Summary of Contents for Oki LD670

  • Page 4 Notes on Use Notes on printing and the paper used (1) Printing at a high rate might result in unclear printing. If this problem occurs, adjust the printing rate. Alternatively, adjust the print speed and print density so that there are no blurs. (See Examples (1) and (2) in Section 10-2, "Setting Up the Printer.") (2) Printing characters from a non-standard character set e.g.
  • Page 5 (10) If label paper is used, adhesive matter adhering to the cutter blade, thermal head, paper transport, or paper holder may cause a cutting error, print error, or paper transport error. Remove adhesive matter periodically (typically on a monthly basis). (11) If paper is left inserted in the printer for a long time, the paper may become deformed and result in thin (faint) printed characters.
  • Page 6 Notes on using the cutter (1) Note also that the paper length used per transaction must be at least 15mm. (2) The maximum number of successive cuts by the cutter is 30 cuts per minute (at least two seconds per cut). Using the cutter at a higher rate may cause a failure.
  • Page 7 Notes on using the printer through the USB interface (1) The printer must be connected directly to the host computer. (2) Before starting printing, turn on the power to the printer. (3) If a printer error occurs during printing, recover the printer from the error, and then retry printing.
  • Page 8 Note on installation (1) The printer must be used indoors. If used outdoors, the printer may fail because of dust. Note on the modular connector (1) This product uses a modular connector as a dedicated connector for the cash drawer or customer display terminal. The connector must not be connected with a connector that leads to a public switched line or other such destination.

  • Page 9: Table Of Contents

    TABLE OF CONTENTS 1. Appearance and Names of Components ·········································· 11 Appended goods ·········································································· 12 2. AC Adapter ················································································ 13 2-1. AC adapter ·········································································· 13 3. Paper Specifications ···································································· 14 3-1. Paper Width ········································································· 14 3-2. Paper Thickness ··································································· 14 3-3.
  • Page 10 6-3-1. Automatic layout detection ············································ 58 6-3-2. Setting the Paper Width ················································ 59 6-3-3. Automatic layout detection ············································ 61 6-4. Replacing paper ···································································· 64 6-5. Paper Layout Errors ······························································ 65 6-6. Adjusting Sensors ································································· 66 6-7. Print Density Setting ····························································· 67 6-8.
  • Page 11 14-5. Roll Paper Unit Installation Procedure ·································· 208 14-6. Method of setting PNE sensor ·············································· 213 14-7. Method of setting guide plate ··············································· 214 14-8. Setting the Roll Paper ························································· 215 14-9. Roll Paper Unit Appearance ················································· 220 OKI CONTACT DETAILS ······························································· 221...

  • Page 12: Appearance And Names Of Components

    1. Appearance and Names of Components Control panel Top cover This panel Open and close this contains status cover to replace lamps and forms. operating switches. Power switch Paper guide Open the paper guide This switch turns the when the expected printer power on and off.

  • Page 13: Appended Goods

    Appended goods Thermal paper MANUAL PRINTER DRIVER UTILITY SOFT Instruction sheet Safety warranty sheet AC adapter Power cable...

  • Page 14: Ac Adapter

    2. AC Adapter 2-1. AC adapter Only use the AC adapter specified below. Model name: KA02951-0120 Input: 100 to 240V AC, 50/60Hz- Output: DC24V±5%, 1.5A Caution: Only use authorized AC adapters. Caution: Do not use the bundled AC adapter and Power cable for any electrical equipment other than this printer.

  • Page 15: Paper Specifications

    3. Paper Specifications 3-1. Paper Width (1) Paper width of 83 mm: 83 mm; paper width of 80 mm: 80 -1.0 -1.0 (2) Paper width within a range of 70 to 25.4 mm (by units of 1 mm) : 70 to 25.4 -1.0 Note: Paper with a width within a range of 71 to 79 mm cannot be used.
  • Page 16 (2) Fanfold paper - Maximum stack height: 180 mm or less - Fold length: 76.2 to 203.2 ± 0.5 mm (3 to 8 inches) - Perforation specifications: 3 (cuts):1 (tie)

  • Page 17: Paper Types

    3-4. Paper Types The printer supports the following paper types: a. Plain paper (including full-sheet label paper) b. Black mark paper c. Die-cut label paper (including die-cut label paper with black marks) When using black mark or die-cut paper, the printer can move the paper to the start position, cutting position, peeling-off position, or tear-off position according to the paper layout settings.
  • Page 18 Note: Die-cut label paper is a type of label paper with a label sheet already cut into segments of a certain size. Note: Full-sheet label paper is a type of label paper with an uncut label sheet that allows users to cut to any length by using a cutter. Note: The same settings can be used when printing on full-sheet label paper or plain paper (with no black marks).

  • Page 19: Requirements For Full-Sheet Label Paper

    3-4-1. Requirements for full-sheet label paper To prevent adhesive matter from sticking to the print head or paper guide, use label paper that has undergone margin removal as shown below. (Margin removal means cutting the margins at the time of manufacturing.) Slits on both sides on the printable side of paper 2 mm or less...

  • Page 20: Conditions For Using Black Mark Paper

    3-4-2. Conditions for using black mark paper When using receipt paper or full-sheet label paper with black marks, confirm that the following conditions are satisfied. The reflection factors at locations A and B on the paper must be the combination of values specified in the table below.

  • Page 21: Conditions For Using Die-Cut Label Paper

    3-4-3. Conditions for using die-cut label paper When using die-cut label paper, confirm that the following conditions are satisfied. When using die-cut label paper with black marks, confirm that the conditions stated in Section 3-4-2, "Conditions for using black mark paper,"...

  • Page 22: Recommended Thermal Paper

    3-5. Recommended Thermal Paper Manufacturer Product Quality characteristics Paper Density name thickness specification Oji Paper Co., PD160R Monochrome receipt paper 75µm 100% Ltd. (high-grade preservation type) PD190R Monochrome receipt paper 100% 75µm (mid-grade preservation type) Nippon Paper TF60KS-EX Monochrome receipt paper 75µm 100% Industries Co.,...
  • Page 23 Note : Red or blue printing on two-color thermal paper has an inferior preservation characteristic that is equivalent to that of normal thermal paper. Note : Printouts on label paper or thick paper may contain blurs or voids, depending on the humidity and other environmental conditions. Adjust the print speed and print density as appropriate for the type of paper used.

  • Page 24: Preparations

    4. Preparations No printer cable is provided with the product. Obtain a printer cable suitable for the product interface. If you have any questions, consult your dealer. Before connecting or disconnecting cables, make sure of the following: 1) The power to the printer and all other devices connected to the printer is turned off.
  • Page 25 LAN interface model Connector Cover Insert LAN interface cable Insert DIP switches LAN interface connector Power connector Drawer kick connector LEDs Caution: Do not touch the DIP switches during normal use. This may change the network settings, disabling normal printing. Caution: If the device is installed vertically, the LAN cable may not usable due to its shape.
  • Page 26 For a unit with Dual interface Connector cover Insert USB Interface Cable Type-B * Connect the printer to a PC through this connector. Serial interface cable * Secure the connector with screws after making the connection. Insert Interface connector (Serial interface) Power connector Interface Connector (USB Interface Type-B)

  • Page 27: Connecting The Drawer Kick Cable

    4-2. Connecting the drawer kick cable Open the connector cover at the rear of the printer by pulling it up, and connect the drawer kick cable to its rear connector socket. Close the cover after connecting the cable. Note : If the cable is arranged so that it extends from the rear, remove the inserts in the connector cover with nippers or a similar tool.

  • Page 28: Connecting The Ac Adapter

    4-3. Connecting the AC Adapter (1) Connect the AC adapter to the AC adapter power cable. Note: To connect or disconnect the AC adapter, turn off the power switches of the printer and all the devices to be connected to the printer. Then, unplug the plug of the AC adapter power cable from the electrical outlet.
  • Page 29 Note: To prevent the adaptor from slipping out, the connector section is designed to be tight to fit. When inserting, (1) pinch the base of the cable, (2) while sliding the outer section of the connector upwards, (3) and insert the connector until it locks in place with a “click” sound. Base of the cable Outer section of the connector...

  • Page 30: Disconnecting The Ac Adapter

    4-4. Disconnecting the AC Adapter To unplug the AC adapter cable, grasp the connector as shown in the picture below and pull it out. The lock mechanism of the connector will then disengage, and the cable can be unplugged easily. Conversely, forcibly pulling on the cable itself may damage the connector.

  • Page 31: Turning On The Power

    4-5. Turning on the Power After the AC adapter is connected, turn on the power switch at the side of the printer. The POWER lamp on the control panel lights. Control panel Power switch...

  • Page 32: Inserting Paper For Printing

    5. Inserting Paper for Printing 5-1. Opening the Top Cover (1) Grasp the top cover, pull up the cover release lever, and open the top cover. Top part of the top cover Bottom part of the cover release lever (2) When manipulating the top cover, note that the cover seems to lock in position before it is open completely.

  • Page 33: Setting The Paper Width

    5-2. Setting the Paper Width Separator A is set to the position for a paper width of 70 mm at the time of shipment from the factory. - By adjusting the position of separator A, you can use paper with a width within a range of 70 to 25.4 mm.

  • Page 34: Mounting Separator A

    5-2-1. Mounting separator A Holding separator A at locations a (lever) and b, slide the lever to the desired position. Then, set the separator in place. Use the scale as necessary. Note: Separator A must be set in place with an allowance of about 0.5 mm for the maximum paper width.

  • Page 35: Removing Separators A And B

    5-2-2. Removing separators A and B (1) Removing separator A While holding part b on separator A with part a (lever) pushed in the arrow-indicated direction, lift it to disengage the lock, and then remove the rear bearing section. Location b Location a (lever) Rear bearing section Separator A...
  • Page 36 (2) Removing separator B Holding separator B at location a, lift the separator to disengage the lock. Then, remove the separator at the rear bearing section. Rear bearing section Lock Location a Separator B Separator B...

  • Page 37: Attaching Separators A And B

    5-2-3. Attaching separators A and B (1) Attaching separator A Attach separator A from the rear bearing section. Aligned horizontally Rear hook for the axis Note : Push the separator down until it engages with an audible click, and confirm that the top of the separator is aligned horizontally.
  • Page 38 (2) Attaching separator B Attach separator B from the rear bearing section. Aligned horizontally Rear hook for the axis Note : Push the separator down until it engages with an audible click, and confirm that the top of the separator is aligned horizontally.

  • Page 39: Loading Paper

    5-3. Loading Paper 5-3-1. Loading roll paper (1) When using a new paper roll, remove the glued portion of the paper as well as the part to which adhesive tape is affixed. Note : Since the glued portion of the paper should not be printed on, remove about one turn (about 40 cm) of the roll paper from the beginning so that none of the remaining paper has glue on it.
  • Page 40 Note : Before loading a new roll, make sure that an old core does not remain in the roll holder. Leaving an old core will cause a paper-near-end error condition. Paper not protruding Roll paper inserted from the front cover upside down Note : The roll paper must have no deformities.

  • Page 41: Loading Fanfold Paper

    5-3-2. Loading fanfold paper (1) Load the fanfold paper with its thermo sensitive side facing up. (2) Open the top cover, and then pass the fanfold paper through the paper feed section at the rear of the printer. Paper feed section Load the paper with its thermo sensitive side facing up.
  • Page 42 Figure 1 Max 180mm 20 mm or more Figure 2 Max 80mm Note: Fanfold paper must be placed at least 20 mm from the rear of the printer. When this requirement is satisfied, paper can be stacked up to 180 mm (see Figure 1). When fanfold paper is placed in contact with the rear of the printer, paper can only be stacked up to 80 mm (see Figure 2).
  • Page 43 Note: When using perforated paper, make sure that the printer does not cut the paper at perforations or in an area that is 0 to 15 mm in front of perforations (as viewed from the paper feed direction). Otherwise, incorrect cutting may result. (See Figure 3.) Note: When using perforated paper, be sure to prevent paper from being caught, paper jams, paper from being cut during transport, and other such problems.

  • Page 44: Setting The Paper Guide

    5-4. Setting the Paper Guide When the print length per print session is longer than 50 mm, use the printer with the paper guide open. When it is equal to or less than 50 mm, use the printer with the paper guide closed. Paper guide For print length equal to or less than 50 mm: Use the printer with the paper guide closed.

  • Page 45: Closing The Top Cover

    5-5. Closing the Top Cover Place the paper in the correct orientation, and carefully close the top cover. Press here Release lever Top cover Note : Place the paper in the correct orientation. If the top cover is closed while the paper is not correctly in place, a paper jam or misaligned printing might occur.

  • Page 46: Setting Up The Printer

    6. Setting Up the Printer Introduction to printer setup procedures You can set the following items for this printer: (1) Paper type and paper layout - Die-cut label paper, black mark paper, or plain paper - Paper width and other paper layout information (2) Custom paper creation (3) Sensor adjustment (4) Print speed...
  • Page 47 Note: - The printer provides a function that automatically detects the paper layout. This automatic layout detection function obtains fixed information on width settings. Therefore, OKI recommends that you manually specify these settings. Note: - There are two ways to manually set up the printer:...
  • Page 48 6-1. Paper Information Setting Using the Driver Printer setup flow I. Installing the driver Installation Guide ↓ See "Chapter 3 Installation" in the II. Paper layout detection ↓ Provide the printer with the paper layout information described in the Manual Section 6-1-1, "Paper layout." III.

  • Page 49: Paper Layout

    6-1-1. Paper layout The printer shipped from the factory is configured to enable automatic paper detection. Follow the procedure below to have the printer automatically detect the paper layout information. <<Procedure>> (1) Turn on the printer power. (2) Open the top cover. (3) Load the paper that you want to use into the printer.

  • Page 50: Custom Paper

    Windows version. For details on how to open the printer folder, see "Section 3.1.1 How to Windows Driver User's Guide Display the Printer Properties" in the 2. Right-click [LD670 Raster], and then select [Properties]. 3. Click the [Custom Paper] tab.
  • Page 51 (1) Creating a new custom paper type <<Procedure>> (1) Check the [Create a New Paper] check box and enter the paper name. (2) Select [Paper Type] and enter the appropriate paper information ([S1] to [S5]). Do not change [S5] (cut position) with its default value. (3) Enter the left, right, top and bottom margins.
  • Page 52 (2) Using an existing type of paper <<Procedure>> (1) Select the desired paper that has already been created. (2) Click the [Transfer to Printer] button. The selected paper layout information is sent to the printer and becomes effective. (3) Go to step 4.
  • Page 53 Before actually printing data, however, be sure to replace the paper. * If the newly set type of paper is not plain paper, the printer feeds paper up to the top-of-form position. 5 In the LD670 Raster Properties window, click the [OK] button.

  • Page 54: Printing From An Application

    You can print a document from an application using paper information registered in the printer driver. The procedure below explains how to print a document to the LD670 printer using WordPad as an example. 1. From the WordPad [File] menu, select [Page Setup].

  • Page 55: Paper Information Setting Using The Utility

    6-2. Paper information setting using the utility 6-2-1. Paper layout The printer shipped from the factory is configured to enable automatic paper detection. Follow the procedure below to have the printer automatically detect the paper layout information. <<Procedure>> (1) Turn on the printer power. (2) Open the top cover.

  • Page 56: Setting Detailed Paper Layout Information

    This procedure explains how to send layout information to the printer. The use of Windows XP Professional is assumed for the screen shots. 1. Click [Start], [All Programs], [Okidata], and [LD670 Utility] in this order. * The method of running the printer utility varies depending on the Windows Utility User's Guide version.
  • Page 57 <<Procedure>> (1) Uncheck the [Automatically set the paper layout] check box. (2) Select [Paper Type] and enter the appropriate paper information ([S1] to [S5]). Do not change [S5] (cut position) with its default value. (3) Enter the left, right, top and bottom margins as required. (4) Click the [Set Layout] button.
  • Page 58 4 When a confirmation message appears, respond as instructed and then click the [OK] button. 5 A message appears, prompting you to replace the paper with paper targeted by the layout setting. Replace the paper and click the [OK] button. * If the error remains even after setting is completed, re-verify that the paper loaded on the printer matches the paper setting.

  • Page 59: Setting Paper Information Using The Printer

    6-3. Setting Paper Information Using the Printer 6-3-1. Automatic layout detection The printer shipped from the factory is configured to enable automatic paper detection. Follow the procedure below to have the printer automatically detect the paper layout information. <<Procedure>> (1) Turn off the printer power. (2) Open the top cover.

  • Page 60: Setting The Paper Width

    This procedure explains how to send your paper width setting to the printer. The use of Windows XP Professional is assumed for the screen shots. 1. Click [Start], [All Programs], [Okidata], and [LD670 Utility] in this order. * The method of opening the printer folder varies depending on the Windows version.
  • Page 61 <<Procedure>> (1) Enter the paper width. (2) Click the [Layout Auto Set] button. 4 When a confirmation message appears, respond as instructed and then click the [OK] button. 5 A message appears, prompting you to replace the paper with paper targeted by the layout setting.

  • Page 62: Automatic Layout Detection

    6-3-3. Automatic layout detection The automatic layout settings are configured as follows: Black mark paper L1: Length from the vertical reference position to the next reference Position : Automatically detected L2: Length of the detection area for the vertical reference position : 5.0mm to 5.5mm L3: Length from the vertical reference position to the start position : 1.5mm...
  • Page 63 Die-cut label paper L1: Length from the vertical reference position to the next reference position : Automatically detected L2: Length of the detection area for the vertical reference position : Automatically detected L3: Length from the vertical reference position to the start position : (L2/2 + 1.5) mm L4: Length from the vertical reference position to the cutting position : 0.0 mm...
  • Page 64 Plain paper (including full-sheet label paper) L1: Length from the vertical reference position to the next reference position : Not determined L2: Length of the detection area for the vertical reference position : Not determined L3: Length from the vertical reference position to the start position : Not determined L4: Length from the vertical reference position to the cutting position : Not determined...

  • Page 65: Replacing Paper

    6-4. Replacing paper The paper replacement procedure is as follows. Automatic layout detection <<Procedure>> (1) Turn off the printer power, and open the top cover. (2) Turn on the printer power. (3) Load the paper that you want to use into the printer. Leave the top cover open.

  • Page 66: Paper Layout Errors

    6-5. Paper Layout Errors When using black mark or die-cut label paper, the printer monitors the paper length (L1) based on the set paper layout. If the detected paper length does not match the set paper length, a paper layout error occurs. (1) Error when paper is being loaded Confirm that the paper being loaded is the same as the paper specified in the paper layout information for the printer.

  • Page 67: Adjusting Sensors

    6-6. Adjusting Sensors 1) There are two ways to adjust sensors: a. Automatic sensor adjustment (This mode is set at the time of shipment from the factory.) b. Manual sensor adjustment ■ Automatic sensor adjustment 1) With this mode enabled, the sensor is automatically adjusted in parallel with automatic layout detection.

  • Page 68: Print Density Setting

    6-7. Print Density Setting The printer can specify a print density for the paper to be used. The print density is preset to 130% at shipping. You can change this setting to the value appropriate for the paper to be used as described in Section 3-5, "Recommended Thermal Paper."...

  • Page 69: Print Speed Setting

    6-8. Print Speed Setting There are three methods of changing the setting: (1) Using the Windows printer driver Windows Driver User's Guide See "Section 4.4 [Graphics] Tab" in the (2) Using the printer utility Utility User's Guide See "Section 3.2.5 Customize Value" in the (3) Setting up the printer Change the settings as described in Example (2) in Section 10-2, "Setting Up the Printer."...

  • Page 70: Cutting Position Correction

    6-9. Cutting Position Correction This printer allows you to correct (upward or downward) the top-of-form position, cut position, peeling-off position and tear-off position. Change the setting as required. You can use one of the following methods to change this setting. (1) Using the Windows printer driver Windows Driver User's Guide See "Section 4.1 [Custom Paper] Tab"...

  • Page 71: Other Settings

    6-10. Other Settings This printer allows you to specify whether to feed paper up to the top-of-form position at power-on and whether to cut paper upon the closing of the cover. There are two methods of changing the setting: (1) Setting up the printer Change the setting as described in Example (4) in Section 10-2, "Setting Up the Printer."...

  • Page 72: Control Panel

    7. Control Panel 7-1. Control Panel POWER lamp (●) Lights when the power switch is turned on and power is supplied to the printer. ERROR lamp (●) Lights or blinks to indicate errors. FEED switch - Plain paper (including full-sheet label paper) Pressing this switch once advances the paper one line.
  • Page 73 * How to initialize the paper layout Pressing the FEED switch with the top cover open initializes the paper layout information. After initialization is completed, load the paper you want to use and then close the top cover. The printer feeds paper, automatically retrieves paper information, and retains the paper layout information.

  • Page 74: Error Indications

    7-2. Error Indications Recoverable errors Error condition LED LAMP Blinking pattern No paper POWER ( Constantly on ● (paper end) ERROR ( Constantly on ● Cover open POWER ( Constantly on ● ERROR ( Constantly on ● Head hot (*1) POWER ( Constantly on ●...
  • Page 75 Unrecoverable errors Error condition LED LAMP Blinking pattern Internal error POWER ( ● ――●―●― ERROR ( ● ●――――― Repeated pattern in which the green lamp blinks twice and the amber lamp blinks once Head not POWER ( ● ――●―●―●― installed ERROR ( ●...

  • Page 76: Preventing And Clearing Paper Jams

    8. Preventing and Clearing Paper Jams 8-1. Preventing Paper Jams Do not touch the paper while the paper is being ejected or cut. Holding or pulling the paper by hand during ejection might cause a paper jam, incorrect cutting, or a feed error. 8-2.

  • Page 77: Troubleshooting

    9. Troubleshooting This chapter describes the appropriate action to be taken in cases where the printer is not operating correctly or fails to produce clean printouts. 9-1. Power-on Problems and Errors Symptom Cause Corrective action Although the power (1) The power cable is (1) Connect the power cable.

  • Page 78: Printing-Related Problems

    9-3. Printing-related Problems Symptom Causes Corrective action Printing does not (1) The interface cable is (1) Connect the interface cable begin. disconnected or broken. correctly, or replace it. (2) The printer setup is (2) Set up the printer correctly. incorrect. Example: An incorrect baud rate is set.

  • Page 79: Special Modes

    10. Special Modes 10-1. Test Printing With paper inserted in the printer, turn off the printer power switch once, and turn on the switch again while holding down the FEED switch on the control panel. Then, the data shown below is printed. When "TEST PRINT" is printed, press and hold down the FEED switch for one second or longer to start test printing.
  • Page 80 The printer stops after printing the selection items. - When you press the FEED switch briefly (one second or less), the printer ends test printing. - When you press and hold down the FEED switch for one second or longer, the printer continues test printing to print a list of fonts.

  • Page 81: Setting Up The Printer

    10-2. Setting Up the Printer This section explains how to set up the printer without using a PC. With the printer connected to a Windows PC, you can easily change the settings by using the utility software contained on the CD-ROM provided with the printer.

  • Page 82: Example (1): Changing The Print Density

    Example (1): Changing the Print Density Change from 130% to 100% The procedure for this setting is as follows. 1. Before starting work for this setting, verify the following conditions of the printer: (1) The power is off. (2) Roll paper is inserted in it. (3) The cover is closed.
  • Page 83 3. Enter setup mode from special mode. Press the FEED switch briefly (one second or less) once to move to "SETUP". Setup ↑ Test Print Sample Print Data Analysis Cleaning Sensor Adjustment Setup Test Print Selection Item Then, press and hold down the FEED switch for one second or longer to accept the selection.
  • Page 84 4. In setup mode, select "SETUP" Press and hold down the FEED switch for one second or longer to accept the selection. The printer prints the following when you accept the selection of "SETUP": Paper Setting Return to Top Menu Others Serial Condition Customize Value...
  • Page 85 5. Select "CUSTOMIZE VALUE" as your option. Quickly press the FEED switch twice (up to one second each) to move to "CUSTOMIZE VALUE". Customize Value ↑ Memory Switch ↑ Paper Setting Return to Top Menu Others Serial Condition Customize Value Memory Switch Paper Setting Selection Item...
  • Page 86 6. Select "PRINT DENSITY" as your option. Press the FEED switch briefly (one second or less) three times to move to "PRINT DENSITY". Print Density ↑ Print Color ↑ NV Graphics Memory ↑ User NV Memory Return to Top Menu Return to Up Low Power Max Speed...
  • Page 87 7. Select "100%" as your option. Press the FEED switch briefly (one second or less) until the item "100%" is reached. 100% ↑ ↑ ↑ ↑ ↑ ↑ 70% (Lightest) ↑ 130% (Darkest) 130% (Darkest) 125% 120% 115% 110% 105% 100% 70% (Lightest) Selection Item...
  • Page 88 8. Select "RETURN TO UP" as your option. Press and hold down the FEED switch for one second or longer to accept the selection. The printer prints the following when you accept the selection of "RETURN TO UP": Return to Top Menu Return to Top Menu Others Serial Condition...
  • Page 89 10. Select "END" as your option. Quickly press the FEED switch three times (up to one second each) to move to "END". ↑ Default Set ↑ Setup Print ↑ Setup Default Set Setup Print Setup Selection Item Then, press and hold down the FEED switch for one second or longer to accept the selection.

  • Page 90: Example (2): Changing The Max Speed

    Example (2): Changing the Max Speed Change from 5 (Max. 140 mm/s) to 9 (Max. 260 mm/s) The procedure for this setting is as follows. 1. Before starting work for this setting, verify the following conditions of the printer: (1) The power is off. (2) Roll paper is inserted in it.
  • Page 91 3. Enter setup mode from special mode. Press the FEED switch briefly (one second or less) once to move to "SETUP". Setup ↑ Test Print Sample Print Data Analysis Cleaning Sensor Adjustment Setup Test Print Selection Item Then, press and hold down the FEED switch for one second or longer to accept the selection.
  • Page 92 4. In setup mode, select "SETUP". Press and hold down the FEED switch for one second or longer to accept the selection. The printer prints the following when you accept the selection of "SETUP": Paper Setting Return to Top Menu Others Serial Condition Customize Value...
  • Page 93 The printer prints the following when you accept the selection of "CUSTOMIZE VALUE": User NV Memory Return to Top Menu Return to Up Low Power Max Speed BK Density Print Density Print Color NV Graphics Memory User NV Memory Selection Item Customize Value 6.
  • Page 94 Then, press and hold down the FEED switch for one second or longer to accept the selection. The printer prints the following when you accept the selection of "MAX SPEED": 9th (High Speed) 1st (Low Speed) Selection Item Max Speed 7.
  • Page 95 The printer prints the following when you accept the selection of "9th": Return to Up Return to Top Menu Return to Up Sensor Auto Adjust Mark Feed with Cut Feed at Power On Layout Er Recovery Layout Er Process TearOff Adjustment Base Adjustment Paper Width Paper Detection...
  • Page 96 9. Select "RETURN TO TOP MENU" as your option. Press and hold down the FEED switch for one second or longer to accept the selection. The printer prints the following when you accept the selection of "RETURN TO TOP MENU": Setup Default Set Setup Print...
  • Page 97 Note: If you turn off the printer power switch without first selecting "END", your setting will be lost. - Verifying your setting To verify your setting, execute a test print, referring to Section 10-1. The test printing prints a list of printer settings. Check the list, and verify your setting.

  • Page 98: Example (3): Changing The Print Color

    Example (3): Changing the Print Color Change of the print color setting (from monochrome to two colors) The procedure for this setting is as follows. 1. Before starting work for this setting, verify the following conditions of the printer: (1) The power is off. (2) Roll paper is inserted in it.
  • Page 99 3. Enter setup mode from special mode. Press the FEED switch briefly (one second or less) once to move to "SETUP". Setup ↑ Test Print Sample Print Data Analysis Cleaning Sensor Adjustment Setup Test Print Selection Item Then, press and hold down the FEED switch for one second or longer to accept the selection.
  • Page 100 4. In setup mode, select "SETUP". Press and hold down the FEED switch for one second or longer to accept the selection. The printer prints the following when you accept the selection of "SETUP": Paper Setting Return to Top Menu Others Serial Condition Customize Value...
  • Page 101 Then, press and hold down the FEED switch for one second or longer to accept the selection. The printer prints the following when you accept the selection of "CUSTOMIZE VALUE": User NV Memory Return to Top Menu Return to Up Low Power Max Speed BK Density...
  • Page 102 Then, press and hold down the FEED switch for one second or longer to accept the selection. The printer prints the following when you accept the selection of "PRINT COLOR": Mono 2 Color Mono Selection Item Print Color 7. Select "2 COLOR" as your option. Press the FEED switch briefly (one second or less) once to move to "2 COLOR".
  • Page 103 The printer prints the following when you accept the selection of "2 COLOR": Return to Up Return to Top Menu Return to Up Sensor Auto Adjust Mark Feed with Cut Feed at Power On Layout Er Recovery Layout Er Process TearOff Adjustment Base Adjustment Paper Width...
  • Page 104 9. Select "RETURN TO TOP MENU" as your option. Press and hold down the FEED switch for one second or longer to accept the selection. The printer prints the following when you accept the selection of "RETURN TO TOP MENU": Setup Default Set Setup Print...

  • Page 105: Example (4) Changing The Feed At Power On

    Example (4) Changing the Feed at Power On Change from ENABLE to DISABLE The procedure for this setting is as follows: 1. Before starting work for this setting, verify the following printer conditions: (1) The power is turned off. (2) Paper is loaded on the printer. (3) The cover is closed.
  • Page 106 The printer prints the following when entering special mode: Test Print Sample Print Data Analysis Cleaning Sensor Adjustment Setup Test Print Selection Item Special Mode Usage Item Selection Please push the feed switch short. Item Decision Please push the feed switch long. 3.
  • Page 107 Then press and hold down the FEED switch for at least one second to accept the selection. The printer prints the following when entering setup mode: Setup Default Set Setup Print Setup Selection Item Setup 4. In setup mode, select "SETUP". Press and hold down the FEED switch for at least one second to accept the selection.
  • Page 108 5. Select "PAPER SETTING" as your option. Press and hold down the FEED switch for at least one second to accept the selection. The printer prints the following upon your acceptance of "PAPER SETTING" selection: Paper Detection Return to Top Menu Return to Up Sensor Auto Adjust Mark Feed with Cut...
  • Page 109 6. Select "FEED AT POWER ON" as your option. Quickly press the FEED switch five times (up to one second each) to move to "FEED AT POWER ON". Feed at Power On ↑ Layout Er Recovery ↑ Layout Er Process ↑...
  • Page 110 7. Select "DISABLE" as your option. Quickly press the FEED switch (up to one second) to move to "DISABLE". Disable ↑ Enable Disable Enable Selection Item Feed at Power On Then press and hold down the FEED switch for at least one second to accept the selection.
  • Page 111 8. Select "RETURN TO UP" as your option. Press and hold down the FEED switch for at least one second to accept the selection. The printer prints the following upon your acceptance of "RETURN TO UP" selection: Return to Top Menu Return to Top Menu Others Serial Condition...
  • Page 112 10. Select "END" as your option. Quickly press the FEED switch three times (up to one second each) to move to "END". ↑ Default Set ↑ Setup Print ↑ Setup Default Set Setup Print Setup Selection Item Then press and hold down the FEED switch for at least one second to accept the selection.

  • Page 113: Example (5) Initializing The Printer Settings

    Example (5) Initializing the printer settings Note on initialization The initialization procedure does not initialize the paper width and sensor adjustments. These values will remain as set the paper layout information will be initialized except for the paper width. The initialization procedure is as follows: 1.
  • Page 114 The printer prints the following when entering special mode: Test Print Sample Print Data Analysis Cleaning Sensor Adjustment Setup Test Print Selection Item Special Mode Usage Item Selection Please push the feed switch short. Item Decision Please push the feed switch long. 3.
  • Page 115 Then press and hold down the FEED switch for at least one second to accept the selection. The printer prints the following when entering setup mode: Setup Default Set Setup Print Setup Selection Item Setup 4. In setup mode, select "DEFAULT SET". Quickly press the FEED switch twice (up to one second each) to move to "DEFAULT SET".
  • Page 116 5. Select "DEFAULT SET" as your option. Press and hold down the FEED switch for at least one second to accept the selection. The printer prints the following upon your acceptance of "DEFAULT SET" selection: Setup Default Set Setup Print Setup Selection Item Clear Completed...

  • Page 117: Example (6) Changing The Pne Detect

    Example (6) Changing the PNE Detect The procedure for this setting change is as follows: 1. Before starting work for this setting, verify the following printer conditions: (1) The power is turned off. (2) Paper is loaded on the printer. (3) The cover is closed.
  • Page 118 The printer prints the following when entering special mode: Test Print Sample Print Data Analysis Cleaning Sensor Adjustment Setup Test Print Selection Item Special Mode Usage Item Selection Please push the feed switch short. Item Decision Please push the feed switch long. 3.
  • Page 119 Then press and hold down the FEED switch for at least one second to accept the selection. The printer prints the following when entering setup mode: Setup Default Set Setup Print Setup Selection Item Setup 4. In setup mode, select "SETUP". Press and hold down the FEED switch for at least one second to accept the selection.
  • Page 120 5. Select "OTHERS" as your option. Quickly press the FEED switch four times (up to one second each) to move to "OTHERS". Others ↑ Serial Condition ↑ Customize Value ↑ Memory Switch ↑ Paper Setting Return to Top Menu Others Serial Condition Customize Value Memory Switch...
  • Page 121 6. Select "PNE DETECT" as your option. Quickly press the FEED switch five times (up to one second each) to move to "PNE DETECT". PNE Detect ↑ Process ID ↑ Error ↑ Serial Number ↑ ↑ ACK Pulse Width Return to Top Menu Return to Up Roll Paper Unit PE Roll Paper Unit...
  • Page 122 Press and hold down the FEED switch for at least one second to accept the selection. The printer prints the following upon your acceptance of "PNE DETECT" selection: Enable Disable Enable Selection Item PNE Detect 7. Select "DISABLE" as your option. Quickly press the FEED switch (up to one second) to move to "DISABLE".
  • Page 123 Press and hold down the FEED switch for at least one second to accept the selection. The printer prints the following upon your acceptance of "DISABLE" selection: Return to Up Return to Top Menu Return to Up Roll Paper Unit PE Roll Paper Unit Buzzer Batch (OTHER IF)
  • Page 124 9. Select "RETURN TO TOP MENU" as your option. Press and hold down the FEED switch for at least one second to accept the selection. The printer prints the following upon your acceptance of "RETURN TO TOP MENU" selection: Setup Default Set Setup Print Setup...
  • Page 125 Note: If you turn off the printer power switch without first selecting "END", your settings will be lost. - Verifying your settings To verify your settings, execute a test print as described in Section 10-1. The test printing prints a list of printer settings. Check the list to verify your settings.

  • Page 126: Example (7) Changing The Paper Width

    Example (7) Changing the Paper Width Change from 70 mm to 80 mm The procedure for this setting change is as follows: 1. Before starting work for this setting, verify the following printer conditions: (1) The power is turned off. (2) Paper is loaded on the printer.
  • Page 127 The printer prints the following when entering special mode: Test Print Sample Print Data Analysis Cleaning Sensor Adjustment Setup Test Print Selection Item Special Mode Usage Item Selection Please push the feed switch short. Item Decision Please push the feed switch long. 3.
  • Page 128 Then press and hold down the FEED switch for at least one second to accept the selection. The printer prints the following when entering setup mode: Setup Default Set Setup Print Setup Selection Item Setup 4. In setup mode, select "SETUP". Press and hold down the FEED switch for at least one second to accept the selection.
  • Page 129 5. Select "PAPER SETUP" as your option. Press and hold down the FEED switch for at least one second to accept the selection. Paper Detection Return to Top Menu Return to Up Sensor Auto Adjust Mark Feed with Cut Feed at Power On Layout Er Recovery Layout Er Process TearOff Adjustment...
  • Page 130 6. Select "PAPER WIDTH" as your option. Quickly press the FEED switch (up to one second) to move to "PAPER WIDTH". Paper Width ↑ Paper Detection Return to Top Menu Return to Up Sensor Auto Adjust Mark Feed with Cut Feed at Power On Layout Er Recovery Layout Er Process...
  • Page 131 7. Select "80mm" as your option. Quickly press the FEED switch (up to one second) to move to "80mm". 80mm ↑ 70mm 83mm 80mm 70mm 6Xmm 5Xmm 4Xmm 3Xmm 2Xmm Selection Item Paper Width Press and hold down the FEED switch for at least one second to accept the selection.
  • Page 132 8. Select "RETURN TO UP" as your option. Press and hold down the FEED switch for at least one second to accept the selection. The printer prints the following upon your acceptance of "RETURN TO UP" selection: Return to Top Menu Return to Top Menu Others Serial Condition...
  • Page 133 10. Select "END" as your option. Quickly press the FEED switch three times (up to one second each) to move to "END". ↑ Default Set ↑ Setup Print ↑ Setup Default Set Setup Print Setup Selection Item Then press and hold down the FEED switch for at least one second to accept the selection.

  • Page 134: Example (8) Changing The Batch(Other If)

    Example (8) Changing the Batch(OTHER IF) Change of the Batch(OTHER IF) value to ENABLE The procedure for this setting change is as follows: 1. Before starting work for this setting, verify the following printer conditions: (1) The power is turned off. (2) Paper is loaded on the printer.
  • Page 135 The printer prints the following when entering special mode: Test Print Sample Print Data Analysis Cleaning Sensor Adjustment Setup Test Print Selection Item Special Mode Usage Item Selection Please push the feed switch short. Item Decision Please push the feed switch long. 3.
  • Page 136 Then press and hold down the FEED switch for at least one second to accept the selection. The printer prints the following when entering setup mode: Setup Default Set Setup Print Setup Selection Item Setup 4. In setup mode, select "SETUP". Press and hold down the FEED switch for at least one second to accept the selection.
  • Page 137 5. Select "OTHERS" as your option. Quickly press the FEED switch four times (up to one second each) to move to "OTHERS". Others ↑ Serial Condition ↑ Customize Value ↑ Memory Switch ↑ Paper Setting Return to Top Menu Others Serial Condition Customize Value Memory Switch...
  • Page 138 6. Select "BATCH(OTHER IF)" as your option. Quickly press the FEED switch eight times (up to one second each) to move to "BATCH(OTHER IF)". Batch (OTHER IF) ↑ Batch (COM IF) ↑ Font-B ↑ PNE Detect ↑ Process ID ↑ Error ↑...
  • Page 139 Press and hold down the FEED switch for at least one second to accept the selection. The printer prints the following upon your acceptance of "BATCH(OTHER IF)" selection: Disable Disable Enable Selection Item Batch (OTHER IF) 7. Select "ENABLE" as your option. Quickly press the FEED switch (up to one second) to move to "ENABLE".
  • Page 140 Press and hold down the FEED switch for at least one second to accept the selection. The printer prints the following upon your acceptance of "ENABLE" selection: Return to Up Return to Top Menu Return to Up Roll Paper Unit PE Roll Paper Unit Buzzer Batch (OTHER IF)
  • Page 141 9. Select "RETURN TO TOP MENU" as your option. Press and hold down the FEED switch for at least one second to accept the selection. The printer prints the following upon your acceptance of "RETURN TO TOP MENU" selection: Setup Default Set Setup Print Setup...
  • Page 142 Note: If you turn off the printer power switch without first selecting "END", your settings will be lost. - Verifying your settings To verify your settings, execute a test print as described in Section 10-1. The test printing prints a list of printer settings. Check the list to verify your settings.

  • Page 143: Setup Items

    10-3. Setup Items Setup group items № Setup group item Explanation Paper Setting Enters the mode for PAPER-related settings. Memory Switch Enters the mode for MEMORY SWITCH-related settings. Customize Value Enters the mode for CUSTOMIZE VALUE-related settings. Serial Condition Enters the mode for SERIAL INTERFACE CONDITION-related settings.
  • Page 144 № Item Explanation Detailed setup item Base Adjustment Specifies the value used for batch -5.0 mm correction of the start position, -4.X mm cutting position, peeling-off -3.X mm position and tear-off position. -2.X mm -1.X mm -0.X mm 0.0 mm +0.X mm +1.X mm +2.X mm...
  • Page 145 № Item Explanation Detailed setup item TearOff Adjustment Specifies the value used for -5.0 mm correction of the tear-off position. -4.X mm -3.X mm -2.X mm -1.X mm -0.X mm 0.0 mm +0.X mm +1.X mm +2.X mm +3.X mm +4.X mm +5.0 mm When "-4.X mm"...
  • Page 146 № Item Explanation Detailed setup item Layout Er Process Specifies the action to be taken if a Layout Continue paper layout error occurs. Layout Clear - Specify whether to clear the paper layout error information stored in memory. - To continue using the same paper, do not clear the paper layout information.
  • Page 147 (2) Memory Switch setup items № Item Explanation Detailed setup item Power On Status - Specifies reporting the power-on Enable state. Disable Receive Buffer - Specifies the capacity of the receive 45Byte buffer. 4KByte Busy Condition - Specifies the printer BUSY Bufferfull condition.
  • Page 148 (3) Customize Value setup items № Item Explanation Detailed setup item User NV Memory - Capacity of the user NV memory. 1KBYTE 64KBYTE, 128KBYTE 192KBYTE NV Graphic Memory - Capacity of the NV graphic None memory. 64KByte 128KByte 192KByte 256KByte 320KByte 384KByte Print Color...
  • Page 149 № Item Explanation Detailed setup item Max Speed - Maximum print speed. 1st(Low Speed) 1:60mm/S 2: 80mm/S 3:100mm/S 4:120mm/S 5:140mm/S 6:160mm/S 7:180mm/S 8:220mm/S 9:260mm/S 9th(High Speed) Print speed Normal Low Power (maximum) Mode1 Mode1: Printing at 80% of the :Reduction of about specified print density Mode2: Varying of the strobe pulse...
  • Page 150 (4) Serial Condition setup items № Item Explanation Detailed setup item Baudrate - Baud rate. 2400BPS 4800BPS 9600BPS 19200BPS 38400BPS 57600BPS 115200BPS Format - Data format. 7EVEN1 7ODD1 8NONE1 8EVEN1 8ODD1 Protocol - Buffer control protocol. XON/XOFF DSR/DTR Return to Up - Returns to the selection mode for the setup group items.
  • Page 151 Explanation № Item Detailed setup item Font-B - Specifies Font B. Mode1 Mode1: Font in the standard Mode2 specifications Mode2: compatible font Bstch(COM IF) Enable - Batch printing: Received data is Disable printed in a batch. (Priority is placed on print quality.) - Serial printing: Received data is printed serially.

  • Page 152: Sensor Adjustment

    10-4. Sensor Adjustment 10-4-1. Sensor adjustment mode 1. Before starting work for this adjustment, verify the following printer conditions: (1) The power is turned off. (2) Paper is loaded on the printer. (3) The cover is closed. 2. Enter special mode. Turn on the power switch on the right side of the printer while holding down the FEED switch on the left part of the top cover.
  • Page 153 The printer prints the following when entering special mode: Test Print Sample Print Data Analysis Cleaning Sensor Adjustment Setup Test Print Selection Item Special Mode Usage Item Selection Please push the feed switch short. Item Decision Please push the feed switch long. 1) Quickly press the FEED switch twice (up to one second each).
  • Page 154 ■ How to select an item 1) Each time that you press the FEED switch briefly and release it, the printer operates as follows: 2) The printer prints "ADJUSTMENT", "ADJUSTMENT PRINT", "END", "ADJUSTMENT," and so on cyclically in this order.
  • Page 155 ■ How the printer accepts your selection of an item 1) When you press and hold down the FEED switch for one second or longer, the printer accepts the top printed item as your option. 2) Then, the printer starts processing for the selected item. ■...
  • Page 156 ■ ADJUSTMENT 1) When "ADJUSTMENT" is printed, press and hold down the FEED switch for one second or longer to start sensor adjustment. a. The printer prints the selection items. 2) The printer prints "BM SENSOR," "LABEL SENSOR," "PNE SENSOR," "PE SENSOR,"...

  • Page 157: Black Mark (Bm) Sensor Adjustment

    10-4-2. Black mark (BM) sensor adjustment 1) When "BM SENSOR" is printed, press and hold down the FEED switch for one second or longer to start BM sensor adjustment. 2) The printer prints the following and then cuts the paper when BM sensor adjustment begins: 3) Open the top cover and load the paper you want to adjust.
  • Page 158 4) The printer stops the adjustment in the following cases: a. The cover is opened. b. The printer has no paper. c. The adjustment is completed. 5) After paper feeding stops, load the original paper again. The printer prints the adjustment result. 6) The printer writes the adjustment result in memory, and then returns to the previous state when sensor adjustment began.

  • Page 159: Adjusting The Label Sensor

    10-4-3. Adjusting the label sensor 1) When "LABEL SENSOR" is printed, press and hold down the FEED switch for one second or longer to start label sensor adjustment. 2) The printer prints the following and then cuts the paper when label sensor adjustment begins: 3) Open the top cover and load the paper you want to adjust.
  • Page 160 5) After paper feeding stops, load the original paper again. The printer prints the adjustment result. 6) The printer writes the adjustment result in memory, and then returns to the previous state when sensor adjustment began. 7) If the adjustment failed, the printer prints "ADJUSTMENT FAILED" and then returns to its state at the start of sensor adjustment.

  • Page 161: Paper-Near-End (Pne) Sensor Adjustment

    10-4-4. Paper-near-end (PNE) sensor adjustment 1) When "PNE SENSOR" is printed, press and hold down the FEED switch for one second or longer to start PNE sensor adjustment. 2) The printer prints the following and then cuts the paper when PNE sensor adjustment begins: 3) Open the top cover and load the paper you want to adjust.
  • Page 162 6) The printer writes the adjustment result in flash memory and then returns to its state at the start of sensor adjustment. 7) The printer writes the adjustment result in memory, and then returns to the previous state when sensor adjustment began.

  • Page 163: Paper End (Pe) Sensor Adjustment

    10-4-5. Paper end (PE) sensor adjustment Note: You need not adjust the PE sensor when using plain paper (including full-sheet label paper) or black mark paper. 1) When "PE SENSOR" is printed, press and hold down the FEED switch for one second or longer to start PE sensor adjustment.
  • Page 164 Note: When loading die-cut label paper, partially peel off the label from the base paper with the label-peeled portion facing the label sensor, and then close the cover. label sensor...
  • Page 165 5) The printer stops the adjustment in the following case: a. The adjustment is completed. 6) After the adjustment ends, load the original paper again. The printer prints the adjustment result. 7) The printer writes the adjustment result in memory, and then returns to the previous state when sensor adjustment began.

  • Page 166: Data Analysis

    10-5. Data Analysis With paper inserted in the printer, turn off the printer power switch once. If you turn on the switch again while holding down the FEED switch on the control panel, the data shown in Section 10-1 will be printed. If you turn on the switch again and press the FEED switch briefly, the data shown below will be printed.
  • Page 167 Data Analysis ↑ Cleaning ↑ Sensor Adjustment ↑ Setup ↑ Test Print Sample Print Data Analysis Cleaning Sensor Adjustment Setup Test Print Selection Item The printer enters received data analysis mode from the special mode. Press the FEED switch briefly (one second or less) four times to move to "DATA ANALYSIS".
  • Page 168 1.HEX DUMP mode Then, press and hold down the FEED switch for one second or longer to accept the selection. When "HEX DUMP" is printed, press and hold down the FEED switch for one second or longer to place the printer in hex dump mode. In hex dump mode, all signals sent from the host computer to the printer are printed as hexadecimal codes.
  • Page 169 2. Command trace mode Quickly press the FEED switch (up to one second), and then press and hold down the FEED switch for at least one second to accept the selection. In command trace mode, all data sent from the host computer to the printer is printed as command names.

  • Page 170: Sample Print

    10-6. Sample Print With paper inserted in the printer, turn off the printer power switch once. If you turn on the switch again while holding down the FEED switch on the control panel, the data shown in Section 10-1 will be printed. If you turn on the switch again and press the FEED switch briefly, the data shown below will be printed.
  • Page 171 Sample Print ↑ Data Analysis ↑ Cleaning ↑ Sensor Adjustment ↑ Setup ↑ Test Print Sample Print Data Analysis Cleaning Sensor Adjustment Setup Test Print Selection Item The printer enters sample print mode from the special mode. Press the FEED switch briefly (one second or less) five times to move to "SAMPLE PRINT".
  • Page 172 The printed pattern is as follows. a) LABEL1 pattern b) LABEL2 pattern c) LABEL3 pattern d) LABEL4 pattern e) LABEL5 pattern When the FEED switch is pressed short, the following pattern is printed. “LABEL1” “LABEL2” “LABEL3” “LABEL4” “LABEL5”  “LABEL1”・・・・・・ When the FEED switch is pressed long (about one second), the same pattern is printed again.
  • Page 173 Printed result of sample printings ”LABEL1” pattern “LABEL2” pattern “LABEL3” pattern “LABEL4” pattern...
  • Page 174 “LABEL5” pattern...

  • Page 175: Regular Cleaning

    11. Regular Cleaning Printed characters may not be completely formed if paper residue, dust, or a similar material is present. To ensure proper printing, remove any paper residue and dust on the paper holder, paper transport components, platen roller, and surface of the thermal head.

  • Page 176: Cleaning The Platen Roller

    11-2. Cleaning the Platen Roller The cleaning procedure is as follows. (1) With paper inserted in the printer, turn off the printer power switch once, and turn on the switch again while holding down the FEED switch on the control panel. Then, the data shown below is printed. Test Print Sample Print Data Analysis...
  • Page 177 (2) Select "CLEANING" as your option. Press the FEED switch briefly (one second or less) three times to move to "CLEANING." Cleaning ↑ Sensor Adjustment ↑ Setup ↑ Test Print Sample Print Data Analysis Cleaning Sensor Adjustment Setup Test Print Selection Item Special Mode Usage...
  • Page 178 Then, press and hold down the FEED switch for one second or longer to accept the selection. The printer enters platen roller cleaning mode. The printer prints the following and cuts the paper when it enters platen roller cleaning mode: (4) Open the top cover, and remove the roll paper.
  • Page 179 (6) After completing cleaning, reposition the roll paper, and close the top cover. Note : Take care not to dent or otherwise damage the platen roller. A dent on the platen roller may result in incomplete printing or line feed errors.

  • Page 180: Cleaning The Thermal Head

    11-3. Cleaning the Thermal Head (1) Before attempting to clean the thermal head, be sure to turn off the printer power switch. (2) Open the top cover. (3) Using an alcohol solvent, remove black paper particles and other residue from the surface of the thermal head. If the printer printed on label paper, any adhesive matter adhering to the surface of the thermal head must be removed.

  • Page 181: Cleaning The Cutter Blade And Frame

    11-4. Cleaning the Cutter Blade and Frame If the printer printed on full-sheet label paper, any adhesive matter adhering to the cutter blade and frame must be removed. Even when label paper has been cut normally, clean the cutter blade at an interval of about once a month to ensure stability in cutting.
  • Page 182 The cleaning procedure is as follows. (1) With paper inserted in the printer, turn off the printer power switch once, and turn on the switch again while holding down the FEED switch on the control panel. Then, the data shown below is printed. Test Print Sample Print Data Analysis...
  • Page 183 (2) Select "CLEANING" as your option. Press the FEED switch briefly (one second or less) three times to move to "CLEANING." Cleaning ↑ Sensor Adjustment ↑ Setup ↑ Test Print Sample Print Data Analysis Cleaning Sensor Adjustment Setup Test Print Selection Item Special Mode Usage...
  • Page 184 (4) Press the FEED switch briefly (one second or less) once to move to "CUTTER CLEANING." Then, press the FEED switch for one second or longer to accept the selection. The printer enters cutter cleaning mode. The printer prints the following and cuts the paper when it enters cutter cleaning mode: (5) After completing cleaning, reposition the roll paper, and close the top cover.
  • Page 185 - Cleaning the Upper cutter Using a general-purpose utility knife, flathead screwdriver, or similar tool, remove the adhesive matter adhering to the inner side and edge of the Upper cutter. Note: Be very careful not to damage the edge of the Upper cutter when handling the utility knife or screwdriver.
  • Page 186 Note: Although the edge of the Upper cutter is not as sharp as the edges of the utility knives generally used in offices, there is a risk of injury to a finger that is moved while pressed directly against the edge of the cutter. (7) After completing cleaning, reposition the roll paper, and close the top cover.
  • Page 187 Cleaning the Lower cutter Using a general-purpose utility knife, flathead screwdriver, or similar tool, remove the adhesive matter adhering to the surface and edge of the Lower cutter. Note: Be very careful not to damage the edge of the Lower cutter when handling the utility knife or screwdriver.
  • Page 188 Using the cleaning sheet or a similar material, wipe off the adhesive matter adhering to the Lower cutter. Lower cutter Note: Although the edge of the Lower cutter is not as sharp as the edges of utility knives generally used in offices, there is a risk of injury to a finger that is moved while pressed directly against the edge of the cutter.

  • Page 189: Interface

    12. Interface 12-1. LAN Interface (1) LAN interface connector Pin No. Signal name I/O direction Signal line name Output Output data Output Output data Input Input data Input Input data (2) LEDs Display Description 10BASE-T link Light goes on when printer recognizes connection destination as 10BASE-T 100BASE-TX Light goes on when printer recognizes connection...
  • Page 190 (3) DIP switches Note: The DIP switches are provided for maintenance purposes. All DIP switches should be left OFF during normal operation. Off (fixed) Setup information initialization Setup information Self-diagnosis printing Procedure for initializing setup information 1) Turn off the printer power. 2) Set switch 2 to ON.

  • Page 191: Dual Interface

    12-2. Dual Interface (1) Type B Connector: 4 Pin Pin No. Signal name I/O direction Signal line name D-inB Input/Output D+inB Input/Output Ground (2) Serial interface connector Pin No. Signal name I/O direction Function Frame ground Output Send data Input Receive data Output Send request...

  • Page 192: Drawer Kick Connector

    12-3. Drawer Kick Connector Pin No. Signal name I/O direction Signal line name Output Drawer frame ground signal *DRD1 Output Drawer kick drive signal 1 DRSNS1 Input Drawer sense signal 1 +24V Output Drive power *DRD2 Output Drawer kick drive signal 2 Output Drawer sense ground signal Notes 1: "*"...
  • Page 193 <Drawer connection 1> Cable Printer Drawer Drawer kick solenoid (24 Ω minimum) Drawer open/close switch Notes :Use a shielded drawer cable. Notes :Two drives cannot be driven simultaneously. Notes :The drawer on/off time must be specified using t1 and t2 in the pulse generation command (ESC p m t1 t2).
  • Page 194 <Drawer connection 2> Drawer 1 Cable Printer Drawer open/close switch Drawer kick solenoid (24 Ω minimum) Drawer 2 Drawer open/close switch Drawer kick solenoid (24 Ω minimum)

  • Page 195: Specifications Of Power Supply

    12-4. Specifications of Power Supply (1) Operating voltage : DC 24V±10% (2) Current consumption :- Standby: 4.5W or less/0.2A on average Note: Maximum drawer kick drive current: 1A Two drawer kicks must not be driven simultaneously. - Average current consumption Operating: About 44W/1.5A on average (at 24V, 25°C, print density setting 100%, paper width 80mm, print duty 9%)

  • Page 196: Specifications

    13. Specifications 13-1. General Specifications (1) Print method: Direct line thermal printing system (2) Dot resolution: 8 dots/mm (0.125 mm) (3) Paper width: 83 mm, 80 mm, or 70 to 25.4 mm (by units of 1 mm) - The paper width is set to 70 mm at the time of shipment from the factory. - If the roll paper partition attached to the printer is removed, you can select a paper width of up to 83 mm.
  • Page 197 (5) Relationship between number of print columns and character size Body Face For paper 58mm wide For paper 60mm wide 32 column printing 35 column printing 36 column printing ANK: Font A 32 columns: 12x24 35 columns: 12x24 36 columns: 12x24 38 columns: 10x24 42 columns: 10x24 43 columns: 10x24...
  • Page 198 (6) Alphanumeric characters (95), extended graphics (128 x 20 pages), international characters (48) Kanji JIS-1990 (6879), special characters (845) (7) Dimensions of fonts Body Face Letter Face (W)x(H) dot (W)x(H) mm (W)x(H) dot (W)x(H) mm ANK: Font A 12 x 24 1.5 x 3.0 11 x 22 1.375 x 2.75...
  • Page 199 (8) External views Paper guide opened Paper guide...

  • Page 200: Cutter Specifications

    13-2. Cutter Specifications Cutting mode: Full cutting Note : For printing on label paper, use only partial cutting. If full cutting is used in such cases, paper cutting performance will deteriorate faster because of the greater adverse effect of adhesive matter. Note : Paper cutting performance may deteriorate faster with the use of label paper because of its adhesive matter.

  • Page 201: Paper Supply Specifications

    13-3. Paper Supply Specifications (1) Loading method: Rolls are loaded manually. (2) Paper near end: Detected when only a little paper is left. Paper thickness The outside core diameter <B> of roll paper is 32 mm. (µm) Sensed diameter <A> Remaining paper length (mm) 75 to 150...

  • Page 202: Interface Specifications

    13-4. Interface Specifications (1) LAN (IEEE802.3 (10BASE-T)/IEEE802.3U (100BASE-TX)) (2) Dual (Conforms to USB 1.1 and RS-232C)

  • Page 203: Environment Specifications

    13-5. Environment Specifications (1) Temperature When operating : Operation guaranteed from 0°C to 40°C. Printing guaranteed from 5°C to 35°C. When no operating : -5°C to 60°C When being transported or stored : -20°C to 60°C (While packaged) (2) Humidity When operating : Operation guaranteed from 10% to 95%RH (no condensation)

  • Page 204: Specifications Of Reliability

    13-6. Specifications of Reliability (1) Printer life Feed of 25 million lines (Specified thermal paper) or 5 years (2) Head Running life : 150km (Specified single-color thermal paper) 75km (Specified dual-color thermal paper) Pulse life : 150 million pulses * Scratches caused by foreign matter are excluded. (3) Cutter Full cutting - Receipt cutting:...

  • Page 205: Roll Paper Unit

    14. Roll Paper Unit 14-1. Outline The wide roll paper unit is optional. A maximum φ200-mm roll can be used. Mount to the rear of the printer to use. Roll paper shaft 14-2. Nomenclature (enclosed) ※Roll paper shaft for 1.5 inches and two-inch Partition diameter is an option sold separately.
  • Page 206 <Enclosed Products> Printer connector fitting Instruction sheet Fitting mounting screws (x2) Roll paper shaft Roll paper shaft (One-inch diameter) (Three-inch diameter)

  • Page 207: Paper Specifications

    14-3. Paper Specifications (1) 83mm paper width… 80mm paper width… − − 70～25.4mm (1mm unit) paper width: ～ 25.4 − (2) External dimensions (A): φ200±0.5mm max. (3) Paper width: 75 to 150µm (4) Roll core dimensions: Inside diameter (C) φ25.4±0.5mm / external diameter (B) φ32±0.5mm (One inch Roll paper) Inside diameter (C) φ76.2±0.5mm / external diameter (B) φ82±0.5mm (Three inch Roll paper)

  • Page 208: Roll Paper Feed Specifications

    14-4. Roll Paper Feed Specifications (1) Feed method: manual setting (2) Paper near end: Detected when there is little remaining paper. The remaining paper that can be detected is described below. Paper External Core Detection Remaining paper thickness diameter (B) diameter (A) (µm) (mm)

  • Page 209: Roll Paper Unit Installation Procedure

    14-5. Roll Paper Unit Installation Procedure When connecting or removing, turn OFF the power supply switches to the printer and all devices connected to the printer before starting work, and remove the plug for the AC adapter power supply cable from the outlet. (1) Remove the connector cover at the rear of the printer.
  • Page 210 (2) Mount the enclosed fitting for the printer connection using the enclosed screws. Mounting screws Printer connection fitting (3) Connect the sensor cable, interface cable, and AC adapter cable for the wide roll paper unit to the connector at the rear of the printer. ②interface cable ①AC adapter cable ③roll paper unit...
  • Page 211 (4) Connect the printer to the wide roll paper unit. Insert the holes on the left and right of the printer connector fitting into the left and right protrusions on the wide roll paper unit connector to connect. Left and right holes of printer connection bracket Left and right connection flanges...
  • Page 212 (5) Route the sensor cable, interface cable, and AC adapter cable of the roll paper unit through the cable clamps from the inside to the outside of the roll paper unit as shown in the diagram below. Interface cable Cable clamps * Open the cable clamp by core warping A part in the...
  • Page 213 (6) Take up the slack in the sensor cable between the roll paper unit and printer by securing the excess length with a cable clamp as shown in the diagram below. Sensor cable Secured with cable clamp...

  • Page 214: Method Of Setting Pne Sensor

    14-6. Method of setting PNE sensor Select PNE sensor position by each size of roll paper core diameter, then pinch and fix the screw. 1 is default position. (The following chart is a position where the paper tube of one-inch diameter is set.) : Position for 1.0 inch core size 1.5 : Position for 1.5 inch core size : Position for 2.0 inch core size...

  • Page 215: Method Of Setting Guide Plate

    14-7. Method of setting guide plate Loosen the knurled screw of the guide plate of each kind of the roll paper core size, set the set position, then fix the knurled screw. 1 is default position. (The following chart is a position where the core of one-inch diameter is set.) : Position for 1.0 inch core size 1.5 : Position for 1.5 inch core size...

  • Page 216: Setting The Roll Paper

    14-8. Setting the Roll Paper (1) Insert the paper roll to the included paper roll shaft core and set them in the large diameter paper roll unit. Roll paper Roll paper shaft Note: To load a new roll paper, first remove the tape and the glued portion at the beginning of the roll.
  • Page 217 Note : The roll paper must have no deformities. Using roll paper such as that shown in the figure below may cause a paper jam, uneven printing, or other printing problem. Note : If the loaded roll paper is loose (slack) as shown below, take up the slack before printing on the paper.
  • Page 218 (2) Set the paper width by positioning the partitions in the roll paper unit. [1] Orient the paper roll along the direction arrow A. [2] Loosen the knob screws front and back that fix the partition. [3] Align the partition to the width of the paper roll, and slide in the direction of the arrows B.
  • Page 219 (3) Pass the roll paper under the guide roller. Lift the guide roller. Then, with the printer top cover closed, insert the leading edge of the paper into the rear of the printer. Guide roller Top cover (closed) Roll paper Fig.a Note : When the rolled paper is guided on top of the guide roller as illustrated in Figure b shown below, the paper may not get through.
  • Page 220 (4) Open the top cover, and pull out the leading edge of the paper from the front of the printer. Top cover Open the top cover. Pull out the leading edge of the roll paper from the front of the printer.

  • Page 221: Roll Paper Unit Appearance

    14-9. Roll Paper Unit Appearance (When connected to the printer.)

Table of Contents
