Using the magnetic stripe reader

With the idle message displayed, select the desired transaction
type. Insert the card into the card reader slot, with the magnetic
stripe lying in the slot and facing the terminal.
Slide the card in either direction through the slot without stopping.
If the card swipe fails, check the position of the magnetic stripe
and slide the card again. If failure persists, the card's stripe may
be damaged, and user will have to manually enter the account
number on the keypad.
Follow remaining prompts on the display to complete the
transaction. Refer to quick reference guide for details.
Using the
chip card reader
(Optional: Smart card capability must
be enabled. Contact your sales or
customer service representative.)
Find the card reader slot at the front
of the FD130 and insert the card
completely so the microprocessor
chip is no longer visible and the front of the card is facing up.
The card must remain inserted throughout the entire transaction.

Using the contactless reader

The card holder will tap his or her
contactless card or device against the
contactless icon located on the FD130. In
some cases, the device may prompt for a
second tap to complete the transaction.
