In the Hardware Setup window, the "Output Trim" settings are irrelevant to the Delta-Link MADI HD because its inputs and
outputs are all digital. Therefore, they can be used to set various Alpha-Link parameters as follows:
Channel Number
1
2
3
4
The 56/28/14 channel MADI mode of the Delta-Link MADI HD does not currently support varispeed operation whilst the
64/32/16 channel MADI mode for any unit can only run at fixed rate. In both modes the Delta-Link MADI HD unit's tolerance
for sample rate variation is ±0.5%.
20
All manuals and user guides at all-guides.com
Parameter
Number of MADI channels
MADI NFS mode
MADI DFS/QFS mode
WordClock input
If "A" is selected
If "B" is selected
56/28/14
Normal
SMUX
WordClock
(48kHz /44.1kHz)
64/32/16
Special
High Speed
FrameClock
