CR805 Retransfer Card Printer
c
1. Insert the cleaning card vertically into the printer between
the retransfer cartridge guidepost and the rollers. The
adhesive side of the card should face to the right and touch
the rollers.
2. Move the cleaning card up and down along the rollers to
remove debris.
Move the cleaning
card up and down
Sticky
Cleaning Card
Ink Ribbon
Printhead
Cartridge
Cam Rollers
Guidepost
10
527692-001EN_E
6
Clean the Printer
"Single-Hopper Printer"
"Multi-Hopper Printer" on page 12
Single-Hopper Printer
a
b
Card Bow
c
Continue with
"Start the Cleaning Cycle" on page
527692-001EN_E
Quick Install Guide
Sticky
Cleaning Card
13.
11
