Watchguard AP Series Quick Start Manual page 2

CONTENTS
Pole Mount Accessories
Wall mount
Pole mount clamps
1 2
Wall Mount Accessories
Drill location
50.00 mm
Wall mount stencil Wall mount
Optional Accessories
4 5
Antenna Options
WG9004 Dual-Band Omni Antennas (5/7 dBi)
Power Options
WG8599 (US) WatchGuard 802.3at PoE+ Injector with AC cord (US)
WG8600 (EU) WatchGuard 802.3at PoE+ Injector with AC cord (EU)
WG8601 (UK) WatchGuard 802.3at PoE+ Injector with AC cord (UK)
WG8602 (AU) WatchGuard 802.3at PoE+ Injector with AC cord (AU)
2
Ground Wire
Ground Wire Ground Wire Screw
3
Insert four anchors
4x 4x
Anchors Anchor Screws
6
1 ACTIVATE YOUR AP
GO TO:
watchguard.com/activate
4x
Wall Mount
Screws
AP327X
Model: O-105E
Input:PoE (802.3at): 48V
SN: 37AP0007A-XXXX
Eth. MAC: 00:90:7F:13:02:DF
, 400mA
3
