5 Accessories

Tango_Plus achieves accuracy class 1 of IEC 61672-1:2003 in all possible device-accessories-alignments
without the necessity of applying any correction values.
Accessory
Cal200
Type 4231
Windscreen W2
USB cable A-Bmini 5 Pol 1.8 m
USB power supply adaptor
Equivalent electrical impedance K65 MICROTECH Gefell
Table 5.1: Available accessories for Tango_Plus
The Windscreen W2 is black coloured and spherically with a diameter of 69 mm.
5.1 Technical specifications of the calibrators
Feature
Standards
Sound pressure level
Supported microphone types 1/2", 1/4", 3/8"
Weight
Sound pressure stability
Surrounding conditions each for
Static pressure
Humidity
Temperature
Table 5.2: Technical specifications Cal200
Manual Tango_Plus
5 ACCESSORIES
Manufacturer
PCB, 1 kHz, 94 dB or 114 dB
B&K, 1 kHz, 94 dB bzw. 114 dB 800043.2
MICROTECH Gefell
SINUS Messtechnik GmbH
SINUS Messtechnik GmbH
Value
IEC 60942:2003 and
ANSI S1.40-1984, Class 1
94 dB, 114 dB 0.1 dB
156 g
<0.1 dB
0.3 dB tolerance
65 kPa . . . 108 kPa
10% . . . 90% RH
-10 C . . . + 50 C
Item number
800934.4
800253.0
801038.7
601092.6
800030.3
Feature
Standard
Sound pressure level
Supported microphone types
Weight
Sound pressure stability
Surrounding conditions
Static pressure
Humidity
Temperature
Table 5.3: Technical specifications Type 4231
28 of 30
Value
IEC 60942:2003, Klasse 1
94 dB, 114 dB 0.2 dB
1",1/2"
approx. 150 g
<0.05 dB
65 kPa . . . 108 kPa
10 % . . . 90 %RH
-10 C . . . + 50 C
