Troubleshooting

Problem
Remote LED is off.
Table lift does not
Limit switch reached
move when motion
control buttons are
pressed.
Table lift travels at a
significantly slower
speed than rated
specification.
Unusual noise during
travel.
Table lift stops abruptly
during travel.
Table lift is not level.
Error Code Error Summary
E01 M1 overcurrent protection
E02 M2 overcurrent protection
E03 M3 overcurrent protection
E04 M4 overcurrent protection
E07 M1 hall error
E08 M2 hall error
E09 M3 hall error
E10 M4 hall error
Over heat /duty cycle
H01
protection
Troubleshooting Guide
Possible Cause Corrective Action
Low power mode
Press any button on the remote and LED will activate.
activated
Disconnect and reconnect the RJ-45 remote connector. Ensure connection is
Connection issue
secure and cable is not damaged.
Follow "Setting Limit Switches" instructions to remove the programmed limit. If
maximum or minimum height limit has been reached, please move the system
in the opposite direction.
Disconnect and reconnect the Lifting Columns, Control Box, AC Power, and
Connection issue
Remote.
Weight issue Ensure weight capacity has not exceeded the maximum load rating.
Weight issue Ensure weight capacity has not exceeded the maximum load rating.
Ensure there are no obstacles in the path of the table lift. If the movement
Obstacle
continues to fail, initiate the Reset Procedure.
Disconnect and reconnect all cables (Lifting Column, Control Box, AC Power,
Out of sync
and Remote), then initiate the Reset Procedure.
Error Codes (remotes with LED display)
Description
All columns stop moving and remote displays E01-E04. Ensure that the total
weight capacity of the table lift has not been exceeded and that no obstacles
obstruct the movement. Press any key and remote will display
RST, initiate the Reset Procedure. If the issue persists, disconnect and
reconnect all of the lifting columns, including the main power. Repeat the Reset
Procedure.
All columns stop moving and remote displays E07-E10. Ensure that all columns
are still properly connected to the control box. Check to see if any cables have
been damaged. Press any key and remote will display RST, initiate the Reset
Procedure. If the issue persists, disconnect and reconnect all of the lifting
columns, including the main power. Repeat the Reset Procedure.
All columns stop moving, remote displays H01 (if LED screen available). Allow
the system to rest for 16 minutes, use normally. Follow the Duty Cycle rating to
ensure no issues arise from overheating.
