- Page 1 HB-3+ Headset Adapter Connected to the IP-223 Operating as a Positional Intercom AN-DISPATCH-036 Rev A 31-MAR-2010...
- Page 2 Table of Contents 1.0 General ..................... 4 1.1 Cable Modification ....................4 2.0 HB-3plus Setup ..................5 3.0 IP-223 Setup .................... 5 3.1 Multicast Setup Window ..................5 3.2 IP-223 Jumper Settings ..................6 3.3 Per Line Setup Window ..................6 AN-DISPATCH-036...
- Page 3 Operating as a Positional Intercom 1.0 General This application note is intended to show how to configure and connect the Telex Radio Dispatch IP-223 Ethernet Adaptor Panel to a Telex HB-3+ Headset Adaptor. This connection provides PTT (Push-To-Talk) control and audio connections for an intercom position to listen and talk on a radio network that is crosspatched by a console position.
- Page 4 HB-3+ Headset Adapter Connected to the IP-223 Operating as a Positional Intercom FIGURE 1. Intercom Design Layout 2.0 HB-3plus Setup To configure the jumper for console mode, do the following: > Move J8 to the B position. 3.0 IP-223 Setup The IP-223 is configured for Local mode.
- Page 5 HB-3+ Headset Adapter Connected to the IP-223 Operating as a Positional Intercom 3.2 IP-223 Jumper Settings To configure the IP-223 jumper settings for use with an HB-3+, do the following: > Set jumpers as indicated in Table 2. TABLE 2. Line 1 Jumper Setting Line 2...
- Page 6 Contact technical support with suggestions or comments concerning this application note. Technical Support: Email: TelexDispatchtechsupport@us.bosch.com Fax: 1-402-467-3279 Phone: 1-800-898-6723 Bosch Security Systems, Inc. 8601 East Cornhusker Highway Lincoln Nebraska 68507 Phone: (800) 752-7560 Fax: (402) 467-3279 Email: Telexdispatch@us.bosch.com Web: www.telex.com Downloads: www.telex.com/Downloads/...
