CHIEF MSB-6309 Installation Instructions

Display mounting bracket
Hide thumbs
1
2

Advertisement

Table of Contents

If you are missing any of the following components, please contact Customer Service at 1-800/582-6480.
(2) Interface Side Brackets
(4) Mounting Buttons – Tapped
(4) M6 x 35mm Phillips Head Cap Screws
(1) 1/8" Allen Key
BEFORE PROCEEDING, READ INSTALLATION INSTRUCTIONS COMPLETELY
CAUTION!
NOTE: If installing screen on a Chief J-series wall mount, proceed to Step 3 (J-Series VESA Interface Installation).
Chief Q-latch Button Installation (Used with MSR, MTR, MWH, MWR, MCS and MCD mounts): Using a
1.
10-24 button head cap screw inserted from back side of bracket, secure mounting button, with chamfered hole of
mounting button (larger surface) facing bracket, to center brackets (four places) (see Figure 2 and Figure 3).
Proceed to Step 4 (Side Bracket Assembly).
2.
CHIEF MANUFACTURING INC. 1-800-582-6480, Fax: 1-877-894-6918, Email: chief@chiefmfg.com
INSTALLATION INSTRUCTIONS
MSB-6309
DISPLAY MOUNTING BRACKET
Prior to assembly, unpack carton completely and verify contents.
DISPLAYS ARE EXTREMELY FRAGILE.
Figure 2
Figure 1
(2) Interface Center Brackets
(8) 10-24 x .5" Button Head Cap Screws
(4) .500 x .257 x .625 Nylon Spacers
Figure 3
8840-000048 RevB
10/18/05
