3. Installation
The Delta-Link MADI HD package includes:
• The Delta-Link MADI HD unit.
• 2 of 0.9m (35") DigiLink cables.
• The mains connection cable.
• This manual.
NOTE: The maximum allowable length of cables required to connect the Digidesign
(DigiLink cables) varies as follows according to the sample rate being used:
• 48 kHz operation: 1.8m (70")
• 96 kHz operation: 0.9m (35")
• 192 kHz operation: 0.45m (18")
If required, Delta-Link MADI HD can be rackmounted. It occupies 1U of rack space in a standard 19-inch rack.
It is assumed that your Pro Tools
8
All manuals and user guides at all-guides.com
HD system is already installed in the host computer (Windows PC or Mac OS X).
®
cards to the Delta-Link MADI HD
®
