Cleaning the Brush Roll

WARNING
To reduce the risk of electric shock, turn Power Switch OFF and disconnect plug from electrical outlet
before performing maintenance or troubleshooting checks.
1
Pinch the tabs on the
brush guard inward and
pull to remove.
4
Replacing the Edge Cleaning Brushes
A Phillips-head screwdriver is required for this task.
1
Use a Phillips-head screwdriver to
remove the screw. Pull up on the base
of the brush.
NOTE: After being used for a period of time, the Edge Cleaning Brushes need to be cleaned
to work more effectively. Once removed, the Edge Cleaning Brushes can be rinsed or soaked
in water. Be sure they are completely dry before returning to the machine.
6
BISSELL.eu
2
Lift to remove the
Brush Roll.
2
Push the brush directly onto the
holder. Replace the screws with a
Phillips-head screwdriver.
3
Clean the Brush Roll
with the Cleaning Tool.
Replace the Brush Roll and
brush guard.
NOTE: The Brush Roll has
two different end pieces.
Ensure the square-shaped
end piece is inserted into the
square-shaped port.
