Tone Frequency & Durations Window
In the Monitor Frequency field, enter the frequency (in Hz) of the function tone sent when the MON button on the
9.
console is pressed.
NOTE: In the FTone 1-16 Frequency fields, the standard frequencies associated with each function tone are provided
in the first field for the function tone. To change the frequency for a function tone, enter the desired
frequency (in Hz) in the field provided.
In the frequency field, enter the desired frequency (in Hz).
10.
Enter the desired frequency (in Hz) for the second function tone. An entry of zero (0) indicates no second function
11.
tone is sent.
Click Submit.
12.
The entries currently displayed on the window are sent to the IP-223 for storage.
From the links, select Save to EEPROM.
13.
The Save Setup Parameters window appears.
Click Save Parameters.
14.
The entries are saved to permanent memory.
