Gysmi E200 FV
p. 8-12 / 28-32
73502-V4-24/01/14
73502_V2_29/04/2013

Advertisement

loading
Need help?

Need help?

Do you have a question about the Gysmi E200 FV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GYS Gysmi E200 FV

Summary of Contents for GYS Gysmi E200 FV

  • Page 1 Gysmi E200 FV p. 8-12 / 28-32 73502-V4-24/01/14 73502_V2_29/04/2013...
  • Page 2 FACE AVANT/FRONTAL SIDE/FRONTSEITE UND ANSCHLÜSSE/CARA DELANTERA/ПЕРЕДНЯЯ ПАНЕЛЬ Afficheur Voyant mode Voyant mode Sélecteur Bouton sélection/ Voyant de protection Bouton de mise en « soudage à « soudage à valeur + validation thermique marche / veille l’électrode » (MMA) l’électrode réfractaire» ou - (TIG) Display...
  • Page 3 POWER SUPPLY – START UP • These machine are delivered with a 230V socket /16A plug type EEC7/7. The GYSMI E200 FV integrate a « Flexible Voltage » system. It has to be on a power supply variable between 110V and 240V (50 – 60 Hz) WITH earth.
  • Page 4 6. Set the gas flow on flewmeter of the gas cylinder, and then open the valve of the torch 7. To boot : Touch the electrode on Raise the electrode 2 to 5 the welding part mm of the part to be welded 8.

  • Page 5: Maintenance

    MAINTENANCE • Refer all servicing to qualified personnel. • Disconnect the generator and wait until the ventilator stopped before working on the unit. Inside the device, voltages and current are dangerous. • 2 or 3 times a year, remove the steel cover and blow off the dust with compressed air. Let check the electrical connections (with an insulated tool) and the insulations by qualified personnel.
  • Page 6 RECOMMENDATION TO REDUCE ELECTRO-MAGNETIC EMISSIONS General The user is responsible for installing and using the arc welding equipment according to the manufacturer’s instructions. If electromagnetic disturbances are detected, then it shall be the responsibility of the user of the arc welding equipment to resolve the situation with the technical assistance of the manufacturer.

  • Page 7: Troubleshooting

    TROUBLESHOOTING Anomalies Causes Remedies The welder thermal protection Wait for the end of the cooling time, The device does not deliver any has turned on. around 2 minutes. The indicator current and the yellow indicator lamp turns off. lamp of thermal defect lights The display is on but the device The cable of the earth clamp or...

  • Page 8: Декларация О Соответствии

    CE Kennzeichnung: 2012 DECLARACION DE CONFORMIDAD : GYS certifica que el aparato de soldadura E200 FV es fabricado en conformidad con las directivas baja tensión 2006/95/CE del 12/12/2006, y las directivas compatibilidad electromecánica 2004/108/CE del 15/12/2004. Esta conformidad está establecida por el respeto a las normas EN 60974-1 de 2005, EN 60974-10 de 2007 y EN 50445 de 2008.
  • Page 9 SCHÉMA ÉLECTRIQUE / CIRCUIT DIAGRAM / SCHALTPLAN Gysmi E200 FV...
  • Page 10 PIÈCES DE RECHANGE/ SPARE PARTS / ERSATZTEILE/ RECAMBIOS / ЗАПЧАСТИ GYSMI E 200 FV N° Désignation E200 FV Douilles / Connectors / Schweißbuchsen / Conectores / Коннекторы 51469 Clavier/ Display / Anzeige / Teclado / Дисплей / Οθόνη 51914 Carte électronique / Electronic card / Elektronikplatine / Tarjeta electrónica / Электронная плата 97143C Cordon secteur / Power cord / Netzkabel / Cable de conexión / Сетевой...
  • Page 11 ICÔNES/ SYMBOLS/ ZEICHENERKLÄRUNG / ICONOS/ ПЕРЕДНЯЯ ПАНЕЛЬ Ampère Ampere Amperio Ампер Volt Volt Volt Voltios Вольт Hertz Hertz Hertz Hertz Герц Soudage à l’électrode enrobée (MMA – Manual Metal Arc Schweißen mit umhüllter Elektrode (MMA) Schweißen mit umhüllter Elektrode (E-Handschweißen) Soldadura con electrodos refractarios (TIG –...
  • Page 12 Nombre d'électrodes normalisées soudables en 1 heure en continu, avec 20 secondes entre chacune, divisé par le nombre d'électrodes soudables dans les mêmes conditions sans disjonction thermique. Number of standardized electrodes weldable over 1 hour of continuous work, divided by the number of electrodes weldable in the same conditions without thermal shutdown Elektroden Anzahl die inerhalb einer Arbeitsstunde verschweißt werden können, geteilt durch Elektroden- Anzahl die tatsächlich verschweißt sind (Abkühlphasen des Geräts)
