User's manual
Video door intercom
System characteristics
Door stations
Programming of door stations
Detailed information on monitors
Support for memory monitors
Installation
Connection diagrams
Video-intercom operation
Warranty Card
RoHS
1
2
15
29
41
43
44
63
65
W20180427

Advertisement

loading
Need help?

Need help?

Do you have a question about the S36 and is the answer not in the manual?

Questions and answers

Related Manuals for Vidos S36

Summary of Contents for Vidos S36

  • Page 1 Programming of door stations Detailed information on monitors Support for memory monitors Installation Connection diagrams Video-intercom operation Warranty Card Firma Handlowa Wena Al. Jerozolimskie 311 05-816 Reguly/ near Warsaw Poland tel. +48 22 8370286; +48 22 8174008 e-mail: biuro@vidos.pl www.vidos.pl RoHS W20180427...

  • Page 2: System Characteristics

    System characteristics S36 ....................Vidos video intercoms are the top-of-the-range devices which fulfil a whole range of features. They are characterised by a unique design and a variety of expansion options. These systems are designed for both single- and multi-family premises. For the convenience of users, these devices enable power supply the operation of two inputs, you can also connect additional CCTV cameras.
  • Page 3 S50D ....................S561D ..................... lock power monitor 5 6 7 8 9 10 setting the access time for the user monitor EXIT 10-20 and 36-40 power EXIT lock supply DC release lock button release button volume volume control control 1: audio - red 1: audio - red 2: ground - blue 2: ground - blue...
  • Page 4 S561Z ....................S562A ....................monitor 1 lock monitor 2 power lock power monitor lock lock release EXIT EXIT release button button volume fingerprint control reader volume control 1: audio - red 2: ground - blue 3: power supply to the camera 1: audio - red from the monitor - yellow 2: ground - blue...
  • Page 5 S6 ..................... S602 / S603 ..................lock monitor volume control CN1: to CN10 in the main module 1: audio - red 2: ground - blue 3: power supply to the camera from the monitor - yellow 4: video - white 5: lock - black 6: lock - black Dimensions: 55x135x39 mm...
  • Page 6 S556 / S558 ..................S601D-2................... volume control J3: output to the lock or jumpers controlled from the monitor only (5-NO; 6-COM; 7-NC) CN1: monitor 1. audio - red power supply 2. ground - blue lock DC 12-14.5V 3. power supply to the camera from the monitor - yellow 4.
  • Page 7 S603D-2..................S603A-2..................... CN1: to CN10 in the main module CN1: to CN10 in the main module J3-1 J3-2 J3-1 J3-2 J1-1 J1-1 PWR: power supply DC 12-14.5V PWR: power supply DC 12-14.5V +: red -: black +: red -: black J5: RS485 J4: additional lock release button J4: additional lock release button...

  • Page 8: Technical Data

    S606 ....................CAMERA ELEMENT Cover CN1: to CN10 in the main module Camera Speaker Call button Microphone 1 2 3 4 Camera-mounting screw Cn10: to the next module with the call buttons Signboard for your (tenant's) name / surname CN9: to CN22 in the main module CN4 - CN6: monitors Cable culverts 1.
  • Page 9 Programming Door Station with S601A-2 / S603A-2 RFID Reader  Insert a user number (from 000 to 999) and the LED lights up green (if it is red, the number is already occupied, press to return and add a user with a different number).
  • Page 10 Programming of Door Station with S601D-2 / S603D-2 Encoding  to exit the programming mode. Lock To set the opening time for Zone II The encoding lock in the 600 series panels supports 2 zones. The maximum number  Enter the programming mode and select 5, the LED flashes yellow.
  • Page 11 3. Adding a new user for Zone I To set the opening time for Zone I  Enter the programming mode, the LED flashes yellow.  Enter the programming mode and select 1, the LED flashes yellow.  Insert a user number (from 000 to 999) and the LED lights up green (if it is red, ...
  • Page 12 Programming Door Station with S601Z-2 Fingerprint Reader If the password length is changed to 2 digits, after restoration it will be when to 3 digits - . INSERT YOUR PASSWORD TWICE. The biometric reader in the S601Z panel supports 2 zones. The maximum number of fingerprints 800 (Zone I);...
  • Page 13 Programming of Door Station with S50 / S561D / 562D Encoding  to exit the programming mode. Lock 5. Deleting user(s)  Enter the programming mode. 1. Programming of the user access code  Insert a number of the user to be deleted (from 000 to 899). 1) press , you will hear 2 short beeps ...
  • Page 14 1) Enter the programming mode (see step 1). 4) press , you will hear 2 short beeps, the LED flashes 2) Press on the remote controller. You will hear a long beep. Wait for the 5) press , you will hear 1 short beeps, the LED flashes sound signal to end to confirm that all the cards have been deleted from the 6) press , you will hear 5 short beeps, the LED goes out, the system is reset.
  • Page 15 7. Deleting all the users Programming Door Station with S561Z Fingerprint Reader 1) Enter the programming mode. DH12-R remote controller is used for programming the reader. the LED flashes orange. 900 is the maximum number of users. The remote controller is included. ;...
  • Page 16 M270-S2 Detailed information on Monitors M270 cursors menu exit menu automatic door system control Dimensions: 282x135x23 mm automatic door system control Dimensions: 282x135x23 mm 1: audio - red power supply 2: ground - blue camera 1 DC 14.5 V power supply 1: audio - red camera 1 3: camera power supply - yellow...
  • Page 17 M320 M323 Dimensions: 245x160x18 mm Dimensions: 245x160x19 mm 1: audio - red camera 1 2: ground - blue connection 3: camera power supply - yellow 1: audio - red power supply 4: video - white camera 1 2: ground - blue DC 14.5 V 8: power supply (+) - red connection...
  • Page 18 M395 M670 Dimensions: 241x161x23 mm Dimensions: 128x180x24 mm power supply 1: audio - red power supply camera 1 DC 14.5 V 2: ground - blue DC 14.5 V camera 2 connection connection 3: camera power supply - yellow connection connection ring tone 4: video - white volume control...
  • Page 19 M670-S2 M690-S2 menu menu exit menu navigation menu exit cursors navigation cursors Dimensions: 241x161x23 mm Dimensions: 208x150x20 mm power supply camera 1 1: audio - red power supply DC 14.5 V 1: audio - red camera 1 connection DC 14.5 V 2: ground - blue connection 2: ground - blue...
  • Page 20 M361 Dimensions: 160x120x42 mm Dimensions: 208x150x20 mm camera 1 J2 J1 connection 1: audio - red 1 2 3 4 2: ground - blue power 3: camera power supply - yellow supply 4: video - white power supply DC 14.5 V 8: power supply (+) - red camera 1 DC 14.5 V...
  • Page 21 MONITOR ITEM Microphone Camera image preview button Intercom button Lock release button Call acceptance button Screen Speaker Call volume control Brightness adjustment Colour adjustment Ring tone volume control Receiver Installation couplings Control of the automatic door system TECHNICAL DATA Power supply DC 14.5V Power consumption 7W working current...
  • Page 22 Deleting all the images Ringtone melody settings Press the button to display the menu window. Pressing the button the The monitor has 16 ring tones to choose from, to change the tone you need to: appropriate number of times takes you to the Delete All window - pressing the 1.

  • Page 23: Connection Diagram

    Instalation Connection diagram 1. When connecting the power supply to your video intercom, pay special attention to the correct connection of its poles! Incorrect connection will damage the video intercom. 2. Do not install the device in places subject to dust, direct sunlight, high temperatures or high humidity.
  • Page 24 S6 / S35 / S551 S6 / S35 / S551 2 cameras + 1 monitor or uniphone 1 camera + 1 monitor or uniphone Power Lock Power Power Camera 1 DC14.5V Power Lock DC14.5V white yellow Camera 1 blue white yellow Monitor 1 blue...
  • Page 25 S6 / S35 / S551 Power S50D DC 12V 2 cameras + 2 monitors or uniphones 1 camera + 1 monitor or uniphone Lock Lock release buttom Power DC 14.5 V Camera 1 Power Power DC 14.5V white yellow Lock blue Power DC 14.5V...
  • Page 26 S50D S50D 2 cameras + 1 monitor or uniphone 2 cameras + 2 monitors or uniphones Power Power DC 12 V DC 12V Lock Lock Power Power Lock Lock DC 14.5V release DC 14.5V release buttom buttom Power DC 14.5V Camera 1 Camera 1 white...
  • Page 27 S561D / S561A / S561Z / S562D / S562A / S36 S561D / S561A / S561Z / S562D / S562A / S36 1 camera + 2 monitors or uniphones 2 cameras + 2 monitors or uniphones Power DC12V Power Lock...
  • Page 28 S561D / S561A / S561Z / S562D / S562A / S36 S563 / S564 / S556 / S558 2 cameras + 4 monitors or uniphones Lock DC 12V Power DC12-14.5V black black white yellow black blue Power Monitor 8 DC12-14.5...
  • Page 29 S601 S601 1 camera + 1 monitor or uniphone 1 camera + 2 monitors or uniphones Camera Volume Camera Volume control control Lock Lock black black Monitor Monitor Power Power Power Power DC 14.5V DC 14.5V 2 cameras + 1 monitor or uniphone black Volume Camera 1...
  • Page 30 S601A-2 / 601D-2 / 601Z-2 S601A-2 / 601D-2 / 601Z-2 1 camera + 2 monitors or uniphones 1 camera + 1 monitor or uniphone Power DC 14.5V Power DC 14.5V Monitor Monitor Power DC 14.5V Volume control Volume Monitor control J1-1 J1-1 Lock 1...
  • Page 31 S 602 / S 603 / S 603A / S 603D S 606 Camera Power DC 12-14.5V black Lock 1 2 3 4 Monitor zasilacz DC14,5V black black Monitor Monitor Power DC 14.5V Power Camera DC 14.5V Lock Volume control 1 2 3 4 black Camera...
  • Page 32 Automatic door station connection Additional types of connections Using a CCTV camera instead of the door station camera In case of insufficient visibility from the camera in the external panel, a CCTV camera can be Exemplary monitor/automatic door station connection diagram The connection used for connection and viewing.

  • Page 33: Video-Intercom Operation

    Video-intercom operation Calling Intercome If there are 2 or more monitors installed in A guest presses the call button on the the system: camera. to call up the second monitor, press the intercom button The monitor shows a guest's image and emits a chime signal.

  • Page 34: Warranty Card

    8. The condition to perform repair works is to deliver the Product with the Warranty Card and the proof of purchase. 9. Service Centre: Firma Handlowa Wena Al. Jerozolimskie 311 05-816 Reguly/ near Warsaw, Poland tel. +48 22 8370286; +48 22 8174008 e-mail: biuro@vidos.pl www.vidos.pl...
