Descriptive Diagram/Reset Function - T-Fal Deep Fryer Instructions For Use Manual

1.
2.
5.
8.
10.
12.
14
1. 1. 1.
a b
11.
a
RESET function: Your appliance is equipped with safety features. If the safety
cut-out is activated, the appliance will shut off automatically and an error code
will appear on the display. Unplug the appliance, let it cool and follow the
instructions for use. If the error code still appears, push the safety cut-out RESET
button (found on the back of the control unit) with a toothpick or similar non-
metallic object. If the problem with the safety cut-out persists, please contact our
Helpline see details on Page 13.
1.
c d
11.
b
1. Lid
a. Permanent filter
b. Filter cover
c. Handle
d. Viewing window
2. Removable
3.
control unit
3. Frying basket
3.
a
a. Handle
b. MAX. food level
3.
b
marking
4. Removable bowl
4.
5. Min. and Max. oil
level markers
6. Basket high position
6.
7. Fixed oil filter grid
8. Safety carrying
7.
handles
9. Oil box control lever
10. Body
11. Oil box
a. Lid
9.
b. Oil box cap
12. Feet
13. Electronic panel
a. Change oil
11.
indicator light
b. Digital timer
c. Temperature light
d. Power light
e. Change oil Reset
f. Temperature
touchpad / ON-OFF
g. Timer touchpad
14. Safety cut-out
reset button
5
