MS926P User's Manual
Wireless 2D Pocket Scanner
- MS926P -
User's Manual
Version 1.1
© 2019 unitech Electronics Co., Ltd. All rights reserved.
unitech is a registered trademark of unitech Electronics Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS926P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Unitech MS926P

Summary of Contents for Unitech MS926P

  • Page 1 MS926P User’s Manual Wireless 2D Pocket Scanner - MS926P - User's Manual Version 1.1 © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 2 MS926P User’s Manual Change Log Date Change Description Version 20190401 first published version 20190625 Update 1.7 © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 3: Preface

    –Reorient or relocate the receiving antenna. © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 4 1.5 cm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 5 Canada. European Conformity Statement unitech Electronics co., Ltd herewith declares that the unitech product is in compliance with the essential requirements and all other provisions of the RED 2014/53/EU directive, the EMC 2014/30/EU directive and the Low Voltage 2014/35/EU directive.
  • Page 6 Waste electrical and electronic equipment (WEEE) unitech has set up a policy and process to meet the EU directive 2002/96/EC and update 2003/108/EC concerning electronic waste disposal. For more detailed information of the electronic waste disposal of the products you have purchased from unitech directly or via unitech’s resellers, you shall either...
  • Page 7 MS926P User’s Manual Taiwan NCC Warning Statement 低功率電波輻射性電機管理辦法 第十二條：經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者 均不得擅自變更頻率、加大功率或變更原設計之特性及功能。 第十四條：低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有 干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。 低功率射頻電機需忍受合法通信或工業、科學及醫療用電波輻射性電機設備 之干擾。 注意事項: 1. 使用過度恐傷害視力。 2. 使用30分鐘請休息10分鐘；2歲以下幼兒不看螢幕，2歲以上每天看螢幕不要超過 1小時。 3. 減少電磁波影響，請妥適使用。 © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 8: Laser Information

    MS926P User’s Manual Laser Information The unitech product is certified in the U.S. to conform to the requirements of DHHS/CDRH 21CFR Subchapter J and to the requirements of IEC 825-1. Class II and Class 2 products are not considered to be hazardous. The unitech product contains internally a Visible Laser Diode (VLD) whose emissions do not exceed the maximum limits as set forth in the above regulations.

  • Page 9: Battery Notice

    It may not be functional anymore. Please only use the original battery from unitech. Using a third party battery can damage our products. Please note that when such damage occurs, it is not covered by your warranty.
  • Page 10 If the connector is damaged, please ensure the connector is being CAUTION! fully repaired before use the unit to avoid causing short circuited. viii © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 11 Please follow the limitation of suggested temperature conditions to avoid failure, damage or malfunction. *For applicable temperature conditions, please refer to the specification of each product. © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 12: Adapter Notice

    Please remove the power adapter when the battery is fully recharged. The bundled power adapter that comes with your unitech product is not meant to be used outdoors. An adapter exposed to water or rain, or a very humid environment can cause damage to both the adapter and the product.

  • Page 13: Worldwide Support

    MS926P User’s Manual Worldwide Support unitech’s professional support team is available to quickly answer questions or assist with technical-related issues. Should an equipment problem occur, please contact the nearest unitech regional service representative. For complete contact information please visit the Web sites listed below: Taipei, Taiwan –...

  • Page 14: Warranty Policy

    The warranty period is varied from each country. Please consult with your supplier or unitech local office for actual length of warranty period to your purchased product. Warranty becomes void if equipment is modified, improperly installed or used, damaged by accident or neglect, or if any parts are improperly installed or replaced by the user.

  • Page 15: Table Of Contents

    Chapter 4 – Command Settings............72 4.1 Operation Mode..................72 4.2 System setting..................73 4.3 RF Config.....................75 4.4 Data & Memory ..................76 xiii © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 16 4.6 HID Keyboard Character Delay ............78 4.7 Beep & Vibration & Indicators...............80 4.8 Data Terminator ..................83 4.9 1:1 / 1:N Checking Indicators ...............84 © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 17: Chapter 1 - Overview

    MS926P User’s Manual Chapter 1 - Overview 1.1 Package Please make sure the following contents are in the MS926P gift box. If something is missing or damaged, please contact your unitech representative. The standard package contents MS926P Scanner ￭ Quick Reference Guide ￭...

  • Page 18: Scanner Detail

    Product Label Hand Strap Hole Micro USB Connector For scanner charging and data transmission - 2 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 19: Specifications

    6.7 mils 5.5 cm 13.5 cm Data Matrix 10 mils 5.5 cm 13 cm 15 mils 4.5 cm 17.5cm - 3 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 20 Battery Charging time Fully charged in about 4 hours Operating Time 9 hours at condition of 1 scan/5 sec - 4 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 21 36.9mm x 95.9mm x 21.1mm Scanner Weight Switch life 10 million times Regulation Approvals  CE, FCC, BSMI, VCCI - 5 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 22: Getting Started

    Plug the USB Dongle to a free USB port of a host computer. The MS926P is now ready to use. - 6 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 23: Battery Charging

    Insert the Micro USB connector into the port on the scanner and the standard USB connector of the USB cable into a USB port on the host PC. - 7 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 24: Led Indicator / Beeper Sequence

    Red light Battery charging connected) always on (USB charging cable Green light Battery connected) always on Fully charged - 8 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 25: Display Menu Tree

    MS926P User’s Manual 1.7 Display Menu Tree To enter main menu of MS926P, press and hold Page Down key and then press Page Up key for 5 seconds. (During one handed operation, you can press the area in between Page Down key and Page Up key to enter the main menu.)
  • Page 26 Erase entry if Yes 2. Erase Buffer Yes/ No selected 3. Free MEM 3.1 Show FREE BUFFER Space - 10 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 27 AM/ HH:MM:SS 7. Data Disable 7.1 Disable Disable /Enable Validation CHECKING CHECKING 7.2 1:N Checking START POSITION LENGTH - 11 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 28 1. RF Address 1.1 RF MAC ADDR RF INFO 2.RF Remove 2.1 Erase ? YES / NO 3. Exit - 12 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 29 3.9.1 1:1 / 1:N Beeper Checking Fail Indicator 3.9 Checking Fail Beeper & Vibrator Vibrator Beeper / None - 13 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 30 2.17 ISSN 2.18 ISBN 2.19 Industrial 2 of 5 2.20 Standard 2 of 5 2.21 MSI PLESSEY 2.22 PLESSEY - 14 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 31 2.1 Auto Trace / Upper/ Lower Auto Trace Keyboard Setting 3. KBD 3.1 1ms/ 100ms/ 50ms/ 20ms/ 10ms/ ChrDelay 4. Exit - 15 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 32: Chapter 2 - Installation

    Step 2. Plug the USB Dongle to a free USB port of a host computer. Step 3. Open a word processing program such as Microsoft Word or Notepad and scan the following barcode. If the word “unitech” appears on the screen you have successfully installed your scanner.
  • Page 33 This allows you to scan into any field you could normally type into. ● If the MS926P is out of RF transmitting range from the host device, it will automatically save any scan data in its buffer memory and automatically upload the scan data to the host when back in RF transmitting range.

  • Page 34: Chapter 3 - Symbology

    If the Disable 2D Symbologies feature is enabled, the engine will not be able to read any 2D barcodes. Enable 2D Symbologies Disable 2D Symbologies - 18 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 35 Before starting any symbology setting, please scan “Enter Setup” Enter Setup When finished setting, please scan “Exit Setup” Exit Setup - 19 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 36 Enable Code 128* Disable Code 128 Set the Minimum Set the Maximum Length for Code 128 Length for Code 128 - 20 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 37 Enable GS1- 128* Disable GS1-128 Set the Minimum Set the Maximum Length for GS1- 128 Length for GS1- 128 - 21 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 38 Restore the Factory Defaults of AIM-128 Enable AIM-128* Disable AIM-128 Set the Minimum Set the Maximum Length for AIM-128 Length for AIM-128 - 22 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 39 In the examples below, the part surrounded by blue dotted line is an EAN-8 barcode while the part circled by red dotted line is add-on code. - 23 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 40 When EAN-8 Add-On Code Required is selected, the engine will only read EAN-8 barcodes that contain add-on codes. EAN-8 Add-On Code Required EAN-8 Add-On Code Not Required * - 24 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 41 Enable EAN-13* Disable EAN-13 3.3.5.1 Transmit Check Digit Transmit EAN-13 Check Do Not Transmit EAN-13 Digit * Check Digit - 25 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 42 Enable 2-Digit Add-On Code Disable 2-Digit Add-On Code * Enable 5-Digit Add-On Code Disable 5-Digit Add-On Code * - 26 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 43 “Add-On Code Required” feature. Do Not Require Add-On Code * Require Add-On Code - 27 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 44 “Add-On Code Required” feature. Do Not Require Add-On Code * Require Add-On Code - 28 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 45 EAN-13 barcodes are handled, depending on your selection for the “Add-On Code Required” feature. Do Not Require Add-On Code * Require Add-On Code - 29 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 46 “Add-On Code Required” feature. Do Not Require Add-On Code * Require Add-On Code - 30 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 47 “Add-On Code Required” feature. Do Not Require Add-On Code * Require Add-On Code - 31 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 48 “Add-On Code Required” feature. Do Not Require Add-On Code * Require Add-On Code - 32 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 49 Do Not Require Add-On Code * Require Add-On Code 3.3.6 ISSN Restore the Factory Defaults of ISSN Enable ISSN Disable ISSN* - 33 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 50 When ISSN Add-On Code Required is selected, the engine will only read ISSN barcodes that contain add-on codes. ISSN Add-On Code Required ISSN Add-On Code Not Required * - 34 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 51: Set Isbn Format

    3.3.7 ISBN Restore the Factory Defaults of ISBN Enable ISBN * Disable ISBN 3.3.7.1 Set ISBN Format ISBN-13* ISBN-10 - 35 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 52 When ISBN Add-On Code Required is selected, the engine will only read ISBN barcodes that contain add-on codes. ISBN Add-On Code Required ISBN Add-On Code Not Required * - 36 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 53 Enable UPC-E * Disable UPC-E 3.3.8.1 Transmit Check Digit Transmit UPC-E Check Do Not Transmit UPC-E Digit * Check Digit - 37 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 54 When UPC-E Add-On Code Required is selected, the engine will only read ISBN barcodes that contain add-on codes. UPC-E Add-On Code Required UPC-E Add-On Code Not Required * - 38 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 55 Enable UPC-E Extend: Extend UPC-E barcodes to make them compatible in length to UPC-A. Enable UPC-E Extend Disable UPC-E Extend * - 39 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 56 Enable UPC-A * Disable UPC-A 3.3.9.1 Transmit Check Digit Transmit UPC-A Check Do Not Transmit UPC-A Digit * Check Digit - 40 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 57 When UPC-A Add-On Code Required is selected, the engine will only read UPC-A barcodes that contain add-on codes. UPC-A Add-On Code Required UPC-A Add-On Code Not Required * - 41 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 58 (“0” for USA), or transmit no preamble. System Character & Country Code System Character * No Preamble - 42 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 59: Interleaved 2 Of

    Set the Minimum Set the Maximum Length for Length for Interleaved 2 of 5 Interleaved 2 of 5 - 43 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 60 Interleaved 2 of 5 barcodes with a total length of 4 characters including the check digit cannot be read.) - 44 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 61 Digit Note: It is advisable not to enable ITF-14 and Interleaved 2 of 5 at the same time. - 45 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 62 Transmit Check Digit Note: It is advisable not to enable ITF-6 and Interleaved 2 of 5 at the same time. - 46 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 63: Matrix 2 Of

    3.3.11.1 Check Digit Verification Do Not Transmit Check Digit After Verification * Transmit Check Digit After Verification Disable - 47 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 64: Industrial 2 Of

    3.3.12.1 Check Digit Verification Do Not Transmit Check Digit After Verification Transmit Check Digit After Verification Disable * - 48 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 65 3.3.13.1 Check Digit Verification Do Not Transmit Check Digit After Verification Transmit Check Digit After Verification Disable * - 49 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 66 3.3.14.1 Check Digit Verification Do Not Transmit Check Digit After Verification Transmit Check Digit After Verification Disable * - 50 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 67: Code 32 Prefix

    “A” to all Code 32 barcodes. Code 32 must be enabled for this parameter to function. Disable Code 32 Prefix * Enable Code 32 Prefix - 51 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 68 Code 32 must be enabled for this parameter to function. Do Not Transmit Code 32 Transmit Code 32 Start/Stop Character * Start/Stop Character - 52 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 69 3.3.16.1 Check Digit Verification Disable * Transmit Check Digit After Verification Do Not Transmit Check Digit After Verification - 53 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 70 ABCD/TN*E as the ABCD/ABCD as the Start/Stop Character Start/Stop Character * Start/Stop Character in Start/Stop Character in Uppercase Lowercase - 54 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 71 3.3.17.1 Check Digit Verification Disable Transmit Check Digit After Verification Do Not Transmit Check Digit After Verification * - 55 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 72 Disable GS1-Databar 3.3.18.1 Transmit Application Identifier “01” Transmit Application Identifier “01” * Do Not Transmit Application Identifier “01” - 56 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 73 Code 11 for Code 11 3.3.19.1 Transmit Check Digit Do Not Transmit Check Transmit Check Digit Digit * - 57 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 74 One Check Digit, MOD11 One Check Digit, MOD11 (Len<=10) (Len<=10) Two Check Digits, Two Check Digits, MOD11/MOD11 (Len>10) MOD11/MOD9 (Len>10) - 58 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 75 3.3.20.1 Check Digit Verification Do Not Transmit Check Digit After Verification * Transmit Check Digit After Verification Disable - 59 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 76 Set the Maximum Length for MSI-Plessey for MSI-Plessey 3.3.21.1 Transmit Check Digit Do Not Transmit Check Transmit Check Digit Digit * - 60 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 77 3.3.21.2 Check Digit Verification One Check Digit, MOD10 * Disable Two Check Digits, Two Check Digits, MOD10/MOD10 MOD10/MOD11 - 61 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 78 Disable JAN Code for Books Books * You may select either of the following ways to transmit JAN barcodes for books. - 62 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 79 Note that the Require Concatenation feature must be enabled for this setting to function. Enable Barcode Disable Barcode Separator Separator * - 63 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 80 Enable PDF 417 * Disable PDF 417 Set the Minimum Length Set the Maximum Length for PDF 417 for PDF 417 - 64 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 81 Default Character UTF-8 Encoding * 3.4.1.3 Enable/Disable PDF417 ECI Output Disable PDF417 ECI Enable PDF417 ECI Output Output * - 65 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 82 Set the Maximum Length for QR Code for QR Code 3.4.2.1 Micro QR Disable Micro QR * Enable Micro QR - 66 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 83: Qr Twin Code

    Default Character UTF-8 Encoding * 3.4.2.4 Enable/Disable QR ECI Output Enable QR ECI Output * Disable QR ECI Output - 67 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 84: Data Matrix

    Enable Rectangular Disable Rectangular Barcode * Barcode 3.4.3.2 Mirror Image Do Not Decode Mirror Decode Mirror Images * Images - 68 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 85: Data Matrix Twin Code

    Data Matrix only. Otherwise, try single Data Matrix only. Single Data Matrix Only * Twin Data Matrix Only Both Single & Twin - 69 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 86 UTF-8 3.4.3.5 Enable/Disable Data Matrix ECI Output Enable Data Matrix ECI Output * Disable Data Matrix ECI Output - 70 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 87: Chinese Sensible Code

    3.4.4.1 Enable/Disable Chinese Sensible Code ECI Output Enable Chinese Sensible Code ECI Disable Chinese Sensible Code Output * ECI Output - 71 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 88: Chapter 4 - Command Settings

    Scan below bar code for batch mode setting Batch Mode 4.1.3 Wedge Scan below bar code for wedge mode setting Wedge Mode - 72 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 89: System Setting

    4.2.2 Display FW version / Data Format Scan below bar code to show the current F/W & BT version FW version - 73 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 90: Auto Power Off

    Scan below bar code to set the time frame for power saving. 5 Seconds 10 Seconds 15 Seconds* 20 Seconds Disable 30 Seconds - 74 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 91: Rf Config

    Scan below bar code to show the current paired device information Paired Device 4.3.2 Remove the pair Scan below bar code to remove pair Remove Pair - 75 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 92: Data & Memory

    Scan【Batch】to switch from Auto Mode to Batch Mode. Data will now be stored in the internal memory of the MS926P and the MS926P will no longer transmit data via RF. Scan below barcode to send data from the MS926P to your host device after collecting the data in Batch Mode.

  • Page 93: Data Sending Block Delay

    Scan below bar code to set the block delay time. Default is 10ms. 10 ms* 50 ms 100 ms 500 ms 1 Sec. 3 Sec. - 77 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 94: Hid Keyboard Character Delay

    Default setting: “auto trace” to have original scanned data transmitted. Auto Trace * To Lower To Upper - 78 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 95 US English * UK English Swiss Swedish Norwegian Italian German French Danish Partial ALT Japanese (OADG109) Spanish ALT Mode - 79 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 96: Beep & Vibration & Indicators

    4.7.1.1 High volume High Volume 4.7.1.2 Medium volume * Medium Volume* 4.7.1.3 Low volume Low Volume 4.7.1.4 Mute Mute - 80 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 97 4.7.4.1 Good Read Indicator Beeper Beeper & Vibrator * Vibrator None 4.7.4.2 Button Indicator Beeper Beeper & Vibrator * Vibrator None - 81 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 98 Beeper Beeper & Vibrator * Vibrator None 4.7.4.6 Power Off Alarm Beeper Beeper & Vibrator * Vibrator None - 82 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 99: Data Terminator

    MS926P User’s Manual 4.8 Data Terminator Scan below bar code to set up terminator. None CRLF - 83 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.

  • Page 100: 1:1 / 1:N Checking Indicators

    4.9.2 1:1/1:N Checking Fail Indicator Scan below bar code to indicate 1:1/1:N Checking Fail. None Beeper & Vibrator * Vibrator Beeper - 84 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
  • Page 101 Disable * 4.9.4 1:1/1:N Checking Screen Indicator Scan below bar code to indicate 1:1/1:N Screen Checking. Enable Disable * - 85 - © 2019 unitech Electronics Co., Ltd. All rights reserved. unitech is a registered trademark of unitech Electronics Co., Ltd.
