. Correct table 2: row 6 column 1. 11-FEB-2011...
