Summary of Contents for Gold Medal 2396A
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS... -
Page 3: Installation Instructions
It is Gold Medal Products Company’s recommendation that this machine be plugged directly into a wall outlet. The use of extension cords is not recommended due to safety concerns and reduction of machine performance. -
Page 4: Installation
6. Plug the power cord from the rack assembly into a proper outlet. 7. Load two boxes of pre-heated topping into the rack. Gold Medal’s Backroom Warmer, Item #2262, may be purchased for pre-heating the topping. Remove the cardboard cutout on the box to expose the quick-disconnect fitting. -
Page 5: General Cleaning Instructions
4. Fill the pail with a sanitizing solution. Gold Medal offers a product for this purpose, Chlor-Tech, part number 1109. Put the bag connector in the pail of sanitizer. Pump it through the lines by holding the dispense button until the pail is empty. -
Page 6: Maintenance Instructions
Bag-In-A-Box Counter Butter Dispenser MAINTENANCE INSTRUCTIONS All Models #2396A and #2396AD... -
Page 7: Ordering Spare Parts
2. When ordering, please include part number, part name, and quantity needed. 3. Please include the machine’s model name, serial number, and date of manufacture (located on the machine nameplate) with your order. 4. Address all parts orders to: Bruce's Entertainment (661) 257-4260 All Models #2396A and #2396AD... - Page 8 Bag-In-A-Box Counter Butter Dispenser PARTS BREAKDOWN – BUTTER TOWER Pedestal Sign p/n 39144 Momentary Switch p/n 38971 No Drip Spout Pan Insert Weldment p/n 38566 p/n 38938 Drip Pan p/n 38936 Momentary Switch p/n 38971 All Models #2396A and #2396AD...
- Page 9 75110 Lead-In Cord Tygon Tubing p/n 22038 p/n 91375 Bag Connector p/n 79100G Thermostat 135F Cinch Jones Plug p/n 38990 p/n 79129 Pilot Light p/n 41033 Exhaust Blower p/n 48018 Heat Element 250W p/n 38824 All Models #2396A and #2396AD...
-
Page 10: Electrical Schematic
Bag-In-A-Box Counter Butter Dispenser ELECTRICAL SCHEMATIC All Models #2396A and #2396AD... - Page 11 Bag-In-A-Box Counter Butter Dispenser COUNTER TOP CUTOUTS All Models #2396A and #2396AD...
-
Page 12: Warranty
WARRANTY WE WARRANT to the original purchaser the Gold Medal equipment sold by us to be free from defects in material or workmanship under normal use and service. Our obligation under this warranty shall be limited to the repair or replacement of any...
