Page 1: Operation Manual
All manuals and user guides at all-guides.com Split Type Inverter Room Air Conditioner OPERATION MANUAL MODELS AY-X28MCJ AE-X28MCJ Thank you for selecting SHARP air-conditioner. Please read this manual carefully before operation and keep it for further reference. - Page 2 All manuals and user guides at all-guides.com...
- Page 3 All manuals and user guides at all-guides.com...
- Page 4 All manuals and user guides at all-guides.com...
- Page 5 All manuals and user guides at all-guides.com...
- Page 6 All manuals and user guides at all-guides.com...
-
Page 7: Names And Functions Of Each Part
All manuals and user guides at all-guides.com Names and functions of each part Indoor unit Air in Air out Front panel Filter Guide louver Wall pipe Bind tape Outdoor unit Connection wire Drainage pipe Remote control Air in Air out... - Page 8 All manuals and user guides at all-guides.com Operation of remote control Names and functions of remote control buttons Note: Be sure that there are no obstructions between receiver and remote control; Don't drop or throw the remote control; Don't let any liquid in the remote control and put the remote control directly under the sunlight or any place where is very hot.
- Page 9 All manuals and user guides at all-guides.com Operation of remote control Names and functions of remote control buttons NOTE: This wireless remote control is universal and it could be used for many different models.Some buttons on this remote control are not applicable to this model. TIMER AUTO Timer button...
- Page 10 All manuals and user guides at all-guides.com Operation of remote control Names and functions of remote control buttons NOTE: This wireless remote control is universal and it could be used for many different models. Some buttons on this remote control are not applicable to this model. X-FAN X-FAN button Press this button to select or cancel X-FAN...
- Page 11 All manuals and user guides at all-guides.com...
- Page 12 All manuals and user guides at all-guides.com Operation of remote control When AUTO RUN is selected, the set temperature will not be displayed on the LCD. The unit senses the room temperature automatically to select a suitable running method for room comfort. When TURBO mode is selected the unit will run at super-high fan speed to cool or heat quickly so that the ambient temperature approaches the preset temperature as soon as possible.
- Page 13 All manuals and user guides at all-guides.com...
- Page 14 All manuals and user guides at all-guides.com...
- Page 15 All manuals and user guides at all-guides.com...
- Page 16 All manuals and user guides at all-guides.com...
- Page 17 All manuals and user guides at all-guides.com...
- Page 18 All manuals and user guides at all-guides.com...
- Page 19 All manuals and user guides at all-guides.com...
- Page 20 All manuals and user guides at all-guides.com...
-
Page 21: Installation Dimension Diagram
All manuals and user guides at all-guides.com Installation dimension diagram Installation dimension diagram Installation dimension diagram Space to the ceiling Above 15cm Above 15cm Above Space to the wall Space to the wall cm cm Above Above Air outlet side Space to the floor Space to the obstruction Air inlet side... - Page 22 All manuals and user guides at all-guides.com and leveled to ensure correct drainage.
-
Page 23: Installing The Indoor Unit
All manuals and user guides at all-guides.com Installing the indoor unit... -
Page 24: Installing The Outdoor Unit
All manuals and user guides at all-guides.com Installing the Outdoor Unit... - Page 25 All manuals and user guides at all-guides.com Installing the Outdoor Unit...
- Page 26 All manuals and user guides at all-guides.com...
-
Page 27: Specifications
All manuals and user guides at all-guides.com Specifications Model AY-X28MCJ; AE-X28MCJ Function COOLING HEATING Rated Voltage 220-240 V Rated Frequency 50Hz Total Capacity (Min Max) (W) 8000(2100 8400) 8400(1800 9300) Power Input (Min Max) (W) 2660(650 3200) 2860(600 3500) 3500 Rated Input (W) Rated Current (A) 15.53... - Page 28 All manuals and user guides at all-guides.com Outdoor Compressor MITSUBISHI Unit Manufacturer/trademark Compressor Model TNB220FLHMC Compressor Type Rotary L.R.A. (A) Compressor RLA(A) Compressor Power Input(W) 2200 Overload Protector CS01F272H01 Throttling Method Capillary Defrosting Method Automatic Defrosting Operation temp Range ( ) -7 C 43 C Condenser Aluminum fin-copper tube...
- Page 29 All manuals and user guides at all-guides.com...
