Arlight SR-2833K8 Product Data

RF Single Color Remote Controller
Important: Read All Instructions Prior to Installation

Function introduction

Click to turn on of all zones
Note:Before the first use, please remove the protective film on the battery.
09.283K8.04271
Click to turn off of all zones
Each button controls one zone of
receiver separately, Click to turn on/off,
Press and hold down to increase/
decrease light intensity
Front side
Back side
Product Data
Output
RF signal

Operation Frequency

869.5/916.5/434MHz

Power Supply

3V(1xCR2025 battery)

Operating temperature

0-40°C

Relative humidity

8% to 80%

Dimensions

136.3x38.9x10.7mm
• Control 8 zones of receivers separately
• Single color controller
• Compatible with all universal series RF receivers
• 1 receiver can be paired by max 8 different remote controls.
• Waterproof grade: IP20
Safety & Warnings
• This device contains a button lithium battery that shall be stored and disposed properly.
• DO NOT expose the device to moisture.

Pair with RF receiver

Step 1:Do wiring the RF receiver according to wiring diagram(please refer to the
instruction of RF receiver that you would like to pair with.
Step 2: Click the "Learning Key" button on RF receiver or re-power on the receiver
three times continuously to set it into pairing status
Step 3:Choose and click a zone number(e.g. zone 8), LED lights connected with the
RF receiver flicker once means the receiver is paired with zone 8 successfully.
Note: one receiver can be paired with max 8 remote controls.
RF LED Receiver
Learning Key
