Appendix A — Specifications
EV12 Linear Imager Reading Distances
Minimum Reading Distances With 0.12 cm (0.05 in) Setback*
EV12 Linear Imager Minimum Reading Distances: This graphic does not
include the 0.12 cm (0.05 in) setback for the CK3.
80
All manuals and user guides at all-guides.com
Symbology Density
Code 39 0.15 mm (6 mils)
0.25 mm (10 mils)
0.5 mm (20 mils)
1 mm (40 mils)
EAN/UPC 0.33 mm (13 mils) 6.1 cm (2.5 in)
*Minimum reading distances are measured in the dark (0 lux).
0"
2"
in
8"
7"
6"
5"
4"
3"
2"
1"
0"
1"
2"
3"
4"
5"
6"
7"
8"
0 5
Minimum Distance
9.6 cm (3.8 in)
7.1 cm (2.9 in)
6.1 cm (2.5 in)
8.1 cm (3.2 in)
4" 8"
6"
EAN/UPC 100%
0.125 mm / 5 mils
0.25 mm / 10 mils
0.5 mm / 20 mils
1 mm / 40 mils
10 15 20
CK3 Mobile Computer User's Manual
Maximum Distance
17.9 cm (7.1 in)
20.9 cm (8.3 in)
26.9 cm (10.6 in)
33.9 cm (13.4 in)
22.9 cm (9.1 in)
12"
10" 14"
25 30 35
16"
20
15
10
5
0
5
10
15
20
cm
40
