  • Page 1 PLSG10000 Z-Wave indoor siren Important notes and FAQs about this product and other products can be found on the Internet page www.abus.com Version 1.3...
  • Page 2 Software, or any breach by ABUS Security Center of its obligations under this Agreement.a. any warranty, contractual, statutory or compensatory damages claims, notwithstanding any other limited or implied warranties, or if the limited warranty does not apply, ABUS Security Center's liability shall be limited to the purchase price of the Product.

  • Page 3: Important Safety Instructions

    Please make sure that the packaging contains the DSK (Device Specific Key) card. This card shows the DSK of your ABUS Z-Wave device. Please keep them in a safe place. Each S2 (Security 2) certified Z-Wave Gateway requires the DSK to learn the device.
  • Page 4 English Notes on handling batteries  Ensure that batteries cannot fall into the hands of children. Children could put batteries in their mouths and swallow them. This can lead to serious damage to health. In this case consult a doctor immediately! ...

  • Page 5: Table Of Contents

    English Table of contents Product operation ..........................6 1.1. Scope of delivery ........................6 1.2. Device features ........................6 1.3. Operating principle ........................7 1.4. Performance characteristics ....................7 1.5. Use in systems of different manufacturers ................7 1.6. DSK Code ..........................7 Functional overview ..........................

  • Page 6: Product Operation

    English 1. Product operation 1.1. Scope of delivery  ABUS Z-Wave indoor siren  1x USB cable for transferring sound files  4x GP LR14 D batteries  Mounting material: screws, dowels, adhesive pads  Quick guide & safety instructions ...

  • Page 7: Operating Principle

    English 1.3. Operating principle The PLSG10000 is designed for use in alarm and home automation systems using the Z-Wave radio standard. The device has the following functions:  Alarm Activation: When the siren is activated by the Z-Wave Gateway, the unit's piezoelectric siren sounds for 3 minutes (default) along with the flashing LED.

  • Page 8: Functional Overview

    English 2. Functional overview 2.1. Inclusion (Inclusion) / Teach-in device Activate the inclusion mode (teach-in mode) on the gateway. (for further details please refer to the gateways manual) Press the "+" key (Add / Inclusion) in your Z-Wave app and follow the instructions to set the gateway to Inclusion mode.

  • Page 9: Planning, Assembly And Installation

    English 2.2. Planning, assembly and installation The unit uses low-power radio signals to communicate with the Z-Wave Gateway. To achieve the best results, please note the following:  Please do not attach directly to metal levels or metal structures as this may limit the range. ...

  • Page 10: Exclusion (Exclusion) / Teach Device Out

    English 2.3. Exclusion (Exclusion) / Teach device out Activate the exclusion mode (learn-out mode) at the gateway. (for further details please refer to the gateways manual) Press the "-" key (Remove / Exclusion) in your Z- Wave app and follow the instructions to set the gateway to exclusion mode.

  • Page 11: Wake Up Device / Wake-Up

    In addition, the device memory already contains 14 useful files:  Further language files in German and English are available for download: www.abus.com/product/PLSG10000  For example, you can be informed about fault messages, such as low battery status of a component, or status changes of the system, e.g.
  • Page 12 English Load audio files to siren A PC with Microsoft Windows operating system and a mini USB cable is required. Make sure that the batteries are inserted in the speech siren as well, otherwise the download will not work. 1. connect the siren to the USB port of the PC using the mini-USB cable Windows asks you if you want to run the software.
  • Page 13 English Explanation of symbols: icon statement Transfer audio files from the middle column of the PC to the right column, the buffer of the siren. Save audio files from siren to PC Play audio file on PC Speaker Pause playback Delete audio file Change the order of the audio files.

  • Page 14: Advanced Z-Wave Parameters

    English 3. Advanced Z-Wave Parameters 3.1. association groups Z-Wave devices can control other devices directly. This direct control is called Z-Wave Association. The device ID of the device to be controlled must be stored in the controlling devices. This is done in so-called association groups.

  • Page 15: Overview Configuration Parameters

    English Switch Binary Report Shows the status of the piezo siren alarm. value Description of the 0x00 Siren's off. 0xFF Siren's on. Siren On/Off Switches the status of the piezo alarm of the siren value Description of the 0xFF Siren is activated and LED starts flashing 0x00 Siren is deactivated and LED goes out 3.2.

  • Page 16: Technical Data

    English 4. Technical data parameter PLSG10000 Dimensions (W x H x D) 44 x 200 x 58 mm Weight 506 g Operating temperature >0° – 40°C IP class IP 20 (indoor) Radio frequency 868.42 MHz (Z-Wave PLUS, Europe) Modulation FSK (BFSK/GFSK) Transmission power: <...
