3.2

LED Error Status Indicators

Description LED1
Yellow
GSM engine Flashing
problem
Solution Refer to your local supplier
No Signal or Signal Flashing
low (less than
25%)
Solution Check your antenna connection or move your antenna to a
location with a better reception or enable your roaming
parameter (See Diagnostics)
Registration Flashing
denied
Solution
Contact your local GSM operator or enable your roaming
parameter (See Diagnostics)
CelluLine CGW-TS: Installation and Programming Manual
LED Status Indicators
LED2 LED3 LED4
Yellow Yellow Yellow
Flashing Flashing Flashing
Off Off Off
Off Off Flashing
Power Status
Green Red
Flashing Flashing
On Off
On Off
