2.2.2 Manual configuration
The manual configuration of the device without PC is shown in the following table 2.2:
Item
Measurement
Record Mode
Sync at Full Hour
Calibration
Start Calibration
Calibration Level
Measurement Values
Display Location
Display Interval
Storage Interval
Print Result
Octave Spectra
Octave Mode
Frequency Weigthing
Display Range
Display Interval
Storage Interval
Storage Weigthing
History Graph
Display Range
History Time
Graph 1
Graph 2
Device
Time
Display
Info
Print Results
Table 2.2: Manual configuration menu of Tango_Plus

2.3 Tango-Utilities

Tango-Utilities is the basic software to configure Tango_Plus and export values from measurements. It is
not meant to perform further analysis calculations.
Status bar
The status bar displays various status information from left to right:
Connection Status:
Virtual COM Port;
Measurement Status: Stop, Measurement, Pause;
Record Status: Record-Mode off,
Marker Status: MARK;
Memory usage: per Hour, Day and Week
SINUS Messtechnik GmbH
2.3 Tango-Utilities
Description
Select values to be stored or just displayed.
Synchronize time intervals to full hours.
Start the process of calibration.
Set the calibration level.
(Select a sound level e.g. L
Select on which graph the value shall be shown.
Select the rate of display refresh (500 ms, . . . , 60 min, End Result only).
Set the storage interval (No storage, 500 ms, . . . , 60 min, End Result only).
Decide whether the result shall be printed.
Select whether 1/3 or full octaves shall be measured.
Available weigthings: Z, A, C
Adjust the scaling of the Y-axis.
Select the rate of display refresh (125 ms, . . . , 60 min, End Result only).
Set the storage interval (No storage, 125 ms, . . . , 60 min, End Result only).
Available weigthings: Z, A, C
Adjust the scaling of the Y-axis.
Adjust the scaling of the X-axis.
Select which value shall be displayed as yellow.
Select which value shall be displayed as green.
Set time and select 12h or 24h format.
Set Display properties.
Read off version numbers of firmware and hardware.
disconnected, connected, but Tango_Plus off,
Record-Mode on,
and adjust the following properties.)
AFmax
Record-Mode on (Recording);
13 of 30
connected, Tango_Plus on;
Manual Tango_Plus
