Cleaning the Brush Roll
WARNING
To reduce the risk of electric shock, turn Power Switch OFF and disconnect plug from electrical outlet
before performing maintenance or troubleshooting checks.
1
Place vacuum upside down with Brush
Roll facing upwards. Remove 5 screws
with a Phillips-head screwdriver.
3
Check air passageway for obstructions.
5
When finished cleaning, align Brush
Roll with belt turning by hand several
times in the direction of the motor to
align the belt on the Brush Roll.
2
Lift off brush cover and grasp Brush
Roll at both ends to lift out. Clean debris
from Brush Roll, motor pulley and drive
belt. If Brush Roll is worn, replace as
needed.
4
Separate the hose from the hose wand
base to look through hose for clogs.
Remove debris from this area.
6
Replace the brush cover and 5 screws.
www.BISSELL.com
11
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the PowerForce Compact Turbo 2690 Series and is the answer not in the manual?
Questions and answers
Boswell power force compact turbo vacuum will not start
The Bissell PowerForce Compact Turbo 2690 Series vacuum may not start due to the following possible causes:
1. The power cord is not plugged in – Ensure the plug is securely connected to an electrical outlet.
2. A blown fuse or tripped circuit breaker – Check and replace the fuse or reset the circuit breaker if needed.
3. The dirt tank is full – Empty the dirt tank.
4. A dirty filter – Inspect the filter and clean or remove any dirt.
5. The hose is not securely connected – Ensure the hose is properly attached at both ends.
6. The dirt tank is not correctly positioned – Make sure the dirt tank is fully inserted and latched.
7. A vacuum path obstruction – Check for blockages in the air passage or intake area.
Following these steps should help resolve the issue.
This answer is automatically generated
