RIOTEC iDC9607LW Quick Manual

*
W e a r a b l e 2 D
P o c k e t b a r c o d e s c a n n e r
Quick Guide
M o d e l n o . : i D C 9 6 0 7 L W

Introduction

Designed primarily for P.O.S. retail environments, the iDC9607LW
is a Wearable pocket barcode scanner that allows you to scan
various barcoded items.
Its in-built excellent 2D engine allows you to reliably read 1D / 2D
barcodes on various shapes and is a great space-saver for busy or
limited workspaces.
It supports iOS, Android, and Windows devices through Bluetooth HID
or SPP communication.

Technical data

* Light source...............625±10 nm LED
* Depth of field..............(20 mil Code 39) : 340 mm
* Scan speed.................30 frame / second
* Best resolution............5 mil
* Transmission range.....BT Class 1 (100m, line of sight)
* Profiles.......................HID & SPP profile 2.4GHz Wireless
* Memory Capacity.........1MB memory inside
* Input voltage..............5V/DC
* Rechargeable battery...3.7V 900mA Li-Ion battery
* Operating time...........10,000 readings when full charged
* Operating conditions...0℃ to 50℃
* Dimensions................100 x 43 x 24.5mm (L x W x H)
* Symbologies:
2D: PDF417, QR code, Data Matrix
1D: Code 128, UCC/EAN-128, EAN-8, EAN-13, ISBN/ISSN, UPC-E,
UPC-A, Interleaved 2 of 5, Matrix 2 of 5, Industrial 25, MSI, Code
39, Codabar, Code 93, Code 11, RSS-14, RSS-Limited, RSS-Expand

Delivery content

* Pocket Barcode scanner + Strap x 1
* Mini USB cable x 1 (charged by USB power adapter of smartphone only)
* Quick instructions x 1
*
Glove + Holder + Ring Trigger Cable x 1set

Limited Warranty

Riotec provide one-year limited warranty.
Riotec will not warranty any product which has been subjected to
improper usage, neglect or unauthorized repair or installation.
Besides, warranty does not cover the faulty usages or consumable
parts. (Cable & battery are consumable.)
1

Safety instructions

Read the operating instructions carefully and especially observe the
safety information.
If you do not follow the safety instructions and information on proper
handling in this manual, we assume no liability for any resulting
personal injury or damage to property.
* Don't put scanner in places excessively high temperatures, such as
expose under direct sunlight
* Don't use scanner in extremely humid area or drastic temperature
change
* The rechargeable battery is permanently built into the product and
cannot be replaced.
* Never damage the rechargeable battery. Damaging the casing of
the rechargeable battery might cause an explosion or a fire!

Operating elements

** Please switch ON and charge scanner for 3~4 hours at first time
before use.
Exit
Window
(For iOS Device ONLY)
the button to raise and
lower ON-Screen
Keyboard
SCAN/ENTER/Power ON
Button
Mini USB port, with protective cover
scanner is charged by USB power adapter only,
via mini USB host cable of smartphone only.
* In the beginning, you must press the orange trigger button
for 8 seconds to turn on the pocket barcode scanner.
Then, press it for scanning barcodes & waking up from
sleeping mode.
Power Saving button:
Press the button for 2~3
seconds then enter
power saving mode
Indicator (LED)
