GRANDIO
®
G R E E N H O U S E S
GRANDIO ELITE 8x12, 8x16, 8x20, 8x24 KIT MANUAL
INCLUDES INSTRUCTIONS FOR BACK DOOR TRANSFORMATION
STOP
This manual is for
8x12, 8x16, 8x20 & 8x24.
Grandio Elite 8x24 Shown In Image
If building an 8x8 with
GREENHOUSE USER MANUAL
no extensions refer to
that manual.
© 2013 Grandio Greenhouses, Backyard Living Source Inc. All rights reserved
April 15, 2016 Manual Edition Extendable Greenhouses

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELITE 8x12 and is the answer not in the manual?

Questions and answers

Related Manuals for Grandio ELITE 8x12

Summary of Contents for Grandio ELITE 8x12

  • Page 1 8x12, 8x16, 8x20 & 8x24. Grandio Elite 8x24 Shown In Image If building an 8x8 with GREENHOUSE USER MANUAL no extensions refer to that manual. © 2013 Grandio Greenhouses, Backyard Living Source Inc. All rights reserved April 15, 2016 Manual Edition Extendable Greenhouses...
  • Page 2 City or Municipality ordinances and HOA’s, as you may need a permit or documentation before you build. CONTACT OUR CUSTOMER SERVICE DEPARTMENT at: Contact your insurance company to make sure your Grandio Greenhouse will be covered on your policy. 1-866-448-8231 Call your local utilities companies before digging.

  • Page 3: Safety Instructions

    Before beginning assembly, read the instruc- tions and identify all parts using the hardware identifier and parts list on pages 68-78. Complete assembly and proper usage are essential to reduce the risk of accident or injury when using your Grandio Greenhouse. CAUTION:...

  • Page 4: Table Of Contents

    ASSEMBLY INSTRUCTION STEPS Introduction................1 Safety Instructions..............2 Prepare For Assembly............4 Box Con gurations ...............5 PREPARE FOR ASSEMBLY Diagrams of Assembled Grandio Elite Sizes 8x8, 8x12, 8x16, 8x20, 8x24......6-10 Base Kit Assembly Information........11 STEP ONE: BASE ASSEMBLY Base Kit Parts Lists............12-13 8x12 Base Kit................14 8x16 Base Kit................15...

  • Page 5: Base Kit Assembly Information

    PREPARE FOR GREENHOUSE ASSEMBLY IMPORTANT: BASE KIT ASSEMBLY & GREENHOUSE PLACEMENT 8X12 GRANDIO ELITE BARN STYLE Before assembling your new greenhouse, a proper GREENHOUSE DIMENSIONS foundation must be prepared. A number of anchor- ing options are acceptable, based on wind and ground conditions in your area.
  • Page 6 *See the reference diagrams on pages 6-10 for more information about how the parts will go together and what makes up each section for the assembly. If building a back door you will follow the instructions in the manual, the parts for the transformation are in box GRA-ELI-BD. GRANDIO ELITE 8X16 GRANDIO ELITE 8X12 Elite 8’x8’ Elite 8’x8’...
  • Page 7 BACK DIAGRAM SHOWS THE ASSEMBLED L08A BA-S1 (8’x8’ BASIC CONFIGURATION) (GRA-ELI-8A & GRA-ELI-8P & GRA-BAS-8) 606-WS 606-WS 606-WS 606-WS 8x8 ELITE KIT INCLUDES, FRONT, L08B-X L08B-X BACK, BASE AND SIDES. 601A-B 601A-B Outside View L08B 603C 603C 603C 603C 601A-B 601A-B 602D 602D...
  • Page 8 (8’x8’ Original Kit) (GRA-ELI-8A & GRA-ELI-8P & GRA-BAS-8) Elite 4’ Side Extension 8x8 Elite Includes Front, Back, Base, and Sides Includes Base DIAGRAM SHOWS THE ASSEMBLED 8X12 GRANDIO ELITE THE BOX CONFIGURATION IS AN ELITE 8X8 PLUS A 4 FOOT EXTENSION KIT Outside View...
  • Page 9 (8’x8’ Original Kit) (GRA-ELI-8A & GRA-ELI-8P & GRA-BAS-8) Elite 8’ Side Extension includes Base 8x8 Elite Includes Front, Back, Base, and Sides DIAGRAM SHOWS THE ASSEMBLED 8X16 GRANDIO ELITE THE BOX CONFIGURATION IS AN ELITE 8X8 PLUS AN 8 FOOT EXTENSION KIT Outside View...
  • Page 10 Elite 8’ Side Extension includes Base 8x8 Elite Includes Front, Back, Base, and Sides Includes Base DIAGRAM SHOWS THE ASSEMBLED 8X20 GRANDIO ELITE THE BOX CONFIGURATION IS AN ELITE 8X8 PLUS AN 8 FOOT AND A 4 FOOT EXTENSION KIT Outside View...
  • Page 11 Elite 8’ Side Extension includes Base Elite 8’ Side Extension includes Base 8x8 Elite Includes Front, Back, Base, and Sides DIAGRAM SHOWS THE ASSEMBLED 8X24 GRANDIO ELITE THE BOX CONFIGURATION IS AN ELITE 8X8 PLUS (2) 8 FOOT EXTENSION KITS Outside View...
  • Page 12 BASE KIT ASSEMBLY INSTRUCTIONS Pre-Plan The Placement Of Your Structure Allow enough room to get a wheel barrow in and around your structure. Be sure the orientation will allow for proper drainage in and around your greenhouse. It is recommended that you place your greenhouse in an area of your property that receives the most sunlight but is also somewhat protected by trees, fencing or your home for wind protection and also to keep the temperature up during early spring and late fall.

  • Page 13: Base Kit Parts Lists

    BASE KIT PARTS LIST 8X8 BASE KIT PARTS WILL BE FOUND IN PARTS WILL BE FOUND IN (GRA-ELI-4X) BOX (GRA-BAS-8) BOX FOR THE 4’ EXTENSION BASE KIT GRAPHIC PART NAME SIZE/LOCATION QUANTITY GRAPHIC PART NAME SIZE/LOCATION QUANTITY 97 3/8 in / 2474 mm BA-S1 BA-S5 46 3/4 in / 1187 mm...

  • Page 14: Base Kit Parts Lists

    BASE KIT PARTS LIST PARTS WILL BE FOUND IN (GRA-ELI-8XA) BOX FOR THE 8’ EXTENSION BASE KIT GRAPHIC PART NAME SIZE/LOCATION QUANTITY BA-S3 93 7/16 in / 2374 mm 93 7/16 in / 2374 mm BA-S4 BA-C4 8 7/16 in /214 mm BA-S10 1/2 X 3/4 M6*14...

  • Page 15: 8X12 Base Kit

    ANCHOR BA-C3 HOLE FOR ANCHOR BA-C3 BA-S1 Note that the holes for GRANDIO T I P screws on the base kit HOLE FOR ANCHOR sides have about a 2 foot gap between each, so be sure base kit extensions are assembled properly. See...

  • Page 16: 8X16 Base Kit

    BA-S2 ANCHOR BA-S10 BA-C4 BA-C3 BA-S1 Note that the holes for GRANDIO T I P screws on the base kit HOLE FOR sides have about a 2 foot gap between ANCHOR each, so be sure base kit extensions are assembled properly. See...

  • Page 17: 8X20 Base Kit

    BA-C3 HOLE FOR HOLE FOR ANCHOR ANCHOR Note that the holes for BA-S10 GRANDIO BA-C3 T I P screws on the base kit BA-C4 BA-S1 sides have about a 2 foot gap between each, so be sure base kit extensions...

  • Page 18: 8X24 Base Kit

    BA-S2 HOLE FOR ANCHOR HOLE FOR BA-C3 ANCHOR HOLE FOR Note that the holes for HOLE FOR GRANDIO T I P ANCHOR ANCHOR screws on the base kit BA-S10 BA-C3 BA-C4 BA-S1 sides have about a 2 foot gap between each, so be sure base kit extensions are assembled properly.
  • Page 19 BASE KIT ASSEMBLY INSTRUCTIONS Slide the BA-C3 into the BA-S1, slide the BA-S2 into the BA-C3, align the holes and push together to an even and tight position and use the BA-S03 Bolt and ML01 Collard Nut combo, tighten the collard nut on the inside of the base kit using the 10mm wrench.
  • Page 20 See www.GrandioGreenhouses.com for anchoring kit options. Outdoor Ground Assembly BA-S1 BA-S2 Make sure base is squared GRANDIO T I P and level before setting BA-S03 anchor into concrete. Use a measuring tape BA-A1 * Must be inserted to ensure all corners are the same. Use level...
  • Page 21 If surface is uneven you may want Make sure base is squared GRANDIO T I P to purchase large washers that and level before setting will fit under the base and allow anchors.
  • Page 22 We recommend watching GRANDIO T I P our how to assembly videos 603E Y3-1 Y3-2 with tricks and tips for easier assembly and installation of your Grandio Greenhouse at: www.grandiogreenhouses.com 601B 601B 603D Lay at on ground to GRANDIO T I P...
  • Page 23 . Note: the fat end of the WG02 will always be on the bottom side Inside View PRETHREAD SCREWS TIP: GRANDIO T I P IMPORTANT: Use only S05 Screws, other screws may damage frame. Locate all WG01, WG02, and S05 screws, pre thread these to make installation easier.
  • Page 24 UV coating. Always use gloves when handling the polycarbonate panels as the edges can be very sharp. BOLT INSTALLATION TIP: GRANDIO W04-1 T I P Transparent Clear Film Locate ML01/S04 nuts and...
  • Page 25 601A-B’s to match the front wall, these holes OUTSIDE INSIDE should face the ground during assembly. BOLT INSTALLATION TIP: GRANDIO T I P Locate all nuts and bolts, pre thread and place in the groove of the extrusion to make installation easier. Move up or down for exact placement.
  • Page 26 Y1 panels, then tighten fasteners. See 2.11 Insert the Y2-2 and Y2-1 polycarbonate panels as shown in Y2-2 Y2-1 603C L08D GRANDIO Transparent Clear Film S04/ L08D L08D T I P ML01 L08D Outside Greenhouse...
  • Page 27 FRONT FRAME ASSEMBLY CONTINUED ALWAYS ASSEMBLE FRONT HORIZONTAL 2.12 Move roof and front section together and align the WG02’s into the 601A’s, and the W04-2’s into the 604’s. Insure a snug t WG02 601B WG02 WG02 between the WG02’s, 601B’s and 601A’s and then tighten the S05 screws as shown in 601A-FR Tighten the W04-2’s with the S04 /ML01 nut...
  • Page 28 We recommend that you assemble the back wall on a tarp. * If you are using the Back Door Transformation Kit you will skip this section. Inside View 601B 601B 601B WG02 WG02 WG01 GRANDIO Transparent Clear Film T I P Outside Greenhouse 601B 601B Y5-2 Y5-1 Polycarbonate...
  • Page 29 WG01 Inside View 601B 601B WG02 WG02 PRETHREAD SCREWS TIP: GRANDIO T I P Locate all WG01, WG02, and S05 screws, loosely pre thread these to 601B 601B make installation easier. Note that the fat end on the WG02 will always face down.
  • Page 30 BACK CONTINUED ALWAYS ASSEMBLE BACK HORIZONTAL Attach (2) 601A-B’s to L08A using S04/ML01 fastener as shown in diagram Attach (2) 602D’s to L08A using S04/ML01 fasteners as shown in diagram Attach 602C to L08A using S04/ML01 fastener as shown in diagram Attach the (4) 606-WS’s to the L08A as shown 601A-B 602D...
  • Page 31 BACK CONTINUED ALWAYS ASSEMBLE BACK HORIZONTAL Set (4) 603C’s atop each Y-1 panel, then align the pre threaded S04-ML01 fasteners in each 603C to the L08B and to each 601A-B, 602D and the 602C. When aligned tighten the middle rst and work your way outward.
  • Page 32 Y4-2 Y4-1 601A-B 601A-B WG02 BOLT INSTALLATION TIP: GRANDIO T I P Locate all nuts and bolts, pre thread and place in the groove of the extrusion to make installation easier. Move Inside View up or down for exact placement.
  • Page 33 602D 602D S04/ML01 602D L08B-X L08A Inside View L08B-X L08B-X ML01 601A-B 601A-B Square by loosening bolts GRANDIO T I P attached to the tops of the L08B-X, use measuring tape to make sure corner to corner measures the same.

  • Page 34: Middle Assembly

    601A configured of more base kit pieces. BA-S2 601A You will need a minimum of GRANDIO T I P (2) people to complete the middle assembly of your greenhouse. The BA-S1 more people the merrier at this stage of...
  • Page 35 MIDDLE ASSEMBLY CONTINUED with the nut and bolt Attach L08C-X to 601A and the BA-S2 with S04/ML01 on both sides as shown in combos. Attach the front section 619 to the base using (3) S10/ML02 fasteners as shown in , then attach the threshold support 619-BAR to the inside of the 619 with (5) S19 self tapping screws included in the package, see 601B 601A...
  • Page 36 MIDDLE ASSEMBLY CONTINUED Have person (1) continue to hold the front vertically while the other attaches the font section to the base with W05/S04/ML01 fasteners as shown in . The (4) W05 clips will catch the under edge of the front base kit and then slide upward attaching to the bottom of the 601A’s and the 604’s.

  • Page 37: Back Wall Assembly

    MIDDLE ASSEMBLY CONTINUED If you are using the Back Door Transformation kit you will repeat steps 4.1-4.5 to install the Back Door Wall, then skip ahead to step 4.9. Attach back wall 601A’s with back base corners using S04/ML01 on both sides as shown in Attach bottom of L08C-X to rear section of base kit with S04/ML01, as shown in .
  • Page 38 DP01 then insert the S06 screws. 607-XS For 8x20 and 8x24 Grandio Elite Assembly DP01 Repeat these steps if you are building an 8x20 or 8x24 with your last extension box, note it is best to connect 8x8, then 8X, then a 4X if assembling an 8x20.
  • Page 39 MIDDLE ASSEMBLY CONTINUED 4.11 With 2 people, attach the ridge to front and back by sliding into place as Side Angle View shown in , using S04/ML01 fasteners attach the 607 to the 601B’s. for how the nal orientation should be. 601B 601B Inside View...

  • Page 40: Extension Assembly

    8x12 or 8x16 Greenhouse, or for an 8x20 or 8x24 Greenhouse page 50. Note it may be helpful to have a few more people at this point the more the merrier. BOLT INSTALLATION TIP: GRANDIO T I P Locate about 30 nuts and...
  • Page 41 EXTENSION ASSEMBLY INSTRUCTIONS Connect the (2) braces labeled L08M-X together with the nut and L08M-X W14 BRACKET bolt combo S04/ML01 see . The combined L08M-X’s should measure about 94 1/2” when connected together. L08M-X Attach the 602A to the base with a nut and bolt combo where the extension kits meet on the base kit, with other person holding the 602A in place.
  • Page 42 EXTENSION ASSEMBLY INSTRUCTIONS Attach the 609-XS to 609 with the (2) S09 screws provided INSIDE VIEW . The S09 screws are to be installed from the outside of the 609, see 609-XS Pay special attention to the orientation of the 609, make sure the correct side faces down, see Profile View OUTSIDE VIEW...
  • Page 43 601B’s and the 601A’s when installed correctly. 601A 601A L08C-X You will need a minimum of GRANDIO T I P (2) people to complete the middle assembly of your greenhouse. The more people the merrier at this stage of assembly.
  • Page 44 EXTENSION ASSEMBLY INSTRUCTIONS 4. Note the top of 602A should touch the line on the 609 for exact placement, see . Attach the 609 to the 602A with the S04/ML01 nut and bolt combos see diagram 5. Repeat steps 1-4 on the other side see NOTE EXACT PLACEMENT OF THE 602A TO THE 609.
  • Page 45 EXTENSION ASSEMBLY INSTRUCTIONS Moving up to the midroof 609, with person 1 holding the 609 in place person 2 will attach the 609 to the front of the greenhouse to the 601B’s, see . Person 1 will continue holding the 609. .
  • Page 46 EXTENSION ASSEMBLY INSTRUCTIONS With two people attach the AZ-1 to W17 and the base and the lower 602A, see 601B . Next attach the upper end to the mid roof line touching the 609 see for exact placement. Install on both sides of the greenhouse where the extension seams meet using the S02/ML01 combo.
  • Page 47 2nd EXTENSION ASSEMBLY INSTRUCTIONS CONTINUE FOR 8X20 AND 8X24 ONLY / FOR 8X12 AND 8X16 SKIP AHEAD TO PAGE 51 OR STEP 5.19 5.10 Connect the (2) braces labeled L08M-X together with the nut and L08M-X L08M-X bolt combo S04/ML01 see .
  • Page 48 2nd EXTENSION ASSEMBLY INSTRUCTIONS CONTINUE FOR 8X20 AND 8X24 ONLY / FOR 8X12 AND 8X16 SKIP AHEAD TO PAGE 51 OR STEP 5.19 5.13 Attach the 609-XS to 609 with the (2) S09 screws provided INSIDE VIEW . The S09 screws are to be installed from the outside of the 609, see 609-XS Pay special attention to the orientation of the 609, make...
  • Page 49 2nd EXTENSION ASSEMBLY INSTRUCTIONS CONTINUE FOR 8X20 AND 8X24 ONLY / FOR 8X12 AND 8X16 SKIP AHEAD TO PAGE 51 OR STEP 5.19 5.14 With 2 people proceed to install 609 extension at the eave GAP FOR SCREWS or lower mid roof in this order. 609-8X-L 1.
  • Page 50 2nd EXTENSION ASSEMBLY INSTRUCTIONS CONTINUE FOR 8X20 AND 8X24 ONLY / FOR 8X12 AND 8X16 SKIP AHEAD TO PAGE 51 OR STEP 5.19 5.15 With person 1 holding the 609 in place person 2 will attach the 609 to the 609-XS with the (2) S09’s screws to the upper mid roof see .
  • Page 51 2nd EXTENSION ASSEMBLY INSTRUCTIONS CONTINUE FOR 8X20 AND 8X24 ONLY / FOR 8X12 AND 8X16 SKIP AHEAD TO PAGE 51 OR STEP 5.19 5.17 With two people attach the AZ-1 to W17 with the base and the lower 602A, see .
  • Page 52 MIDDLE BACK ASSEMBLY INSTRUCTIONS 5.19 With two people attach the 609 extension to 609-XS with the INSIDE VIEW Inside View (2) S09 screws provided see 601B 5.20 With person 2 still holding in place have person 1 loosen the L08C-X nut and bolt combo, allow to fall out of place, then align the 609 into place with the 601B and 601A, see .
  • Page 53 MIDDLE ASSEMBLY INSTRUCTIONS CONTINUED 5.21 Before you attach the 602A’s to the sides 602A Inside View of the greenhouse you will need to loosen the ML01 (nut) attached to the L08C-X and the 602A base. See diagram . Remove and set aside ML01/S04 ML01/S04 the L08D-X supports.
  • Page 54 602B Do Not attach lower roof 602B’s yet, they will get in your way when installing the upper roof panels and roof vents. 602B ML01 GRANDIO Transparent Clear Film T I P Outside Greenhouse Polycarbonate Opal White Film Inside Greenhouse...
  • Page 55 MIDDLE ASSEMBLY INSTRUCTIONS CONTINUED 5.23 Insert Y11 panels to upper roof section then slide the 630 into the groove of the upper 609 as 601B 630-4X-L shown to hold Y11’s in place. See . Note 602B that you may need to loosen the bottoms of some of 602B the 602B’s to slide the 630’s into place as the t is 602B...
  • Page 56 Inside Outside View 602B Screwdriver Place roof windows in GRANDIO T I P desired location before attaching all 602B’s. Note the 8x12 has 3 windows, an 8x16 has 4 windows, an 8x20 has 5 windows and an 8x24 has 6 windows.
  • Page 57 MIDDLE ASSEMBLY INSTRUCTIONS CONTINUED 5.26 Attach all remaining 602B’s between the 609’s, after all roof vents are positioned see 5.27 Install plastic strip 606-WS before inserting polycarbonate sheet Y7’s, see 5.28 After Y7’s are installed on both sides, loosen bolts attached to L08C-X in all upper corners. Using a level, adjust 602A and tighten bolts.
  • Page 58 MIDDLE ASSEMBLY INSTRUCTIONS CONTINUED 5.29 To ensure there is no gap in roof vent Inside view of 603C position 603C as shown in . Connect 603C 603C to middle of 602B’s using W04 bracket as shown in 603C 602B 5.30 Attach HQC01 to 616 with the Z04 screws see , close roof vent and attach...
  • Page 59 MIDDLE ASSEMBLY INSTRUCTIONS CONTINUED 5.31 Remove the L08M-X support combo, take apart and install on the sides of the AZ1 extension brace, as shown in . Save the hardware and W14 bracket for 601B possible future use or hang inside as a plant hanger clip. 5.32 Insert polycarbonate sheets Y8’s and Y9’s into the L08M-X...
  • Page 60 MIDDLE ASSEMBLY INSTRUCTIONS CONTINUED 5.34 Apply a small amount of the silicone caulk to the seam 610-8X-L where the 610 gutters meet, then attach the DP02 on the inside of the gutter and the DP02B will slide under the gutter and will DP02 rest above the 602A.
  • Page 61 MIDDLE ASSEMBLY INSTRUCTIONS CONTINUED 4.25 Attach JG01, JG02A, JG02B, JG03A and JG03B end caps to the ridge, midroof and gutters on both front and back as shown below. Use Z03 screws to attach the JG03A and JG03B endcaps along with the silicone adhesive. Use Z06 screws to fasten end caps through the WG01 and WG02 as shown in images.
  • Page 62 DOOR ASSEMBLY DIAGRAM This image shows the inside view of Right Door Assembly. All parts for door assembly will be found in box GRA-ELI-8A and GRA-ELI-8P. Use the #2 head Phillips Screw Driver for installation. If you are using the Back Door Transformation kit you will repeat steps 6.1-6.11 to install the Back Door, these parts will be found in box GRA-ELI-BD.

  • Page 63: Door Assembly

    Side View 623B 623B 623B Inside View Bottom GRANDIO Transparent Clear Film View T I P Outside Greenhouse J08A J08A Polycarbonate Opal White Film...
  • Page 64 DOOR ASSEMBLY CONTINUED Insert J08A into the bottom of the 622-R and 622-L, note the bottom has a groove see Attach the 622-L to the 623B, 623A and 620 using the Z01 screws as shown in Follow the same instructions for the other door making sure that the 622-L and 622-R with the double ball and catch match up so doors will latch closed and slide properly 623A 622-R...
  • Page 65 DOOR INSTALLATION Slide the (2) S02 bolts down the track of the L21 see , align with the holes on the 603D door header. With one person inside the greenhouse line up hanging door track L21 with door header 603D, move bolts on L21 to line up with bolt holes on door header 603D.
  • Page 66 , and **We included some felt dots in your Grandio Welcome Kit, please apply to the inside bottom edge of the 623B as shown in these felt dots will make your doors t snug and slide smoothly. Bottom...
  • Page 67 DOOR INSTALLATION 6.10 Attach L28 to L21 with S04/ML01, and L28 to 601A with WASHER and S02/ML01 as shown below 603D in diagram . Check that the L21 and L28’s are square. Attach (2) J07 to the ends of L21 see The L28 should align square to the 601A.

  • Page 68: Interior Roof Supports

    INTERIOR ROOF SUPPORT ASSEMBLY Attach the L08E-X to the upper roof section as shown with S04/ML01 fasteners already in BZ-1 place where the 607 meets the 601B, and the 609 and the 602B meet see , repeat this on the front section of the greenhouse, and where extensions meet at the AZ-1.
  • Page 69 (GRA-ELI-8A) 8x8 GRANDIO ELITE ALUMINUM PACKING LIST GRAPHIC PART NAME SIZE/LOCATION QUANTITY GRAPHIC PART NAME SIZE/LOCATION QUANTITY 70 3/4 in / 1797 mm 56 9/16 in / 1437 mm 604-R 601A-B FRONT RIGHT BACK CORNERS 56 9/16 in / 1437 mm...
  • Page 70 (GRA-ELI-8A) 8x8 GRANDIO ELITE ALUMINUM PACKING LIST GRAPHIC PART NAME SIZE/LOCATION QUANTITY GRAPHIC PART NAME SIZE/LOCATION QUANTITY AZ-1 / W17 86 1/4 in / 2190 mm L08D 24 3/16 in / 614 mm S02/ML01 EXTENSION SUPPORT L08A-X 52 1/4 in / 1327 mm...
  • Page 71 (GRA-ELI-8A) 8’x8’ GRANDIO ELITE ALUMINUM PACKING LIST GRAPHIC PART NAME SIZE/LOCATION QUANTITY GRAPHIC PART NAME SIZE/LOCATION QUANTITY JG01 622-HNDL DOOR HANDLES RIDGE END CAP 622-HNDL JG02 A/B DOOR HARDWARE MID ROOF END CAP NUT/BOLT JG03 A/B 21 7/16 in / 545 mm...
  • Page 72 (GRA-ELI-8P) 8’x8’ ELITE PANEL BOX PACKING LIST GRAPHIC NAME SIZE/LOCATION WIDTH HEIGHT 1 HEIGHT 2 22 3/4 in / 578 mm 47 5/16 in / 1202 mm FRONT & BACK PANEL Y2-1 FRONT PANEL 22 3/4 in / 578 mm 9 1/16 in / 230 mm 23 in / 585 mm Y2-2...
  • Page 73 (GRA-ELI-4X) ELITE 4’ EXTENSION ALUMINUM PACKING LIST GRAPHIC PART NAME SIZE/LOCATION QUANTITY GRAPHIC PART NAME SIZE/LOCATION QUANTITY 56 9/16 in / 1437 mm 610-4X-R 602A 46 3/4 in / 1187 mm 610-4X-L 29 7/16 in / 748 mm 602B DP02 GUTTER BRACKET 21 7/8 in / 555 m 603C...
  • Page 74 (GRA-ELI-4X) ELITE 4’ EXTENSION ALUMINUM PACKING LIST GRAPHIC PART NAME SIZE/LOCATION QUANTITY M5*8 SCREW FOR DP02 AND DP02B M6*16 ATTACHES 607-XS TO 607 M4*6 ATTACHES 609-XS TO 609 CONNECTOR FOR 603C L08M-X BRACKET HQC01 ROOF VENT ARM HQC02 ROOF VENT LATCH Z04, S04/ML01 4 EACH ROOF VENT HARDWARE...
  • Page 75 (GRA-ELI-4X) ELITE 4’ EXTENSION PANEL BOX PACKING LIST GRAPHIC NAME SIZE/LOCATION WIDTH HEIGHT 1 HEIGHT 2 SIDE WALL PANEL 22 3/4 in / 578 mm 57 in / 1447 mm ROOF PANEL 22 3/4 in / 578 mm 30 5/8 in / 778 mm UNDER ROOF VENT 22 3/4 in / 578 mm 8 7/8 in / 225 mm...
  • Page 76 (GRA-ELI-8XA) ELITE 8’ EXTENSION ALUMINUM PACKING LIST GRAPHIC PART NAME SIZE/LOCATION QUANTITY GRAPHIC PART NAME SIZE/LOCATION QUANTITY 610-8X-R 56 9/16 in / 1437 mm 602A 93 7/16 in / 2374 mm 610-8X-L 29 7/16 in / 748 mm 602B GUTTER BRACKET DP02 21 7/8 in / 555 m 603C...
  • Page 77 (GRA-ELI-8XA) 8X GRANDIO ELITE ALUMINUM PACKING LIST GRAPHIC PART NAME SIZE/LOCATION QUANTITY M5*8 SCREW FOR DP02 AND DP02B M6*16 ATTACHES 607-XS TO 607 M4*6 ATTACHES 609-XS TO 609 CONNECTOR FOR 603C L08M-X BRACKET HQC01 ROOF VENT ARM HQC02 ROOF VENT LATCH...
  • Page 78 (GRA-ELI-8XP) GRANDIO ELITE 8 EXTENSION PANEL BOX PACKING LIST GRAPHIC NAME SIZE/LOCATION WIDTH HEIGHT 1 HEIGHT 2 SIDE WALL PANEL 22 3/4 in / 578 mm 57 in / 1447 mm ROOF PANEL 22 3/4 in / 578 mm 30 5/8 in / 778 mm...
  • Page 79 (GRA-ELI-BD) GRANDIO ELITE BACKDOOR PACKING LIST GRAPHIC PART NAME SIZE/LOCATION QUANTITY GRAPHIC PART NAME SIZE/LOCATION QUANTITY M4*30 72 3/16 in / 1833 mm 603D SCREWS FOR DOORS BACK WALL 18 1/4 in / 463 mm M6*10 603E S04/ML01 BACK WALL...

  • Page 80: Warranty

    Grandio Greenhouse Limited Lifetime Warranty 1. Grandio Greenhouses are warranted to the original purchaser to be free from defects in material or workmanship for ten years from the date of original retail purchase on all plastic panels. Additionally the aluminium frame is warranted for life. The word “defects” is de ned as imperfections that impair the use of the product.
  • Page 81 NOTES NOTES...
  • Page 82 GRANDIO ® G R E E N H O U S E S Grandio Elite 8x12, 8x16, 8x20 & 8x24 Models GREENHOUSE USER MANUAL KEEP IN A SAFE PLACE FOR REFERENCE CONTACT US IF YOU NEED HELP HAVE MISSING OR DAMAGED PARTS GRANDIOGREENHOUSES.COM...
