Info Tab - SINUS Tango Plus User Manual

Program settings and Extended device settings
Via the main menu Settings->Program. . . the following settings are available (figure 2.1): Selection of the
connected device Tango_Plus (Connected Device), default export directory (Default Export Directory)
and the default directory for configuration data. The Extended device settings cannot be adjusted manually
without PC.
Figure 2.1: Tango-Utilities - Program settings
Parameter
Disable Device Calibration
Disable display setup changes
Disable measurement setup changes Select this parameter to lock measurement recording settings.
Enable fixed record mode
Startup after battery replacement
Table 2.3: Extended progam settings

2.3.1 Info Tab

You may view the software version of Tango-Utilities in the main menu selecting Help -> About (figure 2.4).
The firmware version of the device is displayed in the Info-Tab (figure 2.3).
Figure 2.3: Tango-Utilities - Info Tab
Manual Tango_Plus
2 APPLIANCE
Figure 2.2: Tango-Utilities- Extended device settings
Description
Select this parameter to disable calibration feature on the device.
Select this parameter to lock the display settings.
Select this parameter to activate the Record-Mode permanently.
Automatic start of Tango_Plus after changing the batteries.
14 of 30
Figure 2.4: Tango-Utilities - About-Box
SINUS Messtechnik GmbH
