GB
CAUTION!
Read all safety regulations and instructions.
Any errors made in following the safety regulations
and instructions may result in an electric shock, fire
and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
2. Layout (Fig. 1-4)
1 Tank indicator
2 Tank cover
3 2 x 240 V~ socket-outlets
4 Earth connection
5 Overload cut-out
6 Voltmeter
7 Oil filler plug
8 Oil drain plug
9 Oil shortage cut-out
10 On/Off switch
11 Choke lever
12 Reversing starter
13 Petrol cock
3. Proper use
The device is designed for applications operated with
a 240 V alternating current source. Be sure to
observe the restrictions in the safety instructions.
The generator is intended to provide electric tools
and light sources with electricity.
When using the device with household appliances,
please check their suitability in accordance with the
relevant manufacturerʼs instructions. In case of
doubt, ask an authorized dealer of the respective
appliance.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
6
01.06.2010 10:15 Uhr Seite 6

4. Technical data

Generator Synchronous
Protection type:
Continuous rated power P (S1):
rated
Maximum power P (S2 5 min):
max
Rated voltage U :
rated
Rated current I :
rated
Frequency F :
rated
Drive engine design: 4-stroke, air-cooled
Displacement:
Max. power: 4.77 kW / 6.5 hp
Fuel: normal unleaded petrol
Tank capacity:
Engine oil: approx. 0.6 l (15W40)
Consumption at 2/3 load: approx. 1.4 l/h
Weight:
Sound pressure level L :
pA
Sound power level L /Uncertainty K:
WA
92.9 dB (A)/0.35 dB(A)
Power factor cos ϕ:
Protection type:
Power class:
Max. temperature:
Max. altitude (above mean sea level):
Spark plug: NGK BPR5ES
Operating mode S1 (continuous operation)
The machine can be continuously operated with the
quoted power output.
Operating mode S2 (temporary operation)
The machine may be temporarily operated with the
quoted power output. Afterwards the machine must
be stopped for a while to prevent it from overheating.
5. Before putting the machine into
operation
5.1 Electrical safety:
Electric supply cables and connected equipment
must be in perfect condition.
The generator is to be operated only with
equipment whose voltage specifications conform
with the generator's output voltage.
IP23
2000 W
2200 W
2 x 240V~
8.7 A
50 Hz
196 cm³
15 l
44 kg
72.9 dB(A)
1
IP23
G1
40°C
1000 m
