Connecting Network and Power Source

AC Power Option
Connect the supplied Network cable
between the LAN jack on the phone
and the LAN port on the wall or hub/
switch device port. Connect the DC
plug on the AC wall adapter to the DC
jack marked on the phone.
In-Line Power Option
If the phone is connected to a compat-
ible Ethernet switch that can provide
in-line power, the phone will use that
power option. Simply plug the sup-
plied Network cable between the LAN
jack on the phone and an available
Power and Data port on the In-Line
Power switch.
IEEE 802.3af compliant
In-Line Power switch

(Optional)
(Optional)
