CHIEF MSB-6053 Installation Instructions

I N S T A L L A T I O N I N S T R U C T I O N S
(2) Interface Side Brackets
(4) Mounting Buttons – Tapped
(4) M8 x 65mm Hex Head Cap Screws
(4) M8 Flat Washers
(1) 1/8" Allen Key
BEFORE PROCEEDING, READ INSTALLATION INSTRUCTIONS COMPLETELY
CAUTION!
WARNING!
NOTE: If installing screen on a Chief J-series wall mount, proceed to Step 3 (J-Series VESA Interface Installation).
1. Chief Q-latch Button Installation (Used with MSR, MTR, MWH, MWR, MCS and MCD mounts):
Using a 10-24 button head cap screw inserted from back side of bracket, secure mounting button, with
chamfered hole of mounting button (larger surface) facing bracket, to center brackets (four places) (see
Figure 2 & Figure3).
2. Proceed to Step 4 (Side Bracket Assembly).
MSB-6053
DISPLAY MOUNTING BRACKET
Prior to assembly, unpack carton completely and verify contents.
DISPLAYS ARE EXTREMELY FRAGILE.
ALL COMPONENTS MUST BE SECURELY FASTENED TO A
STRUCTURAL MEMBER CAPABLE OF SUPPORTING 4 TIMES
THE COMBINED WEIGHT OF ALL COMPONENTS PLUS THE
EQUIPMENT BEING MOUNTED. IF IT CANNOT SUPPORT
THIS WEIGHT, THE STRUCTURE MUST BE REINFORCED.
THE MAXIMUM WEIGHT TO BE INSTALLED ON THE
INTERFACE IS 125 POUNDS (79.38 KG).
Figure 2
