- Page 1 All manuals and user guides at all-guides.com Operating and assembly instructions VL 040/041-707 Hob ventilator...
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com VL 040/041-707 Preface Safety notes Page 3 1. Important notes Page 4-5 1.1 For your safety Page 4 1.2 Operating for the first time Page 5 2. Structure and operating principle Page 6 2.1 Structure of the appliance Page 6 2.2 Accessories... -
Page 3: Preface
You will find notes on Page 3 that you ought to VL 040-707 observe before operating the appliance for the first time. Tips and hints in the chapter entitled "Cleaning and care"... -
Page 4: Safety Notes
All manuals and user guides at all-guides.com Safety notes Read And Save These Instructions. WARNING - TO REDUCE THE RISK OF FIRE, WARNING - TO REDUCE THE RISK OF INJURY ELECTRIC SHOCK, OR INJURY TO PERSONS, TO PERSONS IN THE EVENT OF A RANGE OBSERVE THE FOLLOWING: TOP GREASE FIRE, OBSERVE THE FOLLOWING:... -
Page 5: Important Notes
The appliance must only be connected by an to do with the power supply, please contact your authorised specialist, paying attention to the specialist dealer or your responsible Gaggenau relevant regulations of the power supply companies after-sales service. Repairs must be carried out by and the regional construction regulations. -
Page 6: Operating For The First Time
All manuals and user guides at all-guides.com 1.2 Operating for the first time Before operating the appliance for the first time, please pay attention to the following notes: – Conscientiously read through the operating and assembly instructions before operating the appliance for the first time. -
Page 7: Structure And Operating Principle
All manuals and user guides at all-guides.com 2. Structure and operating principle 2.1 Structure of the appliance 1 Ventilation grille 2 Control knob (VL 041-707 only) 3 Clamping screw 4 Retaining bracket 5 Suction extraction connection Fig. 3 2.2 Accessories Special accessories: AS 070-000: connection piece for extension during assembly (fig. -
Page 8: Operation
All manuals and user guides at all-guides.com 3. Operation Note: VL 040 can only be operated in combination with VL 041 or VL 051. All operator inputs apply to both hob ventilators. That is to say: if you set the control knob to level 1, both hob ventilators are operated at level 1. -
Page 9: Cleaning And Care
If the power supply is functioning correctly, but your appliance still does not work, please contact your Gaggenau dealer who will provide you with the Repairs must only be carried out by authorised address and telephone number of your nearest specialists, thus ensuring the safety of the manufacturer’s authorized service agent or contact... - Page 10 All manuals and user guides at all-guides.com 6. Assembly instructions 6.1 Technical data 6.2 How to do it Rating: 120V 60Hz WARNING - TO REDUCE THE RISK OF FIRE, Weight: 3.9 kg ELECTRIC SHOCK, OR INJURY TO PERSONS, Power consumption with GB 031: 250W OBSERVE THE FOLLOWING: Technical modifications reserved.
- Page 11 All manuals and user guides at all-guides.com The appliance must only be connected by cannot be sealed, for example in doors, windows, an authorised specialist. The specialist is incoming/exhaust air wall boxes or other technical responsible for perfect functioning of the appliance means.
- Page 12 All manuals and user guides at all-guides.com Installation Proceed as follows: – Produce the recess for the appliance. Proceed as indicated on the installation sketch and the dimension table (fig. 9). Important: the angle between the cut surface and the worktop must amount to 90°.
- Page 13 All manuals and user guides at all-guides.com – Lower the appliance into the worktop. Make sure that the engaging lugs on the appliance lie exactly on the clamping springs. Press the appliance firmly into the worktop. The engaging lugs on the appliance "snap" into the clamping springs.
- Page 14 All manuals and user guides at all-guides.com 3.6027.93ind02 en 03.03 SK...
- Page 15 All manuals and user guides at all-guides.com GAGGENAU HAUSGERÄTE GMBH 5551 McFADDEN AVENUE P.O. BOX 10 02 50 · 80076 MÜNCHEN HUNTINGTON BEACH, CA 92649 GERMANY Y (0 89) 45 90 - 03 Y (800) 828-9165 · FAX (714) 901-0979 FAX (0 89) 45 90 - 23 47 www.gaggenau-usa.com...
