- Page 1 ® INSTRUCTION MANUAL 3 Series Upper Arm Blood Pressure Monitor Model BP7100CAN...
-
Page 2: Table Of Contents
Table of Contents Introduction ....................3 Important Safety Information ................4 1. Know Your Monitor ................8 2. Preparation ..................13 3. Using the Monitor.................14 4. Error Messages and Troubleshooting..........20 5. Maintenance ..................23 6. Specifications..................25 7. FCC/ISED Statement................27 8. Limited Warranty..................28 9. Guidance and Manufacturer’s Declaration...........30... -
Page 3: Introduction
Safety Instructions This instruction manual provides you with important information about the OMRON BP7100CAN Blood Pressure Monitor. To ensure the safe and proper use of this monitor, READ and UNDERSTAND all of these instructions. If you do not understand these instructions or have any questions, contact 1-800-634-4350 before attempting to use this monitor. -
Page 4: Important Safety Information
Important Safety Information Read the Important Safety Information in this instruction manual before using this monitor. Follow this instruction manual thoroughly for your safety. Keep for future reference. For specific information about your own blood pressure, CONSULT WITH YOUR PHYSICIAN. Indicates a potentially hazardous situation which, if not Warning avoided, could result in death or serious injury. - Page 5 • This product contains small parts that may cause a choking hazard if swallowed by infants, toddlers and children. Battery Handling and Usage • Keep batteries out of the reach of infants, toddlers and children. Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury to the user Caution or patient, or cause damage to the equipment or other...
- Page 6 • Ensure that this monitor has acclimated to room temperature before taking a measurement. Taking a measurement after an extreme temperature change could lead to an inaccurate reading. OMRON recommends waiting for approximately 2 hours for the monitor to warm up or cool down when the...
- Page 7 • Inflating to a higher pressure than necessary may result in bruising of the arm where the cuff is applied. NOTE: please refer to “If your systolic pressure is more than 210 mmHg” in section 3 of this instruction manual for additional information.
-
Page 8: Know Your Monitor
1. Know Your Monitor Contents: Monitor, arm cuff, instruction manual, quick start guide Monitor: Display Battery compartment START/STOP button Air jack Memory button Arm cuff: Arm cuff (Arm circumference 9" - 17" (22 - 42 cm)) Air plug Air tube... - Page 9 1.1 Display and Symbols Memory symbol Appears when viewing readings stored in the memory. Systolic blood pressure reading Diastolic blood pressure reading Low battery symbol Flashes when batteries are low. Depleted battery symbol Appears when batteries are depleted. Heartbeat symbol Flashes while taking a measurement.
- Page 10 Irregular heartbeat symbol Appears along with readings when an irregular rhythm is detected 2 or more times during a measurement. An irregular heartbeat rhythm is defined as a rhythm that is 25% less or 25% more than the average rhythm detected while your monitor is measuring blood pressure.
- Page 11 Classification of BP (Blood Pressure) ACC/AHA 2017 Hypertension guidelines define categories of BP in adults as below. Categories of BP in Adults* BP Category Systolic BP Diastolic BP Normal < 120 mmHg < 80 mmHg Elevated 120-129 mmHg < 80 mmHg Hypertension Stage 1 130-139 mmHg...
- Page 12 1.2 Blood Pressure Measurement Tips To help ensure an accurate reading, follow these directions: • Stress raises blood pressure. Avoid taking measurements during stressful times. • Measurements should be taken in a quiet place. • It is important to take measurements at the same times each day. Taking measurements in the morning and in the evening is recommended.
-
Page 13: Preparation
2. Preparation 2.1 Battery Installation Remove the battery cover. Insert 4 “AA” batteries as indicated in the battery compartment. Replace the battery cover. Notes: • When the low battery symbol ( ) appears on the display, turn the monitor off, then replace all batteries at the same time. Long life alkaline batteries are recommended. -
Page 14: Using The Monitor
3. Using the Monitor 3.1 Applying the Arm Cuff Remove tight-fitting, thick clothing from your arm Caution while taking a measurement. Insert the air plug into the air jack securely. Place your hand through the cuff loop, then pull the cuff until it reaches your upper left arm. - Page 15 • The blood pressure can differ between the right arm and the left arm, and the measured blood pressure values can be different. OMRON recommends to always use the same arm for measurement. If the values between both arms differ substantially, please check with your physician which arm to use for your measurements.
- Page 16 3.2 How to Sit Correctly To take a measurement, you need to be relaxed and comfortably seated with a comfortable room temperature. Place your arm on the table. • Sit in a comfortable chair with your back and arm supported. •...
- Page 17 3.3 Taking a Measurement Notes: • To stop the measurement, press the START/STOP button once to deflate the arm cuff. • Remain still and quiet while taking a measurement. Press the START/STOP button. The arm cuff will start to inflate automatically. START INFLATING COMPLETED...
- Page 18 Remove the arm cuff. Press the START/STOP button to turn the monitor off. The monitor automatically stores the measurement result in its memory. It will automatically turn off after 2 minutes. Note: Wait 2-3 minutes before taking another measurement. Waiting between measurements allows the arteries to return to the condition prior to taking a measurement.
- Page 19 To Delete All the Values Stored in Memory Press the button, while the memory symbol appears. While holding the button down, press the START/STOP button for more than 3 seconds. Note: You cannot partially delete the values stored in memory.
-
Page 20: Error Messages And Troubleshooting
4. Error Messages and Troubleshooting If any of the below problems occur during measurement, check to make sure that no other electrical device is within 12 inches (30 cm). If the problem persists, refer to the table below. 4.1 Error Messages Error Display Cause Solution... - Page 21 Insert the plug securely. Air plug disconnected. Refer to section 3.1. Apply the arm cuff tighter. Arm cuff is applied too loosely. Refer to section 3.1. Replace the arm cuff with a new Air is leaking from the arm cuff. one.
- Page 22 Device error. Contact Customer Service. 4.2 Troubleshooting Problem Cause and Solution Replace all batteries with new ones. No power. Check the battery installation for proper placement of the battery polarities. No display appears on the monitor. Refer to section 2.1. Blood pressure varies constantly.
-
Page 23: Maintenance
5. Maintenance 5.1 Maintenance To protect your monitor from damage, please follow the directions below: • Changes or modifications not approved by the manufacturer will void the user warranty. DO NOT disassemble or attempt to repair this monitor or other components. This may cause an Caution inaccurate reading. - Page 24 5.3 Cleaning • Do not use any abrasive or volatile cleaners. • Use a soft dry cloth or a soft cloth moistened with neutral soap to clean your monitor and arm cuff, and then wipe them with a dry cloth. •...
-
Page 25: Specifications
6. Specifications Model BP7100CAN HEM-7121-CA2 Display LCD digital display Cuff pressure range Pressure: 0 to 299 mmHg Measurement range Pressure: 20 to 280 mmHg Pulse: 40 to 180 beats / min. Pressure: ±3 mmHg Accuracy Pulse: ± 5% of display reading... - Page 26 Notes: • These specifications are subject to change without notice. • This monitor complies with the requirements of ISO 81060-2:2013. In the clinical validation study, K5 was used on 85 subjects for determination of diastolic blood pressure. • This monitor has not been validated for use on pregnant patients. •...
-
Page 27: Fcc/Ised Statement
7. FCC/ISED Statement FCC CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of FCC Rules and Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 28: Limited Warranty
8. Limited Warranty Your BP7100CAN Automatic Blood Pressure Monitor, excluding the arm cuff, is warranted to be free from defects in materials and workmanship appearing within 2 years from the date of purchase, when used in accordance with the instructions provided with the monitor. - Page 29 OMRON SHALL NOT BE LIABLE FOR LOSS OF USE OR ANY OTHER SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT COSTS, EXPENSES OR DAMAGES. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
-
Page 30: Guidance And Manufacturer's Declaration
Information for Accompanying Documents in the Scope of IEC60601-1-2:2014 Important information regarding Electromagnetic Compatibility (EMC) BP7100CAN conforms to IEC60601-1-2:2014 Electromagnetic Compatibility (EMC) standard. Further documentation in accordance with this EMC standard is available at OmronHealthcare.ca/emc. Refer to the EMC information for BP7100CAN on the website. - Page 31 OMRON HEALTHCARE Co., Ltd. 53, Kunotsubo, Terado-cho, Muko, Kyoto, 617-0002 JAPAN Distributed by: OMRON HEALTHCARE, INC. 1925 West Field Court, Lake Forest, IL 60045 U.S.A. OmronHealthcare.ca © 2019 OMRON HEALTHCARE, INC. Made in Vietnam 2881878-0A...
