  • Page 1 Installer manual AMB 30 Accessories, F1345 IHB GB 1341-1 231417...

  • Page 3: Table Of Contents

    Dimensions and setting-out coordinates Connections Sound pressure levels Optional connections Technical specifications 6 Commissioning and adjusting Electrical circuit diagram Preparations Item register Filling and venting the brine system Start-up and inspection, Outdoor air opera- tion AMB 30 Table of Contents |...

  • Page 4: Important Information

    This installer manual must be left with the customer. using the product. Marking The CE marking means that NIBE ensures that the product meets all regulations that are placed on it based on relevant EU directives. The CE mark is obligat- ory for most products sold in the EU, regardless where they are made.
  • Page 5 Fill in the page for information about installation data in the User manual. ✔ Description Notes Signature Date Brine System flushed System vented Shut off valves Electricity Fuses air collector module Fuses property Ambient sensor Control unit Safety breaker Earth circuit-breaker Miscellaneous Docked to AMB 30 Chapter 1 | Important information...
  • Page 6 Puh: 09-274 697 0 Fax: 09-274 697 40 E-mail: info@nibe.fi www.nibe.fi AIT France, 10 rue des Moines, 67000 Haguenau Tel : 03 88 06 24 10 Fax : 03 88 06 90 15 E-mail: info@nibe.fr www.nibe.fr NIBE Energy Systems Ltd, 3C Broom Business Park, Bridge Way, Chesterfield S41 9QG Tel: 0845 095 1200 Fax: 0845 095 1201 E-mail: info@nibe.co.uk www.nibe.co.uk...

  • Page 7: Delivery And Handling

    The concrete foundation or slabs must be positioned so that the lower edge of the evaporator is at the level of the average local snow depth, although a Do not place AMB 30 directly on the lawn or other non minimum of 300 mm. solid surface.
  • Page 8 The section of the pipe that can be affected by frost must be heated by the heating cable to prevent freezing. Route the pipe downward from AMB 30. The outlet of the condensation water pipe must be at a depth that is frost free or alternatively indoors (with reservation for local ordinances and regula- tions).
  • Page 9 The outlet of the condensation water pipe must be at frost free depth. Route the pipe downward from AMB 30. The condensation water pipe must have a water seal to prevent air circulation in the pipe. The condensation water is lead to an indoor drain (subject to local rules and regulations).
  • Page 10 Installation area The distance between AMB 30 and the house wall must be at least 400 mm. Clearance in front of AMB 30 should be at least one metre. Fritt utrymme Serviceutrymme Min. avstånd vid användning av flera AMB30 Fritt utrymme framför...

  • Page 11: Supplied Components

    Supplied components 2x Top clamps (not used during installation together with F1345) Location The kit of supplied items is placed in packaging on top of AMB 30. Removing the covers AMB 30 Chapter 2 | Delivery and handling...

  • Page 12: The Air Collector Module's Design

    3 The air collector module's design EP12 BT21 BT27 AA6-F1 UB2-4 UB5-7 EB12 EB11 Chapter 3 | The air collector module's design AMB 30...
  • Page 13 Serial number plate UB 1 Cable grommet, supply UB2-4 Cable grommet, circulation pumps and reversing valves UB5-7 Cable grommet, communication cables Designations in component locations according to standard IEC 81346-1 and 81346-2. AMB 30 Chapter 3 | The air collector module's design...

  • Page 14: Pipe Connections

    4 Pipe connections System diagram General AMB 30 is a heat absorbing air collector module which Pipe installation must be carried out in accordance with is an accessory for NIBE F1345. AMB 30 is connected current norms and directives. to F1345 only (outdoor air operation) or in combination...
  • Page 15 Hybrid operation mode Hybrid operation In hybrid operation AMB 30 uses the outdoor air in When the outdoor air temperature is between approx.0 combination with ground /rock collector as the heat and 12°C the controls switches the reversing valves to source.

  • Page 16: Dimensions And Pipe Connections

    Brine side tions Connecting the brine side AMB 30 can be connected to the brine system accord- ing to one of the system solutions on page X or that can be downloaded from the website www.nibe.eu. AMB 30 must be vented by the upper connection (XL7, brine out) using the venting nipple (not supplied) in- stalled on the pipe.
  • Page 17 In those cases where ethylene glycol (40%) is used on installation of hybrid operation or outdoor air opera- tion the pressure expansion vessel must be dimen- sioned according to the following diagram. 800 1000 1200 1400 1600 1800 2000 AMB 30 Chapter 4 | Pipe connections...

  • Page 18: Docking Alternatives

    External additional heat Expansion vessel, closed General External electrical additional heat AMB 30 can be installed in several different ways. The FL10 Safety valve, heating medium side requisite safety equipment must be installed in accord- ance with current regulations for all docked options.
  • Page 19 Shut off valve, brine return BT21 Temperature sensor, extract air QM64 Venting valve BT27 Temperature sensor, brine, collector out RM21 Non-return valve EP100 AMB 30 RN15 Valve, Adjusting Tapping valve Designations according to standards 81346-1 and QM50 Shut-off valve 81346-2. QM60 Venting valve...
  • Page 20 AMB 30 docked (outdoor air operation) to NIBE F1345 -EB1 -FL10 -CM5 -EB1 -EB100-BT25 -GP10 -QM42 -EB100-BT71 -QM43 -RN11 -RM21 -EB100-BT1 -EP100 -EP17 -AA25 -EP100-GP5 -RN15 -BT28 -EP100 -EB100 -EP100 -QM64 -QN20 -CP10 -QM60 -EB100 -BT27 -HQ13 -EP15 -QM53 -RM13...
  • Page 21 Several AMB 30 docked (outdoor air operation) to several NIBE F1345 -EP100 -BT28 -AA25 -EB1 -FL10 -RM16 -EP100 -CM5 -QM60 -RN50 -BT27 -EB1 -EB100-BT25 -GP10 -QM42 -EB100-BT71 -QN20 -QM43 -RN11 -RM21 -QM50 -EB100-BT1 -QM1 -EP101 -RM16 -EP101 -QM60 -RN50 -BT27...

  • Page 22: Electrical Connections

    AMB 30. Power supply is routed through the cable grommet UB1, power supply for the circulation pumps and reversing...

  • Page 23: Connections

    N PE high voltage cable when cable routing. Power connection AMB 30 must be installed via an isolator switch with a minimum breaking gap of 3mm. Minimum cable area must be sized according to the fuse rating used. Sup- AMB 30...
  • Page 24 NOTE ation with several AMB 30). GP2 is only connected to the main unit (on in- stallation of several AMB 30) and is only con- Temperature sensor, brine in to the heat nected on installations with hybrid operation. pump during hybrid operation (BT26)

  • Page 25: Optional Connections

    Connecting several AMB 30 Unscrew the screw to open the control unit and access Up to 9 x AMB 30 can be connected to the same install- the circuit board. The screw is underneath a rubber ation.
  • Page 26 COM2 NOTE GP5 is only connected to the main unit (on in- AA6-COM1 AA6-COM2 stallation of several AMB 30). AMB 30 3 Reversing valve for defrosting (QN20) Connect the reversing valve for defrosting (QN20) to COM1 terminal block X4:1 to X4:4 on the relay card (AA6) as illustrated.
  • Page 27 Connection, two AMB 30 to a F1345 Compressor blocking in NIBE F1345 when defrosting In the example below the master unit (AMB 30, 1) and slave unit (AMB 30, 2) are connected to the software For NIBE F1345 to know when the compressors must controlled inputs AUX2 and AUX3 in F1345.

  • Page 28: Commissioning And Adjusting

    6. Start the heat pump according to the starting in- structions. When installing with several AMB 30 the brine flow is adjusted so that it is evenly divided between the units 7. Go to menu 5.1.7 (br pmp al set.) in the heat pump with maximum flow.

  • Page 29: Control - Introduction

    3.8°C BT26 5.0°C Indoors (usually located near F1345) you will find the control unit that is used to communicate with AMB 30. Here you have for example : Operating status of AMB 30. Make settings specific to the installation. Receive information about settings and alarms.

  • Page 30: Control - Menus

    [-]. Service Description System type In this menu you can choose what type of system AMB 30 has been docked to. Settings Installation specific settings can be made in this menu. Test manually...
  • Page 31 In this menu you can make settings Configuration Here you can choose what type of regarding stopping and starting the system AMB 30 has been docked to. fan. Setting range: Hybrid, Air. Defrost In this menu you can make settings regarding defrosting.
  • Page 32 Here you can set the difference BT28 (ambient) and BT27 (brine out) between the temperature sensors at which defrosting of AMB 30 is to BT28 (ambient) and BT27 (brine out) start. at which the fan is to start and stop.
  • Page 33 Language between the temperature sensors for ambient (BT28) and air out (BT21) Sub menu Description from AMB 30 at which passive de- frosting will be stopped. Stop air mode Defrosting is stopped when the BT28 min. Here you can set at what ambient...
  • Page 34 Setting range: 1 – 9 K Preset value: 4 K Air only Here you select at what ambient temperature (BT28) AMB 30 must shift from/to exclusively outdoor air during hybrid operation. Only outdoor air is used when the set temperature is exceeded and starts to be combined with the set value.
  • Page 35 (QN20) should be open (on) or closed (off). Setting range: on/off Compr. Here you set whether the com- pressor in NIBE F1330 should be running. Setting range: on/off Heater Here you set whether the drain pan heater (EB11) and drip tray heater (EB12) must be running.

  • Page 36: Service

    8.045 1.434 1. Switch off the heat pump and cut the power to AMB 30. 6.514 1.228 2. Close the shut-off valve outside AMB 30 for the 5.306 1.048 brine system. 4.348 0.893 3. Open the drain valve (QM1) and lead off the liquid 3.583...
  • Page 37 BT28 BT21 BT27 BT26 COM1 COM2 BT28 Temperature sensor, ambient BT21 Temperature sensor, extract air BT26 Temperature sensor, brine, collector in to the heat pump during hybrid operation BT27 Temperature sensor, brine, collector out AMB 30 Chapter 9 | Service...

  • Page 38: Disturbances In Comfort

    NOTE NOTE As AMB 30 can be connected to a large num- ber of external units, these should also be The product's serial number should always be checked. stated with all correspondence with NIBE.
  • Page 39 Communica- No communication between dis- Operation of AMB 30 and com- The alarm resets automatically tion play and AMB 30 (master unit of pressor in NIBE F1345 is stopped. when the communication is re- several connected) for more than sumed.

  • Page 40: Troubleshooting

    Start by checking the following possible fault sources: That the heat pump/air collector module is running Cause: AMB 30 does not defrost completely. or that the supply cable to AMB 30 is connected. Group and main fuses of the building. Action: Increase set temperature in menu The building's earth circuit breaker.

  • Page 41: Accessories

    Part no. 089 423 NIBE BCU 30 It requires 2 x reversing valves (NIBE SVH 40/50/65) to use AMB 30 in hybrid operation. The size is determined by the size of the output requirement. SVH 40 Part no.: 067 106 The control pack NIBE BCU 30 is required for systems DN 40 (22 –...

  • Page 42: Technical Data

    12 Technical data Dimensions and setting-out coordinates Ø700 Elintag Cable gland 1095 1175 Ø 30 1205 Fritt utrymme Serviceutrymme Min. avstånd vid användning av flera AMB30 Fritt utrymme framför Chapter 12 | Technical data AMB 30...

  • Page 43: Sound Pressure Levels

    AMB 30 is usually placed next to a house wall, which gives a directed sound distribution that should be AMB 30 works with low fan speed or high fan speed considered.

  • Page 44: Technical Specifications

    26.5/11.4/2.3 42/17.2/2.4 Brine flow 1.18 1.62 2.09/2 2.90/2 Pressure drop in AMB 30 Hybrid system together with F1345 See technical data in the heat pump "Installer Manual". Miscellaneous AMB 30 Operating voltage 400 V 3NAC 50Hz Brine, outdoor air operation only...
  • Page 45 EN 14511. 3) Ambient temperature/Flow temperature Working range AMB 30 outdoor air operation (not hybrid) AMB 30 together with NIBE F1345 24 kW AMB 30 together with NIBE F1345 30 - 60 kW AMB 30 Chapter 12 | Technical data...
  • Page 46 Pressure drop AMB 30 outdoor air operation (not hybrid) at ethylene glycol 40% volume percent Chapter 12 | Technical data AMB 30...

  • Page 47: Electrical Circuit Diagram

    Electrical circuit diagram AMB 30 Chapter 12 | Technical data...
  • Page 48 Chapter 12 | Technical data AMB 30...
  • Page 49 AMB 30 Chapter 12 | Technical data...

  • Page 50: Item Register

    Symbol key, 12 Circulation pump for defrosting, 24 Symbols, 2 Common alarm, 25 System diagram, 12 Compressor blocking in NIBE F1345 when defrosting, 25 Hybrid operation, 13 Connecting several AMB 30, 23 Outdoor air operation, 12 Connections, 21 General, 20...
